- Page 1 Ryobi Reciprocating Saw October 11, 2005 Computer Aided Drafting 14:650:388:01 Project Team 1 Christopher Clark Danielle Launay Jonathan Lin John Sequeira Rishi Wadhera...
- Page 2 Objective: In this project, our main objective is to effectively model the Ryobi ® Variable Speed Reciprocating Saw. It runs through normal 120-V alternating current power. When on, the saw blade has a stroke of 19/16 inches moving at a maximum speed of 2800 strokes per minute.
- Page 4 Part Number Name Cover Plate Gear Case Seal Gear Case Cover Spring Washer Screw (M4 x 18mm) Seal Screw (M4 x 10mm) Cover Plate Guide Block Saw Bar Assembly Yoke Plate Retaining Ring Roller Bearing Gear Assembly Screw (M4 x 16mm) Shaft Mounting Plate Ball Bearing Gear Shaft...
- Page 5 We do, though, reserve the right to change these responsibilities as necessary, or to suit a particular members strongest abilities. References: http://www.ryobi.com http://oneworld1.inetu.net/manuals/ryobi/RJ162VK_628_r.pdf The Ryobi ® Variable Speed Reciprocating Saw from which our models will be created. Switch Lead Assembly Screw Data Plate...
