Youth Basketball System
Owner's Manual
Toll-Free Customer Service Number for U.S.: 1-800-558-5234
http://www.huffysports.com
© COPYRIGHT 2004 by HUFFY SPORTS
Item Qty. Part No.
1
1
900265
2
1
900266
3
1
900267
4
2
900268
5
2
900270
6
2
201358
7
4
201362
8
4
201363
9
20
201364
10
2
203092
11
4
204591
12
10
206723
13
4
266102
14
2
201360
15
1
908175
16
1
17
1
18
2
204589
19
2
204590
20
4
203493
* YOU MAY HAVE EXTRA PARTS WITH THIS MODEL.
Write Model Number
From Box Here:
1
PARTS LIST
Description
Top Pole Section
Middle Pole Section
Bottom Pole Section
Leg, High Holes
Leg, Low Holes
Screw, Self Tapping, 6-18, .50 Long
Cap, Pole, Plastic, Male
Cap, Pole, Plastic, Female
Washer, Flat, .25 I.D., .50 O.D.
Bolt, Hex, 1/4-20 x 1.75" Long
Bolt, Hex, 1/4-20 x 1.125" Long
Bolt, Hex, 1/4-20 x 3.625" Long
Locknut, Nylon Insert
Bracket, Board Mounting
Plate, Mounting
Net
Rim
Wrench
Screwdriver, Phillips
Lockut, Nylon Insert, 1/4-20
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING
INSTRUCTIONS COULD
RESULT IN INJURY OR
DAMAGE TO PROPERTY.
12/04
P/N 211745
