Ryobi P2601 Operator's Manual

Ryobi P2601 Operator's Manual

18 volt hedge trimmer
Hide thumbs Also See for P2601:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
ACCEPTS ALL ONE+ BATTERY PACKS
BATTERIES AND CHARGERS SOLD
SEPARATELY
Your hedge trimmer has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 VOLT HEDGE TRIMMER
P2601

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P2601 and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi P2601

Summary of Contents for Ryobi P2601

  • Page 1 ACCEPTS ALL ONE+ BATTERY PACKS BATTERIES AND CHARGERS SOLD SEPARATELY Your hedge trimmer has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION CALL US FIRST For any questions about operating or maintaining your product, call the Ryobi Your product has been fully tested prior to shipment to ensure your complete satisfaction. Help Line! ®...

  • Page 3: General Safety Rules

     Avoid dangerous environments. Do not use the tool in damp or wet locations. Do not operate the hedge trimmer in rain.  Maintain tools with care. Keep cutting tools sharp and clean.

  • Page 4: Specific Safety Rules

     Before starting the hedge trimmer, make sure the blade is not in contact with any object.  Stop the unit, remove the battery pack, and make sure the blade has stopped before setting the unit down.  Never cut any material with a diameter larger than 3/8 in.

  • Page 5: Symbols

    Keep all bystanders at least 50 ft. away. Wear non-slip, heavy-duty protective gloves when handling the blades. Hold and operate the hedge trimmer properly with both hands. Keep hands away from moving parts. Failure to use in dry conditions and to observe safe practices can result in electric shock.

  • Page 6: Symbols

    To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand completely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance.

  • Page 7: Features

    Motor ...18 V DC Blade Length ... 18 in. SCABBARD BLADES KNOW YOUR HEDGE TRIMMER See Figure 1. The safe use of this product requires an understanding of the information on the tool and in this operator’s manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules.

  • Page 8: Assembly

    APPLICATIONS You may use this product for the purpose listed below:  Trimming and shaping hedges and shrubbery This product will accept Ryobi One+ 18 V lithium-ion battery packs and Ryobi One+ 18 V nickel-cadmium battery packs. For complete charging instructions, refer to the Operator’s Manual for the battery packs and chargers listed in the General Safety Rules.

  • Page 9: Holding The Hedge Trimmer

    TO INSTALL BATTERY PACK See Figure 2.  Place the battery pack in the hedge trimmer. Align the raised rib on the battery pack with groove in the hedge trimmer’s battery port.  Make sure the latches on each side of the battery pack snap in place and that the battery pack is secured in the hedge trimmer before beginning operation.

  • Page 10: Operating Tips

     Before starting the hedge trimmer, hold the unit with both hands with the cutting blades directed away from you. Always use the hedge trimmer properly.

  • Page 11: Maintenance

    Use clean cloths to remove dirt, dust, oil, grease, etc. BATTERIES This product will accept Ryobi One+ 18 V lithium-ion battery packs and Ryobi One+ 18 V nickel-cadmium battery packs. Length of service from each charging will depend on the type of work you are doing.

  • Page 12: Replacing Blades

    Removing the blade:  Remove the battery pack from the hedge trimmer.  Place the hedge trimmer upside down on a workbench and remove the four (4) blade cover screws.  Remove the blade cover.

  • Page 13: Lubricating The Blade

     Reinstall the battery pack and resume use. SHARPENING THE BLADE See Figure 10.  Allow the blades of the hedge trimmer to come to a stop in the position shown. This will allow clearance for the file between the cutter teeth and the guard teeth.

  • Page 14: Cleaning The Hedge Trimmer

     Slide the scabbard over the blade.  Remove the battery pack.  Clean dirt and debris from the body of the hedge trimmer, using a damp cloth with a mild detergent. NOTE: Do not use any strong detergents on the plastic housing or the handle.

  • Page 15: Warranty

    Blower Fans, Blower and Vacuum Tubes, Vacuum Bag and Straps, Guide Bars, Saw Chains Techtronic Industries North America, Inc., reserves the right to change or improve the design of any RYOBI outdoor product without assuming any obligation to modify any product previously manufactured.
  • Page 16 1-800-860-4050. • HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-860-4050. RYOBI is a registered trademark of Ryobi Limited used under license. ® TECHTRONIC INDUSTRIES NORTH AMERICA, INC. 987000-314 04-10-08 (REV:0) OPERATOR’S MANUAL...
