RKI Eagle 2 Operator's Manual

6 gas sample drawing monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Eagle 2 Data Logger
Management Program
Operator's Manual
Part Number: 71-0170RK
Revision: F
Released: 7/20/18
www.rkiinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eagle 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RKI Eagle 2

  • Page 1 Eagle 2 Data Logger Management Program Operator’s Manual Part Number: 71-0170RK Revision: F Released: 7/20/18 www.rkiinstruments.com...
  • Page 2 Warranty RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials and workmanship, and performance for a period of one year from date of shipment from RKI Instruments, Inc. Any parts found defective within that period will be repaired or replaced, at our option, free of charge.

  • Page 3: Table Of Contents

    Eagle 2 Data Logging Capacity ....... 20 Overwriting Data in the Eagle 2 ....... 21 Viewing Data in the Instrument Information Screen .
  • Page 4 Calibrating An Eagle 2 With the Data Logging Software ..73 Changing Eagle 2 Instrument Parameters ..... . 77 Detail Settings Button .

  • Page 5: Introduction

    Program. The Eagle 2 Data Logger Management Program downloads stored data in the Eagle 2 to a Windows-based PC. After the data has been downloaded, you can view, save, or print it using your computer and the Eagle 2 Data Logger Management Program.

  • Page 6: System Requirements

    System Requirements To use the Eagle 2 Data Logger Management Program , your personal computer must meet the following requirements: ® ®...

  • Page 7: Installing The Eagle 2 Data Logger Management Program

    9. After a few seconds, a screen appears indicating that the InstallShield Wizard is preparing to install the Data Logger Management Program, then the Eagle 2 InstallShield Wizard window appears to guide you through installation. Installing the Eagle 2 Data Logger Management Program • 3...
  • Page 8 .zip file, it will ask you if you want to keep these newer files. Click Yes. 12.When the InstallShield Wizard indicates that installation is complete, click the Finish button. 4 • Installing the Eagle 2 Data Logger Management Program...

  • Page 9: Irda Downloading Cable

    IrDA Downloading Cable The Eagle 2 communicates with a computer via an on-board infrared communication port that complies with IrDA protocol standards. NOTE: If your computer has a built-in infrared port, you do not need an adapter cable to download data.

  • Page 10: Windows ® Wireless Link Operation Note

    ® Windows Wireless Link Operation Note When using an IrDA adapter cable and the Eagle 2 Data Logger ® Management Program on a Windows computer, it is necessary to make a special setting in the Wireless Link Configuration window for proper communication between the Eagle 2 and the Eagle 2 Data Logger Management Program.
  • Page 11 Deselect Figure 2: Image Transfer Tab 6. Click OK. 7. Close the Control Panel window. IrDA Downloading Cable • 7...

  • Page 12: Launching The Program

    Eagle 2 from the list of apps. 2. The program will launch and the Download Window will appear. Figure 3: The Download Window 3. For convenience, make a shortcut of the Eagle 2 Data ® Logger Management Program and place it on the Windows ®...

  • Page 13: Control Buttons

    Control Buttons This section provides an overview of the control buttons. Instructions for using the various parts of the program accessed by the control buttons are given in other parts of this manual. When the program is launched, it opens in the Download Window.

  • Page 14: Download Button

    See “Downloading Data from the Eagle 2” on page 15 for a complete description of downloading data from an Eagle 2. Instrument Information Button Clicking the Instrument Information button opens the Instrument Information Window.

  • Page 15: Data Button

    A calibration history file is saved for each instrument that has been downloaded. It records the calibration information for every calibration that was downloaded. The Eagle 2 can save information for up to 100 calibrations in its memory. Control Buttons • 11...
  • Page 16 100 alarm events in its memory. • Trouble Event Files Trouble event files record sensor failure and system failure events that have been downloaded from instruments. The Eagle 2 can save up to 100 trouble events in its memory. 12 • Control Buttons...

  • Page 17: Last Calibration Button

    Figure 7: Last Calibration Window The Last Calibration Window stores the information for the most recent successful calibration for each Eagle 2 that has been downloaded. You can display the information three ways by using the Need Calibration, Calibration Date, or Calibration Record selection buttons.

  • Page 18: Set Button

    • Alter the appearance of the software windows with the Font and Color buttons • Change parameters of a connected instrument by editing the fields in the Eagle 2 Status frame and in the Gas/Sensor frame at the bottom of the window and clicking the Update button •...

