SPALDING 89226CA Owner's Manual

Display system
Hide thumbs

Advertisement

Quick Links

Download this manual
To ensure prompt and correct handling of any problems, or to answer any questions, please
© COPYRIGHT 2006 by SPALDING
Display System
Owners Manual
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO PROPERTY.
contact the Sample and Display Technician at 1-800-558-5234.
Customer Service Center
REQUIRED TOOLS AND MATERIALS:
• 2 Capable Adults
• 2 Stepladders
• Phillips Screwdriver
IMPORTANT!
1
Model
89226CA
• (2 each) Wrenches and/or
Socket Wrenches and
Sockets.
7/16"
1/2"
9/16"
AND/OR
7/16"
1/2"
9/16"
11/06
ID# M890021

Advertisement

loading
Need help?

Need help?

Do you have a question about the 89226CA and is the answer not in the manual?

Questions and answers

Related Manuals for SPALDING 89226CA

Summary of Contents for SPALDING 89226CA

  • Page 1 © COPYRIGHT 2006 by SPALDING Display System Owners Manual Customer Service Center REQUIRED TOOLS AND MATERIALS: • 2 Capable Adults • 2 Stepladders • Phillips Screwdriver IMPORTANT! Model 89226CA • (2 each) Wrenches and/or Socket Wrenches and Sockets. 7/16" 1/2" 9/16" AND/OR 7/16" 1/2"...

  • Page 2: Safety Instructions

    hardware and additional parts are packed inside. SAFETY INSTRUCTIONS FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY This unit is intended for display purposes only and To ensure safety, do not attempt to assemble this system without following the instructions carefully. Check entire box and inside all packing material for parts.
  • Page 3 Item Qty. Part No. Description 200318 Bracket, Reinforcement S/J 203223 Bolt, Carriage, 5/16-18 x 1" 908379 Board Bracket 200533 Spacer, Mounting 990062 Pole, 3.5" 908378 201611 Bolt,Hex-Flange, 5/16-18 x 3" 205544 Bolt, 5/16-18 x 1.25" 203063 Lock Nut, 3/8-16 Nylon Insert 912006 Extension Arm 203100...
  • Page 4 Install display boards in the marked locations. Each mounting location consists of a mounting pole stub with the following dimensions: Height = 8”, O.D. = 3 3/8”, I.D. = 3 1/8” (arrows indicate direction the board is facing). Display boards will be mounted as follows: Corner Location 1: Corner Location 2: Corner Location 3:...
  • Page 5 Corner Location 1 & 2: POLE PLACEMENT At corner locations 1 and 2 slide the 3-1/2" diameter end of the display pole (5) outside the mounting stubs. Corner Location 3: POLE PLACEMENT At corner location 3 slide the 2.75” diameter pole end of the display pole (24) inside the moiunting stub.
  • Page 6 Corner Location 1: STEEL FRAME ACRYLIC BACKBOARD ASSEMBLY Display Stand - Top View 3" 3-1/2" 65246CA Open - No Board 77271CA 66281CA 3-1/2" 3-1/2" Insert “T” bolt (18) through Slam Jam bracket (23) as shown. Secure Slam Jam bracket (23), extension arm (10) and mounting spacers (4) assemblies to backboard using bolt (7 ) and nut (11) as shown.
  • Page 7 • Fit rim (21) securely into bracket (23) as shown. • Install reinforcement bracket (1) onto “T” bolt (18) as shown. • Install spring (16) onto “T” bolt (18) as shown. • Install special nut (17) and washer (15) onto “T” bolt (18). NOTE: Peel protective film from surface...
  • Page 8 Corner Location 2: 48” SQUARE MOLDED PLASTIC BOARD ASSEMBLY Display Stand - Top View 3" 3-1/2" 65246CA Open - No Board 66281CA 77271CA 3-1/2" 3-1/2" Insert “T” bolt (18) through Slam Jam bracket (23) as shown. Secure Slam Jam bracket (23) and extension arm (10) to backboard using bolt (7) and nut (11) as shown.
  • Page 9 • Fit rim (21) securely into bracket (23) as shown. • Install reinforcement bracket (1) onto “T” bolt (18) as shown. • Install spring (16) onto “T” bolt (18) as shown. • Install special nut (17) and washer (15) onto “T” bolt (18). NOTE: Tighten nut (17) until flush with end of...
  • Page 10 Corner Location 3: 44" TRAPEZOID MOLDED PLASTIC BOARD ASSEMBLY Attach rim (6), backboard (26) and support brackets (3) to the mounting pad on the top pole using the bottom rim mounting bolts (8) as shown. ID# M890021 11/06 Display Stand - Top View 3"...
  • Page 11 Install the top rim mounting bolts (8) as shown. Install net (20) as shown. Install support bracket mounting bolts (21) as shown. OUTSIDE VIEW 11/06 ID# M890021...
