Ryobi CFS1503K Operator's Manual

5-1/2 in. corner cat compact finish sander double in
Hide thumbs Also See for CFS1503K:
Table of Contents

Advertisement

Quick Links

Your finish sander has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
5-1/2 in. CORNER CAT
COMPACT FINISH SANDER
DOUbLE INSULATED
CFS1503
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFS1503K and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi CFS1503K

Summary of Contents for Ryobi CFS1503K

  • Page 1 Your finish sander has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.

  • Page 2: Table Of Contents

    WHAT THIS WARRANTy COVERS: This warranty covers all defects in workmanship or materials in your RYOBI tool for a period of two years from the date of purchase. With the exception of batteries, power tool accessories are warranted for ninety (90) days.

  • Page 3: General Safety Rules

    WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warn- ings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. SAVE THESE INSTRUCTIONS WORk AREA SAFETy  keep work area clean and well lit.

  • Page 4: General Safety Rules

    SERVICE  Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. WARNING! To reduce the risk of injury, user must read instruction manual.

  • Page 5: Symbols

    Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SyMbOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current No Load Speed...

  • Page 6: Symbols

    To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand com- pletely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance.

  • Page 7: Double Insulation

    DOUbLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three- wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded.

  • Page 8: Features

    Before use of this product, familiarize yourself with all operating features and safety rules. CIRCULAR SANDING ACTION The oscillating action of the sander produces very quick, small circular motion of the sanding pad. The motion is ideal for producing a fine finished grain or, when using the scrubbing pad, removing light rust, paint, and other buildup from the work surface.

  • Page 9: Assembly

     If any parts are damaged or missing, please call 1-800-55-579 for assistance. PACkING LIST 5-1/ in. Corner Cat Compact Finish Sander ® 60-grit Sanding Sheet () 10-grit Sanding Sheet (3) 40-grit Sanding Sheet ()

  • Page 10: Attaching The Dust Bag

    TURNING THE SANDER ON/OFF See Figure 4. While holding the tool in normal operating position:  Push the ON/OFF switch to the left to turn sander on.  Push the ON/OFF switch to the right to turn sander off. OPERATION...

  • Page 11: Operating The Sander

    WARNING: Keep your head away from the sander and sanding area. Hair could be drawn into sander causing serious injury.  Hold the sander in front and away from you, keeping it clear of the workpiece. CAUTION: To avoid motor damage resulting from overheating, do not cover the air vents with your hand.

  • Page 12: Emptying The Dust Bag

    Collected dust from sanding surface coatings such as polyurethanes, linseed oil, etc. can self-ignite in the sander dust bag or elsewhere and cause fire. To reduce the risk of fire, empty the dust bag every 10-15 minutes while sanding. Never store or leave a sander without totally emptying its dust bag.

  • Page 13: General Maintenance

    Always store pads and sanding sheets flat in a cool, dry location. CLEANING THE SANDING SHEETS The sanding sheets that came with the sander are made to be re-used. Therefore, it is important that they be cleaned periodically to remove sanding residue and foreign material that can accumulate over time.
  • Page 14 1-800-55-579. • HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-55-579. RYOBI is a registered trademark of Ryobi Limited used under license. ® 987000-149 06-18-07 (REV:01) OPERATOR’S MANUAL 5-1/2 in. CORNER CAT...