  • Page 19: Downloading Data From The Eagle 2 • 15

    Download Commands are not selectable. 2. Place the Eagle 2 within an inch or two of the infrared port on your computer aligning the infrared port on the front of the Eagle 2 with the infrared port on your computer.
  • Page 20 IrDA adapter cable as shown in Figure 10 below, aligning the infrared port on the front of the Eagle 2 with the infrared port on the cable. Figure 10: Aligning the Eagle 2 with the Cable Infrared Receiver 3. Press and hold the POWER...
  • Page 21 Download window indicate what actions the program is performing and if there are any communication or downloading problems. These messages also tell you what type of information has been downloaded. Downloading Data from the Eagle 2 • 17...
  • Page 22 Information control button if the unit is still turned on and connected to the computer. For more information on the Instrument Information screen, see “Viewing Data in the Instrument Information Screen” on page 22. 18 • Downloading Data from the Eagle 2...
  • Page 23 Last Calibration Window” on page 66. 9. After downloading data from an instrument, you can delete all the data in the Eagle 2 by clicking Clear Logger Data if desired. This will not delete instrument parameters such as serial number, alarm settings, or autocalibration settings.

  • Page 24: Eagle 2 Data Logging Capacity

    The interval trend time setting can be set using the Set Window (see “Changing Eagle 2 Instrument Parameters” on page 77). It can also be set in the Eagle 2 Setup Mode (see the Eagle 2 Operator’s Manual).

  • Page 25: Overwriting Data In The Eagle 2 • 21

    Setup Mode. To set the Data Log Overwrite function to Off, see the Eagle 2 Operator’s Manual. When the Data Log Overwrite function is set to off, the Eagle 2 will stop saving data when its data logging memory is full.

  • Page 26: Viewing Data In The Instrument Information Screen

    Viewing Data in the Instrument Information Screen You can view information for an instrument that has been downloaded and is currently connected by using the Instrument Information Window. Information cannot be printed or deleted in this window. Once the instrument is turned off, the Instrument Information Window becomes blank.
  • Page 27 • After — shows the gas response after calibration. • A. Cal. — lists the auto-calibration setting for each channel of the Eagle 2. If a Eagle 2 passes its calibration, the “After” column should match the “A. Cal.” column. If the Eagle 2 fails calibration on any of its channels, those channels will retain the previous calibration information.

  • Page 28: Viewing, Printing, Exporting, & Deleting Data In The Data Window

    Viewing, Printing, Exporting, and Deleting Data in the Data Window The Eagle 2 logs four types of data files: calibration history, interval trend data, alarm trend data, and event data. You can view, print, and export (save to a file) each of these types of data files.
  • Page 29 The Data Window is divided into four frames. The upper left frame is the Data Frame and displays all the data folders. They are grouped under the Eagle 2 icon in the upper left part of the frame. If the data folders are not visible, double click the Eagle 2 icon to make them visible.

  • Page 30: Calibration History

    Calibration History The Eagle 2 is capable of saving calibration information for up to the 100 most recent calibrations. This calibration history is retrieved by the Data Logger Management Program when data is downloaded from the Eagle 2 using either the Complete Download download command or the Download Logger Data download command.
  • Page 31 Histories file Figure 17: Data Window - Selecting Calibration History Files 2. If necessary, double-click the Eagle 2 icon in the top of the Data Window’s upper left frame to see the folders of downloaded data. 3. Find your instrument by serial number, then click the expanded view symbol (+) of or double-click the serial number folder to view the contents.The top folder is untitled...
  • Page 32 below the untitled folder along with the Alarm Events and Trouble Events folders. 5. Click the Calibration History folder. The Calibration Histories file or files for that instrument will appear in the top right frame. If multiple Station ID’s or User ID’s are used for an instrument, then more than one Calibration Histories file will appear.
  • Page 33 9. If you want to print the data, click the Print button. A Printer List dialog box will appear for you to select a printer. Figure 19: Printer List Dialog Box, Calibration History 10.Select a printer and click OK to print the data. 11.To export the data for use in another application, for example a spreadsheet or database, click the Export button.

