Ryobi cordless drill-driver models hp1442m and hp1802m operator's manual
Hide thumbs

Advertisement

Table of Contents

MODEL HP1442M
THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER.
Your new cordless drill-driver has been engineered and manufactured to Ryobi's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new cordless drill-driver.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your cordless drill-driver properly
and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
CORDLESS DRILL-DRIVER
MODEL NOS. HP1442M / HP1802M
MODEL HP1802M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP1442M and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi HP1442M

Summary of Contents for Ryobi HP1442M

  • Page 1 THANK YOU FOR BUYING A RYOBI CORDLESS DRILL-DRIVER. Your new cordless drill-driver has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Use battery only with charger listed. MODEL BATTERY HP1442M 1314702 HP1802M 1322401 / 1323303 ■ Use battery operated tool only with specifically designated battery pack.

  • Page 3: General Safety Rule

    Tool Use and Care Use clamps or other practical way to secure and support the workpiece to a stable platform. Holding the work by hand or against your body is unstable and may lead to loss of control. Do not force tool. Use the correct tool for your appli- cation.
  • Page 4 SPECIFIC SAFETY RULES AND/OR SYMBOLS WARNING: A damaged battery is subject to explosion. To avoid serious personal injury, properly dispose of a damaged battery. Important Safety Instructions For Charger Save these instructions. This manual contains im- portant safety and operating instructions for charger. Following this rule will reduce the risk of electric shock, fire, or serious personal injury.
  • Page 5 SYMBOLS SYMBOL NAME Volts Amperes Hertz Minutes Alternating Current Direct Current No Load Speed .../min Revolutions or Reciprocation Per Minute Safety Alert Symbol The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding.

  • Page 6: Features

    Your drill has a two-speed gear train designed for drilling or driving at LO (1) or HI (2) speeds. A slide switch is located on top of your drill to select either LO (1) or HI (2) speed. FORWARD/REVERSE SELECTOR...
  • Page 7 HORIZONTAL DRILLING TWO SPEED GEAR TRAIN (HI-LO) TORQUE ADJUSTMENT RING KEYLESS CHUCK MAG TRAY™ (SCREW HOLDER) TOP VIEW OF LEVEL FOR HORIZONTAL DRILLING FEATURES MODEL HP1442M SWITCH TRIGGER MODEL HP1802M SWITCH TRIGGER Page 7 LEVEL STORAGE AREA DIRECTION OF ROTATION SELECTOR...

  • Page 8: Operation

    Your Drill-Driver" for normal recharging of batteries. If the charger/charging assembly does not charge your battery pack under normal circumstances, return both the battery pack and charger/charging assembly to your nearest Ryobi Authorized Service Center for electrical check. Page 8...
  • Page 9 Your drill has a two-speed gear train designed for drilling or driving at LO (1) or HI (2) speeds. A slide switch is located on top of your drill to select either LO (1) or HI (2) speed. When using drill in the LO (1) speed range, speed will decrease and unit will have more power and torque.
  • Page 10 KEYLESS CHUCK See Figure 6. A keyless chuck has been provided with your drill to allow for easy installation and removal of bits. As the name implies, you can hand tighten or release drill bits in the chuck jaws. Grasp and hold the collar of the chuck with one hand. Rotate the chuck body with your other hand.
  • Page 11 Insert your drill bit into the chuck the full length of the jaws. See Figure 8. Tighten the chuck jaws on the drill bit. To tighten, grasp and hold the collar of the chuck with one hand, while rotating the chuck body with your other hand.
  • Page 12 BIT STORAGE See Figure 12. When not in use, bits provided with your drill can be placed in the storage area located on the top of your drill as shown in figure 12. LEVEL DRILLING See Figures 13 and 14.
  • Page 13 When drilling metals, use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action.

  • Page 14: Operation

    See Figure 4. Insert a 5/16 inch or larger hex key wrench into the chuck of your drill and tighten the chuck jaws securely. Tap the hex key wrench sharply with a mallet in a clockwise direction. See Figure 15. This will loosen the screw in the chuck for easy removal.

  • Page 15: Maintenance

    Any repairs requiring disassembly should only be performed by a Ryobi Authorized Service Center. For the repair center nearest you, call 1-800-525-2579. Store and charge your batteries in a cool area. Temperatures above or below normal room temperature will shorten battery life.

  • Page 16: Parts Ordering / Service

    Ryobi Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-800-525-2579 for your nearest Ryobi Authorized Service Center. You can also check our web site at www.ryobitools.com for a complete list of Authorized Service Centers.
