- Page 1 ® Tranquility uest Plus Service Manual ® ® ®...
- Page 2 ® Tranquility Quest Plus CPAP System is patent pending. Copyright © 2000 Respironics, Inc. All rights reserved. Tranquility Quest Plus CPAP System Service Manual...
-
Page 3: Limited Warranty
Respironics warrants that the Tranquility Quest Plus CPAP System shall be free from defects of workmanship and materials and will perform in accordance with the product specifications for a period of two years from the date of sale by Respironics. If the product fails to perform in accordance with the product specifications, Respironics will repair or replace—at its option—the defective material or part. -
Page 4: Table Of Contents
Block Diagram..........6 (Optional)............ 30 Chapter 4: System Setup Clinical Remote Control Test Data Sheet Procedures (Optional)............ 31 Pressure and Ramp Settings....... 7 Chapter 5: Routine Maintenance Cleaning the System ........8 1003740 Tranquility Quest Plus CPAP System Service Manual... - Page 5 A.1 Service Tools and Supplies ....... 32 A.2 Acceptable Test Equipment ...... 32 A.2.1 Digital Manometer ........A.2.2 Digital Multimeter ........Appendix B: Schematics Schematic Statement ......... 34 Main Printed Circuit Assembly (PCA) ............35 1003740 Tranquility Quest Plus CPAP System Service Manual...
-
Page 6: Chapter 1: Warnings, Cautions, And Notes
1.1 WARNINGS Tranquility Quest Plus CPAP System enclosure and may create a risk of fire. This warning applies to 1.1.1 Safety most types of CPAP devices. -
Page 7: Service
1.1.3 Service • Care should be taken to avoid exposure of the Tranquility Quest Plus to temperatures at or near • Electronic components used in this device are the extremes of those specified in Chapter 2. If subject to damage from static electricity. -
Page 8: Notes
System setup should be performed by appropriate personnel using Home Care Dealer Instructions. 1.3 NOTES • Refer to the Tranquility Quest Plus User’s Manual for product use, additional warnings, cautions, and notes. Additional WARNINGS, CAUTIONS, and NOTES are located throughout this manual. -
Page 9: Chapter 2: Specifications Specifications
Fuse Type ..........T1A, 250v, 5 x 20 mm -60 to + 120 L/min. (Respironics P/N 1004092) Accuracy, Dynamic ....... + 1.5 cm H O for flows between -60 to + 120 L/min. Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 10: Chapter 3: Theory Of Operation
The Tranquility Quest Plus is intended to deliver CPAP therapy and is then pressurized. Ultimately, therapeutic pressure is pro- only. -
Page 11: Block Diagram
Chapter 3: Theory of Operation 3.2 Block Diagram Tranquility Quest Plus Air Outlet Control Pad (3 Pushbuttons) Tranquility Quest Plus Optical Connection Main PCA Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 12: Chapter 4: System Setup Procedures
Press the up or down arrow button to change the CAUTION: If the Tranquility Quest Plus CPAP System has setting. The setting is implemented immediately when the up or been exposed to either very hot or very cold down button is pressed. -
Page 13: Chapter 5: Routine Maintenance
Let the use. Never place a wet filter into the device. unit dry before reconnecting the electrical supply. Respironics recommends that you clean the filter in the morning and alternate using the two pollen 5.2 Cleaning / Replacing the filters provided with the system to ensure enough drying time for the cleaned filter. -
Page 14: Preventive Maintenance Schedule (Factory Recomended)
Chapter 5: Routine Maintenance Tranquility Quest Plus CPAP System Preventive Maintenance Schedule (Continued) 5.3 Tranquility Quest Plus Preventive Maintenance Schedule (Factory Recommended) Model No. _____________ Serial No. ______________________ Date ____________ Service Technician ________________ Maintenance Item Verification Reference Service Interval Date... -
Page 15: Chapter 6: Troubleshooting
Main PCA, loose all connectors on • Power Supply PCA An intermittent on / off connections. the PCAs. condition exists, unit operates • Power Supply PCA. randomly, or indicator lights blink sporadically. Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 16: Chapter 6: Troubleshooting
Wash buildup. tubing with soap and water. To clear residue build-up, replace all subassemblies in the patient air stream (blower, filters, patient circuit). 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 17: Chapter 6: Troubleshooting
Check blower for air kinked. Main PCA or • Replace blower, pressure leaks. blower malfunction. tubing, or Main PCA as required. Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 18: Chapter 6: Troubleshooting
Static pressure fluctuates • Replace the Main PCA. value by more than the specification • Replace the Main PCA. Unable to turn unit on. Replace the Main PCA. Device not calibrated Ramp LED Flashing 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 19: Chapter 6: Troubleshooting
(see Section 8.1) greater than 1 cm H • Main PCA, Blower • Air path blocked Replace Main PCA Time not updating. Main PCA Compliance Meter Not Updating Tranquility Quest Plus CPAP System Service Manual 1003740... - Page 20 Repair Information Service Notice..........16 Technical Support ........16 Tranquility Quest Plus CPAP System Exploded View .......... 17 Tranquility Quest Plus CPAP System Repair Kits ..........18 Repair Identification Photo’s ....22 1003740 Tranquility Quest Plus CPAP System Service Manual...