  • Page 34: Event Data

    Event Data The Eagle 2 not only saves trend files which include logged data at scheduled times, but also saves the 100 most recent alarm events and the 100 most recent trouble events. When an...
  • Page 35 Alarm event file Figure 21: Data Window - Selecting Event Data Files 2. If necessary, double-click the Eagle 2 icon in the top of the Data Window’s upper left frame to see the folders of downloaded data. 3. Find your instrument by serial number, then click the expanded view symbol (+) of or double-click the serial number folder to view the contents.The top folder is untitled...
  • Page 36 untitled folder. The Alarm Events Folder and Trouble Events Folder will appear below the untitled folder along with the Calibration History Folder. 5. Click the Alarm Events or Trouble Events folder. One or more alarm or trouble event files will appear in the top right frame.
  • Page 37 Figure 23: Data View - Trouble Events 8. If you click the Summary button, the Data Window will split into two frames one above the other with the event list in the lower frame and the summary information shown in the upper frame.

  • Page 38: Interval Trend Data

    The interval trend time is set using either the Data Log Interval menu item in the Eagle 2 Setup Mode or the Interval Trend Time item in the Set window. See “Changing Eagle 2 Instrument Parameters” on page 77 or the Eagle 2 Operator’s Manual for instructions to set...
  • Page 39 An interval trend data file is created and saved in the Eagle 2 when the instrument is turned off or when a user ID, station ID, or catalytic combustible channel gas configuration (using the relative response feature in Display Mode) is changed during operation.
  • Page 40 Interval trend files Figure 26: Data Window - Selecting Interval Trend Data Files 2. If necessary, double-click the Eagle 2 icon in the top of the Data Window’s upper left frame to see the folders of downloaded data. 3. Find your instrument by serial number, then click the expanded view symbol (+) of or double-click the serial number folder to view the contents.The top folder is untitled...
  • Page 41 dated folder whose contents you want to see. 5. Click on the Interval Trend Folder. In the upper right frame of the Data Window, a list of file names will appear in the Name column. A prefix of “iv” indicates an interval trend data file. 6.
  • Page 42 “normal” condition after an alarm has been reset using the POWER ENTER RESET button on the Eagle 2. • If you click the Summary button, the Data Window will...
  • Page 43 • The catalytic combustible channel can be recorded in %LEL, ppm, or %volume units depending on the instrument setting. When viewing the interval trend data in table format, the units are displayed as the unit the reading was recorded in. Figure 28: Interval Trend Data Table Format (4 Gas) Viewing, Printing, Exporting, and Deleting Data in the Data Window •...
  • Page 44 • If installed, an infrared methane or hydrocarbon channel records data in %LEL and/or % volume units depending on whether the channel is configured as a % LEL channel or a %LEL/% volume autoranging channel. When viewing the interval trend data in table format, the units are displayed as the unit the reading was recorded in.
  • Page 45 8. When the data is viewed in table format, if you move the cursor over an alarm event, it will change into a small symbol that looks like an alarm trend data file while it is kept over the alarm event. Alarm Trend Cursor...
  • Page 46 If you click on the event, the corresponding alarm trend data file will be opened in a new window that pops up over the Data Window. No control buttons will be visible along the right side of the new window when an alarm trend data file is displayed in this way.
  • Page 47 NOTE: The data count shown when you have selected an interval trend data file, as in Figure 26 above, can be more than five if you have events, such as the Eagle 2 going into and out of alarm, but you may not have five scheduled data points.
  • Page 48 Event Select Cursor Feature Zoom Level Catalytic Combustible Channel Reading Units Figure 32: Interval Trend Data in Graph Format When viewing interval trend data in graph format, you have several options: • You can choose which gas(es) you want to graph by selecting or deselecting the boxes next to each gas name.
  • Page 49 session and on the zoom factor. Depending on the length of the data session, data sessions that show changing readings will normally have more choices for zoom levels than sessions that show stable data to allow for viewing of gas reading changes in greater detail. •...
  • Page 50 channel is the first channel and is displayed in green. Event Select Cursor Feature Zoom Level Catalytic Combustible Channel Reading Units Figure 33: Interval Trend Data in Graph Format • If installed, an IR HC or CH channel can be graphed in %LEL or % volume in order to accurately depict the full range of the sensor.
  • Page 51 %LEL up to 100% LEL and then it will start recording data in % volume up to 100% volume. If %LEL is chosen as the graphing units, all data collected for a %LEL only channel will be displayed. Any data collected in an autoranging configuration that exceeds 100% LEL will not be shown.
  • Page 52 IR HC or CH4 Cursor feature autoranging sensor Zoom Level Catalytic combustible channel reading units Event select channel reading units Figure 34: Interval Trend Data in Graph Format With Autoranging NOTE: The IR Range Select selection box in the lower right hand corner only appears if an IR HC or CH sensor is installed, is in use, and is set up for autoranging.
  • Page 53 information shown in the lower right frame in Figure 26. To return to the one frame format, click Summary again. 12.To print the data, whether it is viewed in table or graph format, click the Print button. A Printer List dialog box will appear for you to select a printer.

