Your pressure washer has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
DANGER:
You WILL be KILLED or SERIOUSLY HURT if you do not follow the instructions in this operator's
manual.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
GASOLINE PRESSURE wASHER
3000 PSI
Ry80030A
Advertisement
Table of Contents
Related Manuals for Ryobi 3000 PSI, RY80030A
Summary of Contents for Ryobi 3000 PSI, RY80030A
- Page 1 Your pressure washer has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. DANGER: You WILL be KILLED or SERIOUSLY HURT if you do not follow the instructions in this operator’s manual.
-
Page 2: Table Of Contents
Introduction ... Important Safety Instructions ...3 Specific Safety Rules...4 Symbols ... 5-6 Features ... 7-8 Assembly ... 9-1 Operation ... 1-15 Maintenance ... 16-18 Troubleshooting ...19 Warranty ... 1-5 Parts Ordering / Service ...6 This tool has many features for making its use more pleasant and enjoyable. -
Page 3: Important Safety Instructions
IMPORTANT SAFETy INSTRUCTIONS wARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or carbon monoxide poisoning which will cause death or serious personal injury. READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT ... -
Page 4: Specific Safety Rules
Never direct a water stream towards people or pets, or any electrical device. Before starting any cleaning operation, close doors and windows. Clear the area to be cleaned of debris, toys, outdoor furniture, or other objects that could create a hazard. -
Page 5: Symbols
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SyMBOL NAME Wet Conditions Alert Read The Operator’s Manual Eye Protection Safety Alert Hot Surface... -
Page 6: Symbols
The following signal words and meanings are intended to explain the levels of risk associated with this product. SyMBOL SIGNAL DANGER: wARNING: CAUTION: CAUTION: SERVICE Servicing requires extreme care and knowledge and should be performed only by a qualified service technician. For service we suggest you return the product to your nearest AUTHORIZED SERVICE CENTER for repair. -
Page 7: Features
FEATURES PRODUCT SPECIFICATIONS Engine Size ...11 cc Engine Output, Horsepower ...7 HP Fuel Tank Capacity ... 3.8 quarts (3.6 liters) Maximum Pounds per Square Inch Pressure ... 3000 psi Maximum Gallons Per Minute ....7 GPM nOzzle CleAnIng tOOl CHOKe reCOIl fUel stArter vAlve... - Page 8 SUBARU ENGINE ® This 7 HP engine enables the pressure washer to achieve 3,000 PSI and .7 gallons per minute. THERMAL RELIEF VALVE This pump feature will prevent water temperatures from reaching harmful levels by releasing a small amount of water from a rubber hose.
-
Page 9: Assembly
NOTE: Do not start the pressure washer until the engine has been filled with oil and all hoses are connected. Running this machine without oil will damage the engine while running it without water will damage the high pressure pump. - Page 10 ATTACHING THE RESTING FOOT See Figure 3. Lift the machine slightly. Slide the resting foot into the bottom of the spray wand storage tube. Push the resting foot into the storage tube until the base of the machine rests in the grooves on top of the resting foot.
- Page 11 When adding gas to the pressure washer, make sure the unit is sitting on a flat, level surface and that the engine is not hot. If the engine is hot, let the pressure washer cool before adding gas. ALWAYS fill the fuel tank outdoors.
- Page 12 Water supply must come from a home water main. NEVER use hot water or water from pools, lakes, etc. Before connecting the garden hose to the pressure washer: Run water through the hose for 30 seconds to clean any ...
-
Page 13: Starting/Stopping
APPLICATIONS This product has been designed for the purposes listed below: Removing dirt and mold from decks, cement patios, and house siding Cleaning cars, boats, motorcycles, outdoor furniture, and grills STARTING/STOPPING THE PRESSURE wASHER See Figures 11 - 13. CAUTION: Do not run the pump without the water supply connected and turned on. - Page 14 NEVER change nozzles without locking the lock out on the spray wand. Using the quick-connect collar, changing nozzles is easy. Turn off the pressure washer and shut off the water supply. Pull trigger to release water pressure. To connect a nozzle to the spray wand: Push the nozzle into the quick-connect collar want until ...
