Your new Sander has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. When properly cared for, the sheet sander will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual.
WARNING: The operation of any sander can result in foreign objects being thrown into your eyes, which can result in severe eye damage. Before beginning power tool operation, always wear safety goggles or safety glasses with side shields and a full face shield when needed. We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shields.
WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in elec- tric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work Area ■ Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. ■...
■ Keep the tool and its handle dry, clean, and free from oil and grease. Always use a clean cloth when clean- Additional Rules for Safe Operation ■ Know your power tool. Read operator's manual care- fully. Learn its applications and limitations as well as the specific potential hazards related to this tool.
Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Minutes Alternating Current Direct Current No Load Speed...
"OFF". SWITCH PAPER PUNCH WARNING: Do not allow familiarity with your sander to make you careless. Remember, a careless fraction of a second is sufficient to inflict severe injury. FEATURES ELECTRICAL CONNECTION Your sander has a precision built electric motor. It should be connected to a power supply that is 120 volts, 60 Hz, AC only (normal household current).
1/4 Sheet Orbital Sander Sandpaper (3 sheets) Conversion Pad Operator’s Manual WARNING: If any parts are missing, do not operate your sander until the missing parts are replaced. Failure to do so could result in possible serious personal injury. APPLICATIONS Page 7...
The punched holes must align with the holes in the sander cushion. 1. Install sandpaper on your sander. 2. Align sander cushion over the paper punch. See Figure 3. 3. Push down on sander. Page 8...
Unsecured work could be thrown towards the operator causing injury. Hold your sander in front and away from you, keeping it clear of the workpiece. Start your sander by pressing the switch button to "ON" position and letting the motor build to its maximum speed.
DUSTLESS SANDING The dust bag located on the rear of your sander provides a dust collection system for your sander. Sanding dust is drawn up through the holes of the cushion and collects in the dust bag during sanding operation.
WARNING: When servicing use only identical Ryobi replacement parts. Use of any other parts may create a hazard or cause product damage. GENERAL Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to various types of commercial solvents and may be damaged by their use.
Ryobi Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-800-525-2579 for your nearest Ryobi Authorized Service Center. You can also check our web site at www.ryobitools.com for a complete list of Authorized Service Centers.