  • Page 54: Alarm Trend Data

    If the Eagle 2 was operating in Inert Mode at the time of the alarm, the maximum oxygen readings will be saved. If the Eagle 2 has not been on for 30 minutes before the alarm event occurs, the data during this time is left blank.
  • Page 55 Alarm trend files Figure 37: Data Window - Selecting Alarm Trend Data Files 2. If necessary, double-click the Eagle 2 icon in the top of the Data window’s upper left frame to see the folders of downloaded data.
  • Page 56 5. Click on the Alarm Trend Folder in the upper left frame. In the upper right frame of the Data window, a list of file names will appear in the Name column. A prefix of “al” indicates an alarm trend data file. 6.
  • Page 57 • In table format, the log times are shown along with the peak (minimum for oxygen) gas readings for the previous five seconds. • The gas readings at the time of the alarm event around which the logged data are centered are highlighted in red and are the instantaneous readings at that time.
  • Page 58 • If installed, an infrared methane or hydrocarbon channel records data in %LEL and/or % volume units depending on whether the channel is configured as a % LEL channel or a %LEL/% volume autoranging channel. When viewing the alarm trend data in table format, the units are displayed as the unit the reading was recorded in.
  • Page 59 8. The Event Only and Condensed selection boxes are not selectable for alarm trend files. 9. To view the data in graph format, click the Graph button. An alarm trend file can always be graphed regardless of the number of logged points. Cursor feature Catalytic combustible channel reading units Zoom level...
  • Page 60 recorded in any of these units and stored in the same file, those readings may only be graphed in one unit at a time. If %LEL is chosen as the unit, any ppm or %volume data is converted and graphed as %LEL. The user may change back and forth between the units for the graph and still have all data shown.
  • Page 61 range of the sensor. If the channel is configured as a %LEL only channel, then data will only be recorded in %LEL and the range will be 0-100% LEL. Any gas concentration above that level will not be recorded. If the channel is configured as a %LEL/% volume autoranging channel, then data will be recorded in %LEL and % volume where appropriate.
  • Page 62 Cursor feature IR HC or CH4 channel units Catalytic combustible channel reading units Zoom level Figure 42: Alarm Trend Data in Graph Format NOTE: The IR Range Select selection box in the lower right hand corner only appears if an IR HC or CH sensor is installed, is in use, and is set up for autoranging.
  • Page 63 • When selected, the Event feature shows on the graph where each channel went into and out of alarm and at what concentration each event occurred. • When selected, the Cursor feature allows you to display the gas reading and log time for each data point in the alarm trend file.

  • Page 64: Deleting Data In The Data Window

    12.To export the data for use in another application, for example a spreadsheet or database (for table data) or a word processing or presentation program (for graph data), click the Export button. A “Save As” dialog box will appear for you to specify the filename, file location, and file type.
  • Page 65 • Interval Trend and Alarm Trend data files To delete any of the above items in the Data Window: 1. With the program launched, click the Data control button on the right side of the program window. 2. Find the folder or file you want to delete. 3.
  • Page 66 “rki”. The password is case sensitive. See “Changing the Password” on page 63 for instructions to change the password if desired. 6. When the password has been entered and Continue clicked, the Delete Data Window (if a folder is selected for...

  • Page 67: Changing The Password

    Changing the Password CAUTION: Changing the password requires use of the Delete box. Take care to avoid accidentally deleting data if you decide to change the password. It is possible to change that password as follows: 1. Right-click a data folder, data file, or event file. The Delete box will appear.
  • Page 68 3. Click Change Password. The Password Window asks you to input the current password. Figure 50: Inputting Current Password 4. Type the current password, then click Current password. The Password Window asks you to input the new password. Figure 51: Inputting New Password 5.
  • Page 69 7. Click OK when the program confirms that you have changed the password. Figure 53: Confirming New Password 8. Close the Password Window by clicking the red “X” in the upper right corner of the window. Viewing, Printing, Exporting, and Deleting Data in the Data Window • 65...

