TriSquare GE 35811 User Instruction Manual

Buttons and Controls

1) On/Off/Volume
counter-
clockwise to
ON and increase
listening volume.
clockwise to
decrease volume
power OFF.
2) PTT (Push to
Press to transmit,

to receive.

3) PAGE – Press to
call tone to other
tuned to the
channel.
4) CHANNEL (up/down) – Press the up arrow to
increment and down arrow to decrement.
5) MON – Press to deactivate the automatic squelch
feature and listen to the air traffic on the current
channel before initiating transmission. Press the
MON button again to return to standby.
6) MODE – Use for setting individual CTCSS
codes and selecting call tones.
7) Accessory Jack – Insert optional headphones
into the accessory jack to listen to calls. This will
disable the built-in speaker.
8) MIC – Built-in microphone
9) Speaker – Built-in speaker
10) Antenna
TriSquare Communications
GE 35811 – User Instruction Guide – Content Draft

Display

– Turn
power
Rotate
1) Battery Icon – Indicates the battery level. When
and turn
the batteries are nearly drained, the icon will start
to blink, and the unit beeps peridically.
2) RX icon – Indicates when the unit is receiving a
Talk) –
transmission.
release
3) TX icon – Indicates when the unit is transmitting.
4) Subcode CTCSS icon – Shows the current sub
code number (0-38).
send a
5) Channel number – Shows the current channel
radios
(1-14).
same
6) CALL icon – Displays call tone number (1-5).
7) Lock Icon – Displays when the keypad lock is
turned on.

Battery Installation

Your radio uses 3 AA Alkaline batteries for power.
To install the batteries:
1) Remove the battery compartment door by
sliding it down from the unit.
2) Install 3 AA Alkaline batteries (not included)
into the battery compartment.
follow the + and – symbols in the compartment.
Installing the batteries incorrectly will prevent
the unit from operating.
Note: In order to maintain your user settings
(CTCSS code assignment, current channel, etc.)
make sure the unit is off before removing the
batteries. Your
approximately 10 minutes while you install the new
batteries.
Draft for content only – customer to define layout and additional graphics
Be certain to
settings will remain for

Low Battery Alert

When the batteries in the unit are low, the unit will
emit a "low battery" tone indication. Replace the
batteries immediately to continue using the radio.

Belt Clip Installation and Removal

To install the belt clip, line up the grooves on the
clip with the grooves on the back of the unit. Push
downward until it snaps into place.
To remove the belt clip, release the snap with your
finger or a tool while firmly pushing the clip upward.

Using Your Family Radio

1. Turn on power.
2. Check the battery condition on the display
3. Set to desired channel.
4. Adjust volume to comfortable level.

To Transmit

Press the PTT button. Speak slowly and clearly 2-3
inches from the microphone. To avoid cutting off
the first part of your transmission, pause slightly
after pressing the PTT button before you start
talking. The transmit symbol is displayed while the
unit is transmitting.
To Receive
When you are finished talking, release the PTT
button to listen to the transmission. The receive icon
is displayed while the unit is receiving.
Page 1
