OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
3/8 in. DRILL
PERCEUSE 10 mm (3/8 po)
TALADRO DE 10 mm (3/8 pulg.)
D46C
Your drill has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Votre perceuse été conçue et fabriquée conformément à nos strictes
normes de fiabilité, simplicité d'emploi et sécurité d'utilisation.
Correctement entretenue, elle vous donnera des années de
fonctionnement robuste et sans problème.
AVERTISSEMENT :
blessures, l'utilisateur doit lire et veiller à bien comprendre le
manuel d'utilisation avant d'employer ce produit.
Merci de votre achat.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Pour réduire les risques de
Su taladro ha sido diseñada y fabricada de conformidad con las
estrictas normas para brindar fiabilidad, facilidad de uso y seguridad
para el operador. Con el debido cuidado, le brindará muchos años
de sólido y eficiente funcionamiento.
ADVERTENCIA:
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
Para reducir el riesgo de lesiones,
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ryobi D46CK
Summary of Contents for Ryobi D46CK
- Page 1 TALADRO DE 10 mm (3/8 pulg.) D46C Your drill has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using...
-
Page 2: Table Of Contents
The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®... -
Page 3: General Safety Rules
WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. -
Page 4: Specific Safety Rules
SERVICE Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel may result in a risk of injury. Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. -
Page 5: Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME Volts Amperes Hertz Watt Minutes Alternating Current Direct Current No Load Speed... -
Page 6: Symbols
To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand com- pletely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. − English... -
Page 7: Electrical
DOUBLE INSULATION Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three- wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded. -
Page 8: Features
Before use of this product, familiarize yourself with all operating features and safety rules. BIT STORAGE Bits provided with the drill can be placed in the storage area, located on the top of the drill. DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE) -
Page 9: Assembly
OPERATION SWITCH TRIGGER See Figure 2. To turn the drill ON, depress the switch trigger. To turn it OFF, release the switch trigger. VARIABLE SPEED The variable speed switch delivers higher speed and torque with increased trigger pressure and lower speed with decreased trigger pressure. -
Page 10: Installing Bits
Open or close the chuck jaws to a point where the open- ing is slightly larger than the bit size you intend to use. Also, raise the front of the drill slightly to keep the bit from falling out of the chuck jaws. -
Page 11: Removing Bits
Make sure to insert the drill bit straight into the chuck jaws. Do not insert the drill bit into the an angle then tighten, as shown infigure 6. cause the drill bit to be thrown from the drill, resulting in possible serious personal injury or damage to the chuck. -
Page 12: Operation
This will prevent the drill bit from slipping off-center as the hole is started. When drilling metals, use a light oil on the drill bit to keep it from overheating. The oil will prolong the life of the bit and increase the drilling action. -
Page 13: Maintenance
WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If operation is dusty, also wear a dust mask. GENERAL MAINTENANCE Avoid using solvents when cleaning plastic parts. -
Page 14: Chuck Removal
Unplug the drill. Insert a 5/16 in. or larger hex key into the chuck of the drill and tighten the chuck jaws securely. Tap the hex key sharply with a mallet in a clockwise di- rection. This will loosen the screw in the chuck for easy removal. - Page 15 NOTES 1 − English...
- Page 16 Para obtener Servicio o Asistencia Técnica al Consumidor, sírvase comunicarse con nosotros llamando al 1-800-525-2579. Ryobi es una marca comercial registrada de Ryobi Limited y es empleada mediante autorización. ® 1428 Pearman Dairy Road, Anderson, SC 29625 • Phone 1-800-525-2579 États-Unis, Téléphone 1-800-525-2579 •...
