Your cultivator has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
CULTIVATOR
RY60512

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RY60512 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ryobi RY60512

Summary of Contents for Ryobi RY60512

  • Page 1 Your cultivator has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.

  • Page 2: Table Of Contents

     Introduction ... 2  General Safety Rules ... 3  Specific Safety Rules ... 4  Symbols ... 5-6  Features ... 7  Assembly ... 8-11  Operation ... 11-13  Adjustments ... 14  Maintenance ... 15-17 ...

  • Page 3: General Safety Rules

    Wear protective footwear that will protect your feet and improve your footing on slippery surfaces.  Do not operate the cultivator while under the influence of alcohol or drugs.  Do not put hands or feet near or under tines.

  • Page 4: Specific Safety Rules

     Start the engine carefully according to instructions from a normal operating position and with feet well away from the tines. Do not force cultivator. It will do the job better and with less likelihood of a risk of injury at the rate for which it was designed.

  • Page 5: Symbols

    Some of the following symbols may be used on this product. Please study them and learn their meaning for safe operation of this product. SYMBOL Read the Operator’s Manual Wear Eye and Hearing Protection Safety Alert Keep Bystanders Away Cutting Hazard Gasoline and Oil SYMBOLS NAME...
  • Page 6 To avoid serious personal injury, do not attempt to use this product until you read thoroughly and understand com- pletely the operator’s manual. If you do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance.

  • Page 7: Features

    OFF ( O ) position. JUST ADD SAND ™ Putting sand in the sand tank allows greater stability when oper- ating the cultivator, and also gives added weight to the machine, allowing it to cultivate with less effort and vibration. FEATURES RECOIL...

  • Page 8: Packing List

    Pull Pin Hitch Pins (2) Felt Washers (2) Inner Tines (2) Outer Tines (2) Ryobi Exact Mix 2-Cycle Oil Wheel Assembly (Accessory) Operator’s Manual WARNING: If any parts are damaged or missing do not operate this product until the parts are replaced. Failure to heed this warning could result in serious personal injury.

  • Page 9: Installing The Tines

    INSTALLING THE TINES See Figure 5. The cultivator has four tines —two inner tines labeled B and C, and two outer tines labeled A and D. For correct opera- tion of the unit, the tines must be installed in the correct orientation.

  • Page 10: Mixing The Fuel

    The cultivator is powered by a two-stroke, air-cooled engine and requires a fuel mixture of gasoline and 2-cycle fuel oil. NOTE: Always mix two-cycle engine oil like Ryobi’s Exact Mix Semi Synthetic Oil with gasoline before fueling the unit. Run- ning the cultivator on gasoline alone will ruin the engine.

  • Page 11: Operation

    ADDING SAND See Figure 8. The cultivator is equipped with a Just Add Sand system, which improves the stability of the unit during op- eration. The added weight of the sand also helps you work with less effort and vibration.
  • Page 12 PREPARING THE SEED BED See Figure 13. The cultivator can be used to break up garden soil and pre- pare a seed bed for planting. Plan ahead to leave enough room between the seed rows to allow for machine cultivating after the plants have grown.
  • Page 13 To dig more deeply, lift up on the handlebar. Apply downward pressure on the handlebar for more shallow cultivating. If the machine stays and digs in one spot, try rocking the unit from side to side to start it moving forward again. If the soil is very hard, water a few days before cultivating.

  • Page 14: Adjusting Wheel Position

    ADJUSTING DRAG BAR POSITION See Figure 18. The drag bar may be used to help control the cultivator’s speed and depth of operation. It is located in a slot on the wheel assembly support and is secured with a pull pin.

  • Page 15: General Maintenance

    WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If operation is dusty, also wear a dust mask. WARNING: Before inspecting, cleaning or servicing the machine, shut off engine, wait for all moving parts to stop, and discon-...

  • Page 16: Replacing The Spark Plug

    After extended use the screen can become dirty and may need to be replaced. If replacement is necessary, use part number 000998216. WARNING: To avoid a fire hazard, never run the cultivator without the spark arrestor in place. MAINTENANCE To replace the spark arrestor: ...

  • Page 17: Maintenance

    30 days. Stale fuel has a high gum content and can clog the carburetor and restrict fuel flow. The fuel tank should also be drained if the cultivator will not be used for more than two weeks.

  • Page 18: Troubleshooting

    3 in. x 5 in. card or standard postcard: your name, mailing address, phone numbers, email address, Ryobi product(s) purchased with item number from package, and serial number for each product. Mail the card to: Techtronic Industries North America, Inc., Attn. Ryobi Registration, 1428 Pearman Dairy Road, Anderson, SC 29625.

  • Page 19: Limited Warranty Statement

    Blower Fans, Blower and Vacuum Tubes, Vacuum Bag and Straps, Guide Bars, Saw Chains Techtronic Industries North America, Inc., reserves the right to change or improve the design of any RYOBI outdoor product without assuming any obligation to modify any product previously manufactured.
  • Page 20 Where a warrantable condition exists, Techtronic Industries North America, Inc., will repair your non-road or small off-road engine at no cost to you, including diagno- sis, parts, and labor performed at an authorized service center for RYOBI outdoor products. MANUFACTURER’S WARRANTY COVERAGE: This product’s emissions control system is warranted for two years.
  • Page 21 EMISSIONS MAINTENANCE SCHEDULE AND WARRANTED PARTS LIST Emissions Parts Inspect Before Each Use AIR FILTER ASSY INCLUDES: FILTER ... X ... X SPARK SCREEN ... X CARBURETOR ASSY INCLUDES: HEAT DAM ... X GASKETS ... X FUEL TANK ASSY INCLUDES: FUEL LINES ...

  • Page 22: California Proposition

    • HOW TO ORDER REPAIR PARTS When ordering repair parts, always give the following information: • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® TECHTRONIC INDUSTRIES NORTH AMERICA, INC. 987000-124 2-23-07 (REV:00) OPERATOR’S MANUAL...
