OPERATOR'S MANUAL
HWH COMPUTER-CONTROLLED
SPACEMAKER ROOM EXTENSION SYSTEM
TOUCH PANEL LEVELING CONTROL
DUAL CYLINDER "LEVEL FLOOR" ROOM EXTENSION
SINGLE CYLINDER "BEDROOM" ROOM EXTENSION
AP21910
H
W
CORPORATION
LEVELING SYSTEM
680 SERIES
FEATURING:
AIR LEVELING
HWH COMPUTERIZED LEVELING
EXCESS
SLOPE
AIR
LEVEL
NOT IN
PARK/
DUMP
BRAKE
TRAVEL
OFF
CAUTION!
RAISE
UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES
SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE.
HWH CORPORATION
(ON I-80, EXIT 267 SOUTH)
2096 MOSCOW ROAD
MOSCOW, IOWA 52760
(800) 321-3494 / (563) 724-3396
INTERNET: http: //www.hwhcorp.com
H
R
ML17140/MP05.4710
18MAY01