-
Page 15: Operation ................................................................................................................................................................... 1
Loosen the pivot knob located halfway down the spray wand storage tube. Grasp the handle at the rear of the pressure washer. Turn the top section of the pressure washer until it is fully ex- tended as shown in figure 17. Retighten the pivot knob. -
Page 16: Maintenance
wARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. wARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If operation is dusty, also wear a dust mask. wARNING: Before inspecting, cleaning or servicing the machine, shut off engine, wait for all moving parts to stop, and discon-... -
Page 17: Nozzle Maintenance
Excessive pump pressure (a pulsing sensation felt while squeezing the trigger) may be the result of a clogged or dirty nozzle. Turn off the pressure washer and shut off the water supply. Pull trigger to release water pressure. Remove the nozzle from the spray wand. -
Page 18: Maintenance
STORING THE PRESSURE wASHER It is important to store this product in a frost-free area. Always empty water from all hoses, the pump, the fuel tank, and the detergent bucket before storing. NOTE: Use of a fuel stabilizer and pump saver will give you better performance and increase the life of the machine. -
Page 19: Troubleshooting
PROBLEM Engine fails to start Engine hard to start Engine lacks power Detergent fails to mix with spray Pump doesn’t produce pressure Machine doesn’t reach high pressure TROUBLESHOOTING CAUSE 1. Engine switch is in the off position . No fuel in tank 3. - Page 20 NOTES...
-
Page 21: Warranty
FEDERAL EMISSIONS COMPONENT DEFECT wARRANTy EMISSIONS COMPONENT DEFECT wARRANTy COVERAGE This emission warranty is applicable in all States, except the State of California. Fuji Heavy Industries Ltd. and Robin America Inc., Wood Dale, Illinois, (herein “ROBIN AMERICA”) warrant(s) to the initial retail purchaser and each subsequent owner, that this Nonroad engine (herein “engine”) has been designed, built, and equipped to conform at the time of initial sale to all applicable regulations of the U.S. - Page 22 CALIFORNIA EMISSION CONTROL wARRANTy STATEMENT yOUR wARRANTy RIGHTS AND OBLIGATIONS The California Air Resources Board and Fuji Heavy Industries Ltd. (herein “FUJI”) are pleased to explain the emission control system warranty on your small off-road engine (SORE). In California, new SOREs must be designed, built, and equipped to meet the State’s stringent anti-smog standards.
- Page 23 When warranty repair is needed, the engine must be brought to an authorized service dealer or warranty station’s place of business during normal business hours. In all cases, a reasonable time, not to exceed 30 days, must be allowed for the warranty repair to be completed after the engine is received by the authorized service dealer or warranty station.
- Page 24 LIMITED ROBIN/SUBARU (Effective with engines purchased from Robin America, Wood Dale, IL, after November 15, 1993) Robin America, Inc., a division of Fuji Heavy Industries, Ltd. (herein “Robin”), warrants that each new engine sold by it will be free, under normal use and service, from defects in material and workmanship for a period listed below from the date of sale to the original retail purchaser.
- Page 25 United States and Canada. To locate your nearest Authorized RYOBI wARRANTy Service Center). ® brand pressure washer manufactured by Techtronic Industries North America, Inc. and Service Center, dial 1-800-860-4050. ® brand pressure washer ® Service Center within the warranty ®...
- Page 26 Ryobi Limited used under license. ® TECHTRONIC INDUSTRIES NORTH AMERICA, INC. 983000-86 10-05 (REV: 00) OPERATOR’S MANUAL GASOLINE PRESSURE wASHER 3000 PSI Ry80030A RY80030A 148 Pearman Dairy Road, Anderson, SC 965 Post Office Box 107, Anderson, SC 96-107 Phone 1-800-860-4050 www.ryobitools.com...
