- Page 1 DPA-4.8 manual 11/1/02 4:14 PM 4-Zone / 8-Channel Amplifier DPA-4.8 Instruction Manual OWER OWER Page 1 O N E — H A N N E L M P L I F I E R DPA-4.8...
-
Page 2: Table Of Contents
DPA-4.8 cabinet, take the DPA-4.8 to qualified service personal for inspection. 2. Location of the DPA-4.8 - Do not expose the DPA-4.8 to direct sun light or heating units as the DPA-4.8 internal components temperature may rise and shorten the life of the components. -
Page 3: Introduction
Page 3 the four stereo pairs can be bridged to two stereo pairs for higher output power. The DPA-4.8 power output is 50 watts per channel into 8 ohms, and 75 watts into 4-ohms. Bridged adjacent outputs provide 100 watts of power into 8-ohms and 150 watts of power into 4-ohms. -
Page 4: Possible System Configuration
11/1/02 4:14 PM POSSIBLE SYSTEM CONFIGURATIONS The DPA-4.8 can be configured as an audio distribution sys- tem, or used as the main amplifier for a home theater system. When used with an audio distribution preamp, each zone can independently drive one of several different sources by using each zones’... -
Page 5: Front Panel
OWER OWER FRONT PANEL Rack Mounting: The DPA-4.8 amplifier can be rack mounted. The amplifier will take 3 rack spaces. Power Switch: Turns on the main power for the amplifier. When the power is on the LED will be illuminated. -
Page 6: Bridged Operation
DPA-4.8 manual 11/1/02 4:14 PM BRIDGED OPERATION LEFT CHANNEL LINE INPUT LEFT CHANNEL VOLUME CONTROL LINE SET THIS SWITCH TO BRGD MONO FOR BRIDGING PEAKERS LEFT SPEAKER EIGHT OHM Page 6 ZONE 4 NPUT LINE GAIN STEREO BRGD MONO * ∞... -
Page 7: Specifications
Page 7 WARRANTY The Russound DPA-4.8 is fully guaranteed for two (2) years from the date of pur- chase against all defects in materials and workmanship. During this period Russound will replace any defective parts and correct any defect in workmanship without charge for either parts or labor. - Page 8 DPA-4.8 manual 11/1/02 4:14 PM Page 8 5 Forbes Rd. Newmarket, NH 03857, USA ☎ 603.659.5170 • Fax 603.659.5388 e-mail: tech@russound.com Come visit us at:...
