SPALDING M300011 Owner's Manual

Sports table
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
REQUIRED TOOLS
AND MATERIALS:
• Two (2) capable
adults
• Hammer
• Safety Glasses
• (2 each) Wrenches and/or
Socket Wrenches and
Sockets (Deep-Well
Sockets are
Recommended).
• Extension is Recommended.
7/16"
1/2"
9/16"
3/4"
AND/OR
7/16"
1/2"
9/16"
3/4"
OPTIONAL TOOLS
AND MATERIALS:
• Large and Small
Adjustable Wrenches
© COPYRIGHT 2005 by SPALDING
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
This manual, accompanied by sales receipt, should be saved and kept on hand as a
convenient reference, as it contains important information about your model.
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO
PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-558-5234,
For Europe: 00 800 555 85234 (Sweden: 009 555 85234),
Internet Address: http://www.huffysports.com
Sports Table
Owner's Manual
Customer Service Center
Adult Assembly Required.
WARNING!
For Canada: 1-800-284-8339,
For Australia: 1-800-632 7921
1
Write Model Number
From Box Here:
08/06
ID# M300011

Advertisement

loading
Need help?

Need help?

Do you have a question about the M300011 and is the answer not in the manual?

Questions and answers

Related Manuals for SPALDING M300011

Summary of Contents for SPALDING M300011

  • Page 1 OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-558-5234, For Canada: 1-800-284-8339, For Europe: 00 800 555 85234 (Sweden: 009 555 85234), For Australia: 1-800-632 7921 Internet Address: http://www.huffysports.com Write Model Number From Box Here: 08/06 ID# M300011...
  • Page 2 600057 Base, Laminated 206146 Glider, Feet 205673 Rod, 1/4-20 x 13-1/8 Long 206144 Washer, Large ID# M300011 08/06 Be sure to check inside pole sections, hardware and additional parts are packed inside. STOP! STOP! NOTICE TO ASSEMBLERS STOP! periodically inspect for loose small parts.

  • Page 3: Hardware Identifier

    HARDWARE IDENTIFIER (NUTS AND WASHERS) #7 (2) #8 (1) #11 (1) #10 (4) Get to know the basic parts of your system... 08/06 ID# M300011...

  • Page 4: Outside View

    Place the rod (6) through the table base (4) and install flat washer (7) and jam nut (8) as shown. Position pole (9) over the rod (6) and into the recessed location on the base (4) as shown. ID# M300011 08/06 Install net (3) as shown. OUTSIDE VIEW...
  • Page 5 (6) above the pole (9). Secure with washer (7) and acorn nut (11) as shown. Tighten completely. Position table top (2) as shown. Attach the bumpers (12) to the top of the rim (1) surface as shown. 08/06 ID# M300011...