  • Page 70: Viewing, Printing, & Deleting Data In The Last Calibration Window

    NOTE: The calibration interval, the number of days after a calibration that a new calibration is due, is saved in the Eagle 2. If the calibration interval is changed in the Eagle 2, the new calibration interval will not be known by the program until the Eagle 2 is downloaded.
  • Page 71 • SerialNo — shows the serial number of the Eagle 2 that was downloaded. • UserID — shows the user ID of the Eagle 2 that was downloaded. • StationID — shows the station ID of the unit that was downloaded.
  • Page 72 • Last Downloaded — shows when the last download took place for a unit using the MM/DD/YY format and a 12-hour clock. This parameter is displayed on the second display line for each unit downloaded. The Eagle 2s that are due for calibration (in the case of the Need Calibration view option, that will be all of them), will have their last calibration date highlighted in red.
  • Page 73 Calibration Record View Option Selecting the Calibration Record view option shows detailed calibration information for each Eagle 2’s most recent successful calibration. Figure 58: Last Calibration Window: Calibration Record View Option The fields on this screen include No., SerialNo, UserID, and StationID just as in the Need Calibration and Calibration Date screens.

  • Page 74: Deleting Last Calibration Data

    • After — shows the settings after calibration. • A. Cal. — lists the auto-calibration setting for each channel of the Eagle 2. If a Eagle 2 passes its calibration, the “After” column should match the “A. Cal.” column. If the Eagle 2 fails calibration on any of its channels, those channels will retain the previous calibration information.
  • Page 75 Figure 60: Password Window, Deleting Last Calibration Data 6. Enter the password and click the Continue button. The password when the software is first installed is “rki”. The password is case sensitive. See “Changing the Password” on page 63 for instructions to change the password if desired.
  • Page 76 7. When the password has been entered and the Continue button clicked, the Delete History window will appear asking you to confirm that you want to delete the most recent calibration information for the selected instrument. Figure 61: Delete History Window 8.

  • Page 77: Calibrating An Eagle 2 With The Data Logging Software

    PID, ESM-01, IR, or TC sensors. • A demand-flow regulator to provide adequate sample gas flow. • Non-absorbent tubing to connect the regulator to the Eagle 2’s probe tube. Calibrating an Eagle 2 With The Eagle 2 Data Logger Management Program • 73...
  • Page 78 Instrument Information download command to retrieve the instrument information from the Eagle 2. If you wish to download data before calibrating, click Complete Download instead of Instrument Information. 74 • Calibrating an Eagle 2 With The Eagle 2 Data Logger Management Pro-...
  • Page 79 Eagle 2’s pump will turn on. The Calibration frame will replace the Eagle 2 Status frame and the control buttons along the right side of the window will become inactive. Calibrating an Eagle 2 With The Eagle 2 Data Logger Management Program • 75...
  • Page 80 If not, place the cursor in the field that needs to be changed and update the value. 12.Screw the demand flow regulator onto the calibration cylinder. 76 • Calibrating an Eagle 2 With The Eagle 2 Data Logger Management Pro-...

  • Page 81: Changing Eagle 2 Instrument Parameters

    20.If you wish to exit the software, click the Download button to return to the Download window. Turn off the Eagle 2 by using the POWER ENTER RESET button on the Eagle 2 or by clicking the Power Off button and confirming that you want to turn off the Eagle 2 when the Power Off window appears.
  • Page 82 The oxygen alarm settings shown in green at the bottom of the Gas/Sensor Frame are for Inert Mode. Inert Mode must be activated in the Eagle 2 for this alarm setting to appear. Alarm setting changes made to the Inert Mode oxygen alarms will not affect the Normal Mode oxygen alarms.
  • Page 83 9. After you have finished entering new parameters, you must upload this information to the Eagle 2 by clicking the Update button, then confirming that you want to update the information by clicking the Yes button when the Update window appears.

  • Page 84: Detail Settings Button

    2 by using the POWER ENTER RESET button on the Eagle 2 or by clicking the Power Off button and confirming that you want to turn off the Eagle 2 when the Power Off Window appears. Then click the Exit button to exit the software.
  • Page 85 of Instrument Information. 5. Click the Set button to display the Set window. Figure 66: Set Window Detail Settings Button • 81...