-
Page 21: Chapter 7: Repair & Replacement
This service manual was prepared by Respironics primarily for use Visit Respironics Home Page on the World Wide Web at: by technicians to service the Tranquility Quest Plus System. The individuals using this manual to service the Tranquility Quest Plus www.respironics.com... -
Page 22: System Exploded View
Chassis Mounting Plate Display Assembly Hose ( Blower to Flowmeter Standoffs Outlet Port Heat Sink Blower Vibration Isolator Display Cable Power Supply Mounting Plate Main PCA Tranquility Quest Plus CPAP System Exploded View 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 23: Repair Kits
Bottom Enclosure 1004004 Note 1: For available international AC Power Cords, contact Respironics Customer Service. Note 2: Blower assemblies are not interchangeable. Be sure to use the same style blower when replacing the assembly. Tranquility Quest Plus CPAP System Service Manual... - Page 24 Chapter 7: Repair & Replacement Tranquility Quest Plus CPAP System Repair Kits (Continued) Replacement Part Replacement Part No. Illustration Chassis Mounting Plate 1004009 7-10 Includes: (1) Lower Chassis (1) Foam Seal (1) Screen Foam Cover (3) Vibration Isolators (1) Bottom Blower Foam Seal (3) Standoffs M-F, 6-32 x 1/4”...
- Page 25 (1) #6-19 x 3/8” Plastite PHP Screw (1) Tubing Assembly (1) Tubing Sub-Assembly 5 3/4” (1) Tubing Sub-Assembly 8 1/2” Outlet Port / Flowmeter 1004003 Includes: (1) Outlet Port (1) #6-19 x 3/8” Plastite PHP Screw Tranquility Quest Plus CPAP System Service Manual 1003740...
- Page 26 Power Supply 1004421 (2) #6-32 X 1/4” Screws (2) #6-32 X 1/2” Screws (1) Insulator Ramp Switch Wire Harness 1004002 Rubber Feet (x4) 1004516 7-10 Service Manual 1004014 N.A. Top Enclosure 1004095 1003740 Tranquility Quest Plus CPAP System Service Manual...
-
Page 27: Repair Identification Photo's
AC Inlet Top Enclosure Power Fuse Label (Not Shown) Front Overlay Fiber Optic On / Off Switch Outlet Port Communication Port Replacement Filter Ramp Buttom Fuse Drawer Bottom Enclosure (Figure 1) (Figure 2) Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 28: Power Supply
Chapter 7: Repair & Replacement Repair Identification Photo’s (continued) Blower Assembly Power Supply PCA Power Supply AC Input Wire Harness Cable Tie (through Main PC Board) (Figure 3) (Figure 4) 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 29: Ramp Switch Wire Harness
Main PCA Ramp Switch Wire Blower Vibration AC Inlet Isolator (3) Heat Sink Ramp Switch Wire Harness Chassis Mounting Plate Pressure Tubing Main Power Switch Wire Harness Display Cable (Figure 6) (Figure 5) Tranquility Quest Plus CPAP System Service Manual 1003740... -
Page 30: Rubber Feet (X4)
Chapter 7: Repair & Replacement Repair Identification Photo’s (continued) Rubber Feet (x4) Symbols Label Control Panel (Figure 7) 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 31: Chapter 8: Testing
Final Test ............27 8.2 Tranquility Quest Plus System Final Test Data Sheet ........29 8.3 Clinical Remote Control Testing (Optional) ............. 30 8.4 Clinical Remote Control Test Data Sheet (Optional) ......31 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 32: System Final Test
Unocclude the test orifice. Verify the pressure on the • DC Power Supply, Model 913* manometer is 19.0 to 21.0 cm H O. Record the results. • Optical Interface Cable* (RI P/N 1701-06) * Used for Clinical Remote Control Testing 1003740 Tranquility Quest Plus CPAP System Service Manual... - Page 33 Chapter 8: Testing Tranquility Quest Plus System Final Test (Continued) Step 7 Press the ramp button and verify that the pressure on the manometer drops to approximately 3.0 cm H Pressure will increase over the specified time period until the pressure setting is reached. Verify at least 1 cm H O in pressure change in ramp operation.
-
Page 34: System Final Test Data Sheet
Chapter 8: Testing Tranquility Quest Plus System Final Test Data Sheet Model Number Test Step Specification Actual Actual Final Pre Run-In Post Run-In Pass / Fail Minimum Pressure 2.5 to 3.5 Occluded cm H Minimum Pressure 2.0 to 4.0 Unoccluded... -
Page 35: Clinical Remote Control Testing (Optional)
8.7 to 9.3 read CPAP. 5.7 to 6.3 2.7 to 3.3 5. Connect the manometer to the occluded test orifice and the test orifice to the unit. Turn the units main power switch off. 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 36: Clinical Remote Control Test Data Sheet (Optional)
Chapter 8: Testing 8.4 Tranquility Quest Plus System Final Test Data Sheet Clinical Remote Control (CRC) (Optional to be used if CPAP unit is equipped with a CRC) Serial Number Service Notification (RI use) Model Number Test Step Specification Actual... -
Page 37: Appendix A: Tools And Equipment
A.1 Service Tools and Supplies Specifications: You should have the following hand tools and supplies available for 0 – 25 cm H O (or better) troubleshooting, testing, and repairing the Tranquility Quest Plus CPAP System. ±0.3 cm H O accuracy •... -
Page 38: Digital Multimeter
2.5 digit readout minimum 0.0 – 20.0 VDC 0.0 – 25.0 VAC Acceptable Options: • Fluke 83 or better model • Any commercially available digital multi- meter that meets the above specifications. 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 39: Appendix B: Schematics
New revisions may or may not be distrib- uted in the future. Note: The Power Supply PCA is a purchased item. The schematic is not available for distribution. 1003740 Tranquility Quest Plus CPAP System Service Manual... -
Page 40: Main Printed Circuit Assembly (Pca)
B.2 Main Printed Circuit Assembly (PCA) 1003740 Tranquility Quest Plus CPAP System Service Manual... - Page 41 B.2 Main Printed Circuit Assembly (PCA) 1003740 Tranquility Quest Plus CPAP System Service Manual...
- Page 42 Reorder # 1004014 Revision # 1003740 DS / KT 01/05/00...
