MODEL HP62
THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER.
Your new cordless drill-driver has been engineered and manufactured to Ryobi's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new cordless drill-driver.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your cordless drill-driver properly
and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
CORDLESS DRILL-DRIVER
MODEL NOS. HP62 / HP722
MODEL HP722

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP62 and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi HP62

Summary of Contents for Ryobi HP62

  • Page 1 THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER. Your new cordless drill-driver has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Use battery only with charger listed. MODEL BATTERY HP62 HP722 1311145 ■ Use battery operated tool only with specifically designated battery pack. Use of any other batteries may create a risk of fire.

  • Page 3: General Safety Rule

    Tool Use and Care ■ Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control. ■ Do not force tool. Use the correct tool for your appli- cation.
  • Page 4 SPECIFIC SAFETY RULES AND/OR SYMBOLS Important Safety Instructions For Charger ■ Save these instructions. This manual contains im- portant safety and operating instructions for charger. Following this rule will reduce the risk of electric shock, fire, or serious personal injury. ■...

  • Page 5: Features

    SYMBOLS SYMBOL NAME Volts Amperes Hertz Minutes Alternating Current Direct Current No Load Speed .../min Revolutions or Reciprocation Per Minute Safety Alert Symbol DANGER: Failure to obey a safety warning will result in serious injury to yourself or to others. Always follow the safety precautions to reduce the risk of fire, electric shock and personal injury.
  • Page 6 TWO SPEED SWITCH Your drill has a two speed feature in the switch. Depress the switch trigger halfway for driving screws at a low speed. Depress the switch trigger all the way for normal drilling.
  • Page 7 LEVEL TORQUE ADJUSTMENT RING SWITCH KEYLESS TRIGGER CHUCK MODEL HP722 LEVEL TORQUE ADJUSTMENT RING SWITCH TRIGGER KEYLESS CHUCK MODEL HP62 DIRECTION OF ROTATION SELECTOR DIRECTION OF ROTATION SELECTOR BATTERY PACK Page 7 STORAGE AREA Fig. 1 STORAGE AREA Fig. 1a...

  • Page 8: Operation

    If you have drill Model HP62, return charger to service center. ■ After normal usage, 3 hours or less of charging time is required to fully recharge battery pack. Note: If battery...

  • Page 9: Switch Lock

    ■ Place the direction of rotation selector in center posi- See Figure 4. tion. ■ Place the battery pack in your drill. Align raised rib on bat- tery pack with groove in drill's battery port. ■ Make sure the latches on each side of your battery pack snap in place and that battery pack is secured in drill before beginning operation.
  • Page 10 KEYLESS CHUCK See Figure 7. A keyless chuck has been provided with your drill to allow for easy installation and removal of bits. As the name implies, you can hand tighten or release drill bits in the chuck jaws.

  • Page 11: Installing Bits

    Also, raise the front of your drill slightly to keep the bit from falling out of the chuck jaws. ■ Insert your drill bit into the chuck the full length of the See Figure 8. jaws.
  • Page 12 LEVEL DRILLING See Figure 12. A convenient new feature provided with your drill is a level. It is recessed in the motor housing on top of your drill. It can be used to keep drill bit level during drilling operations. OPERATION...
  • Page 13 When drilling metals, use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action.

  • Page 14: Chuck Removal

    ■ Insert a 5/16 inch or larger hex key wrench into the chuck of your drill and tighten the chuck jaws securely. ■ Tap the hex key wrench sharply with a mallet in a See Figure 14.

  • Page 15: Maintenance

    BATTERIES Your drill is equipped with Nickel-Cadmium rechargeable batteries. Length of service from each charging will depend on the type of work you are doing. The batteries in this tool have been designed to provide maximum trouble-free life. However, like all batteries, they will eventually wear out.

  • Page 16: Battery Removal

    ■ Lock switch trigger by placing the forward/reverse switch See Figure 4. in center position. ■ Remove battery cover from bottom of drill handle by depressing and pushing cover in the direction of the arrow as shown in figure 17.
  • Page 17 NOTES Page 17...

  • Page 18: Parts Ordering / Service

    OPERATOR'S MANUAL CORDLESS DRILL-DRIVER MODEL NOS. HP62 / HP722 • SERVICE Now that you have purchased your tool, should a need ever exist for repair parts or service, simply contact your nearest Authorized Service Center. Be sure to provide all pertinent facts when you call or visit.