  • Page 86: Station & User Tab

    Station & User Tab The Station & User tab displays a list of Station IDs and User IDs. The first time the Eagle 2 is connected to the Eagle 2 Data Logger Management Program, this list will be blank. No Station IDs or User IDs are loaded into the Eagle 2 at the factory.
  • Page 87 CSV Files To edit the Station ID or User ID list, you will need to import a csv (comma separated values) file into the program. A Station csv file and a User csv file are provided with the program. In addition, you can generate csv files for editing from the program.
  • Page 88 2. Navigate to the location you would like to save the csv file, type in a file name, and click Save. Figure 69: Station csv File Save As 84 • Detail Settings Button...
  • Page 89 3. The csv files can be opened, edited, and saved using a word processing program such as Word, WordPad, or Notepad. The Station and User csv files consist of the Station or User ID number and its associated name. Below is an example of a Station csv file opened in WordPad.
  • Page 90 2. In the Station and User tab, click “Import csv file” for either the Station ID or User ID and select a csv file. Click to import User csv file Click to import Station csv file Figure 71: Import csv File 86 •...
  • Page 91 ID for the instrument. 6. To upload the new information from the Data Logger Management Program to the Eagle 2, click the Update button in the Set window. Detail Settings Button • 87...

  • Page 92: Conversion Table Tab

    7. Click Yes in the confirmation window that appears. Figure 73: Update Confirmation Window Conversion Table Tab The Conversion Table tab is used to view the pre-defined relative response gases for the catalytic combustible channel and to edit or add user-defined gases. The pre-defined gases can be found in the Pre-Defined Table tab while the user-defined gases can be found under the User-Defined Table tab.
  • Page 93 There are 8 columns in both the Pre-Defined Table tab and the User-Defined Table tab: • No This column represents the gas number. The gas numbers are 1-30. • Name This is what will appear in the Relative Response list of gases.
  • Page 94 NOTE: If you define a gas whose LEL is above 50,000 ppm, the %LEL reading in Measuring Mode will reflect the defined ppm ratio, but the ppm reading in Measuring Mode will not indicate above 50,000 ppm. For example, if you set the ratio to be 150,000 ppm and set the catalytic combustible channel to display the reading in ppm, the gas reading will not indicate higher than 50,000 ppm, the equivalent of 33 %LEL and 5% volume...
  • Page 95 While the pre-defined gases may not be edited, the 5 user- defined gases may be edited by doing the following: 1. With the Data Logger Management Program running, click the Set button to display the Set window. Click the Detail Settings button to display the Detail Settings window.
  • Page 96 4. Open the csv file using Notepad, Word, or WordPad. The example below shows a csv file opened in WordPad. The list of gases are associated with the numbers 1-5. Figure 76: CSV File If there were no previously defined gases, the csv file will appear as the following: Figure 77: Blank CSV File 5.
  • Page 97 If you do not want to save the changes, click Cancel. 12.To upload the new information from the Data Logger Management Program to the Eagle 2, click the Update button in the Set window. 13.Click Yes in the confirmation window that appears.

  • Page 98: Pid Sensor Tab

    PID Sensor Tab The PID Sensor tab is used to view the pre-defined relative response gases and to view or define the 1 user-defined relative response gas. Every gas has a low and high range which are displayed in the Low Range tab and High Range tab, respectively.
  • Page 99 • Full Scale This is the full scale value for the target gas. • Point The point value indicates to what decimal place the gas readings are shown. A value of 1/1 indicates a reading to the “ones” place while a value of 1/100 indicates a reading to the “hundredths”...
  • Page 100 from Table 5 on page 102 or through testing as described in “Obtaining a Relative Response Factor” on page 101. A valid character for the Factor is a value between 0.01 and 25.00. There are limitations for the full scale and increment values that depend on the factor for both the high range and the low range.
  • Page 101 Table 3: Low Range PID Full Scale Factor Increment (ppm) 0.50-0.59 25.00 0.01 0.60-0.79 30.00 0.02 0.80-0.99 40.00 0.02 1.00-1.99 50.00 0.02 2.00-2.99 100.0 3.00-3.99 150.0 4.00-5.99 200.0 6.00-7.99 300.0 8.00-9.99 400.0 10.00 500.0 Detail Settings Button • 97...
  • Page 102 While the pre-defined gases may not be edited, the 1 user- defined gas may be edited by doing the following: 1. With Data Logger Management Program running, click on the Set button to display the Set window. Click the Detail Settings button to display the Detail Settings window.
  • Page 103 3. Export the current data by pressing the “Export csv file” button. Choose the file path you wish to save the file in. Figure 81: Save As 4. Open the csv file using Notepad, Word, or WordPad. The example below shows a csv file opened in WordPad. The user defined PID gas is number 17.
  • Page 104 If you do not want to save the changes, click Cancel. 13.To upload the new information from the Data Logger Management Program to the Eagle 2, click the Update button in the Set window. 14.Click Yes in the confirmation window that appears.

