Ruby Tech CR-2010 Specifications

RUB
TECH
CR-2010
CR-2010
24-Port 100M SEP-SC Fiber + 2 Gigabit SEP-SC Fiber/TP(Fixed) Dual Media Port Intelligent
Ethernet Switch
Key Features Key Features
Supports in-band/out-of-band
management
Supports backpressure for half
duplex and 802.3x flow control for full
duplex
Supports 2 FE ports on CPU board for
management network
Supports head of line (HOL) blocking
prevention
Max switching capacity: 8.8G non-
blocking at wire speed
Supports chassis ID for location
alignment
Supports management through any
Ethernet port and RS-232
Supports short message and email
for trap and alarm
Supports per port external loopback
capability
Supports port mirroring function
Support MIB II, Bridge MIB, Ethernet
MIB, Enterprise MIB, RMON I MIB
Supports port-based/802.1v and
802.1q tagged VLAN, up to 256
active VLANs
Supports IP multicast with IGMP
snooping
Supports Ethernet multicasting and
broadcasting and flooding storm
control
Supports max of 50 per port allowed
MAC address entries and 50 global
denied MAC address entries for port
security
Supports max. 32 entries of illegal
table
Supports Auto-ping function with
adjustable interval
Supports 802.1p CoS with 2 level
priority
Supports detection of temp. x 2,
voltage, fans speed x 3
Supports 3 fans: two embedded in
power and one driven by two power
Supports dual redundant pluggable
power with loading balance
Technical Specifications Technical Specifications
Performance:
Bandwidth: 8.8Gbps Switching Capacity
VLAN: 256 active
IP multicast table entries: 2k
Supports Packet length up to max of 1536 bytes long
Supports 10k MAC address table
Standards Compliance:
IEEE 802.3u /z /x /ab /ad
IEEE 802.1d /p /q /v /x /advanced 802.1x
100Base-FX Fast Ethernet Fiber Specification
1000Base-SX/1000Base-LX Gigabit Ethernet Fiber specification
SNMP
RMON
Protocol Support:
802.1d/1w/1s STP
802.3ad LACP
802.1q with GVRP/GMRP/GARP
802.1p priority queue
IGMP snooping
ARP, RARP, RIP, DHCP server/client/relay
Telnet, BootP, TFTP, FTP, HTTPD, NTP
Network Management:
RFC 1213 MIB (MIB-II)
Interface MIB
Address Translation MIB
IP MIB
ICMP MIB
TCP MIB
UDP MIB
SNMP MIB
RFC 1757 RMON MIB
Statistics Group 1
History Group 2
Alarm Group 3
Event Group 9
RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
Enterprise MIB
Maximum Switching Ports:
The maximum service port capability:
- 24 Fast Ethernet ports
- 2 Gigabit Ethernet ports
Intellident Switch
Central Office Switch