  • Page 105: Obtaining A Relative Response Factor

    50% of the full scale. If the concentration tested results in an overscale reading, test a lower concentration. 3. Apply the gas sample to the EAGLE 2 and take note of the reading. If the gas sample is of 50 %LEL concentration and the EAGLE 2 display shows a reading of 25 %LEL, then the factor for that gas is 2.
  • Page 106 • Formula-Molecular formula for each VOC • Response Factor (RF)-The relative response factor for each gas. This is the value that is plugged into the Eagle 2 Maintenance Data Loader Program. Some abbreviations that appear in the table are: •...
  • Page 107 Gas/ VOC CAS No. Formula Relative Response Biphenyl 92-52-4 C12H10 Bis(2,3-epoxypropyl) ether 7/5/38 C6H10O3 Boron trifluoride 7637 07 2 Bromine 7726-95-6 Bromine pentafluoride 7789-30-2 BrF5 Bromobenzene 108-86-1 C6H5Br Bromochloromethane 74-97-5 CH2ClBr Bromoethane 74-96-4 C2H5Br Bromoethyl methyl ether, 2- 6482-24-2 C3H7OBr Bromoform 75-25-2 CHBr3...
  • Page 108 Gas/ VOC CAS No. Formula Relative Response Chloro-1,3-butadiene, 2- 126-99-8 C4H5Cl Chloro-1-fluoroethane, 1- 1615-75-4 C2H4ClF Chloro-2-fluoroethane, 1- 762-50-5 C2H4ClF Chloroacetaldehyde 107-20-0 C2H3OCl Chlorobenzene 108-90-7 C6H5Cl Chlorodifluoromethane 75-45-6 CHClF2 Chloroethane 75-00-3 C2H5Cl Chloroethanol 2- 107-07-3 C2H5ClO Chloroethyl methyl ether, 2- 627-42-9 C3H7ClO Chlorofluoromethane 593-70-4...
  • Page 109 Gas/ VOC CAS No. Formula Relative Response Dichloro-1,1-difluoroethane, 1649-08-7 C2H2Cl2F2 1,2- Dichloro-1,2,2-trifluoroethane, 354-23-4 C2HCl2F3 1,2- Dichloro-1,2-difluoroethane, 631-06-1 C2H2Cl2F2 1,2- Dichloro-1-fluoroethane, 1,1- 1717-00-6 C2H3Cl2F Dichloro-1-fluoroethane, 1,1- 1717-00-6 C2H3Cl2F Dichloro-1-fluoroethane, 1,2- 430-57-9 C2H3Cl2F Dichloro-1-propene, 2,3- 78-88-6 C3H4Cl2 Dichloro-2,2,-difluoroethane, 79-35-6 C2H2Cl2F2 1,1- Dichloroacetylene 7572-29-4 C2Cl2 Dichlorobenzene o-...
  • Page 110 Gas/ VOC CAS No. Formula Relative Response Dimethyl cyclohexane, 1,2- 583-57-3 C8H16 Dimethyl disulphide 624-92-0 C2H6S2 Dimethyl ether 115-10-6 C2H6O Dimethyl phthalate 131-11-3 C10H10O4 Dimethyl sulphate 77-78-1 C2H6O4S Dimethyl sulphide 75-18-3 C2H6S Dimethylacetamide N,N- 127-19-5 C4H9NO Dimethylamine 124-40-3 C2H7N Dimethylaminoethanol 108-01-0 C4H11NO Dimethylaniline, NN-...
  • Page 111 Gas/ VOC CAS No. Formula Relative Response Ethyl hexanoate 123-66-0 C8H16O2 Ethyl hexanol, 2- 105-76-7 C8H18O Ethyl hexyl acrylate, 2- 103-11-7 C11H20O2 Ethyl mercaptan 75-08-1 C2H6S Ethyl octanoate 106-32-1 C10H20O2 Ethylene 74-85-1 C2H4 Ethylene dinitrate 628-96-6 C2H4O6N2 Ethylene glycol 107-21-1 C2H6O2 Ethylene oxide 75-21-8...
  • Page 112 Gas/ VOC CAS No. Formula Relative Response Hydroquinone 123-31-9 C6H6O2 Hydroxypropyl acrylate 2- 999-61-1 C6H10O3 Iminodi(ethylamine) 2,2- 111-40-0 C4H13N3 Iminodiethanol 2,2'- 111-42-2 C4H11NO2 Indene 95-13-6 C9H8 Iodine 7553-56-2 Iodoform 75-47-8 CHI3 Iodomethane 74-88-4 CH3I Isoamyl acetate 123-92-2 C7H14O2 Isobutane 75-28-5 C4H10 Isobutanol 78-83-1...
  • Page 113 Gas/ VOC CAS No. Formula Relative Response Methoxypropyl acetate 108-65-6 C6H12O3 Methyl acetate 79-20-9 C3H6O2 Methyl acrylate 96-33-3 C4H6O2 Methyl bromide 74-83-9 CH3Br Methyl cyanoacrylate 137-05-3 C5H5O2N Methyl ethyl ketone 78-93-3 C4H8O Methyl ethyl ketone peroxides 1338-23-4 C8H18O2 Methyl formate 107-31-3 C2H4O2 Methyl isobutyl ketone...
  • Page 114 Gas/ VOC CAS No. Formula Relative Response Nitropropane, 2- 79-46-9 C3H7NO2 Nitrous oxide 10024-97-2 Nonane, n- 111-84-2 C9H20 Norbornadiene, 2,5- 121-46-0 C7H8 Octachloronaphthalene 2234-13-1 C10Cl8 Octane, n- 111-65-9 C8H18 Octene, 1- 111-66-0 C8H16 Oxalic acid 144-62-7 C2H2O4 Oxalonitrile 460-19-5 C2N2 Oxydiethanol 2,2- 111-46-6 C4H10O3...
  • Page 115 Gas/ VOC CAS No. Formula Relative Response Propylene oxide 75-56-9 C3H6O Propyleneimine 75-55-8 C3H7N Pyridine 110-86-1 C5H5N Pyridylamine 2- 504-29-0 C5H6N2 Silane 7803-62-5 SiH4 C2H2O2FNa Sodium fluoroacetate 62-74-8 Styrene 100-42-5 C8H8 Sulphur dioxide 9/5/46 Sulphur hexafluoride 2551-62-4 Sulphur tetrafluoride 7783-60-0 Sulphuric acid 7664-93-9 H2SO4...
  • Page 116 Gas/ VOC CAS No. Formula Relative Response Tributylamine 102-82-9 C12H27N Trichloro-1,1-difluoroethane, 354-21-2 C2HCl3F2 1,2,2- Trichloro-1,2-difluoroethane, 354-15-4 C2HCl3F2 1,1,2- Trichloro-2,2-difluoroethane, 354-12-1 C2HCl3F2 1,1,1- Trichloro-2-fluoroethane, 359-28-4 C2H2Cl3F 1,1,2- Trichlorobenzene 1,2,4- 120-82-1 C6H3Cl3 Trichloroethane, 1,1,1- 71-55-6 C2H3Cl3 Trichloroethane, 1,1,2- 79-00-5 C2H3Cl3 Trichloroethylene 79-01-6 C2HCl3 Trichlorofluoromethane 75-69-4...

  • Page 117: Changing The Appearance Of The Program Screens

    Set Window. Follow the steps below to make changes. 1. Launch the Eagle 2 Data Logger Management Program. 2. Click the Set button to display the Set window. Use the Font And Color Frame in the left side of the window to change fonts and graph colors.
  • Page 118 3. Specify new fonts by clicking the button with the name of a font inscribed on it. This action will display the Font Window. Choose the font type, style, size, and script, then click OK. Figure 85: Font Window 114 • Changing the Appearance of the Program Screens...
  • Page 119 Graph Color button on the left side of the Set Window in the Font and Color frame. The six Graph Color buttons correspond to the 6 possible Eagle 2 channels. From top to bottom, they correspond to channels 1-6.

  • Page 120: Spare Parts List

    71-0170RK Eagle 2 Data Logger Management Program Operator’s Manual (this document) 71-8003RK Eagle 2 Product CD, Includes the Eagle 2 Data Logger Management Program, the Eagle 2 Maintenance Pro- gram, and Operator’s Manuals for each 116 • Spare Parts List...
