RTS Digital Matrix Intercom IFB-828 Specifications

8-channel ifb panel with volume controls

Hide thumbs Also See for Digital Matrix Intercom IFB-828:

See also: Instructions for Using , User Manual

Features

The IFB-828 interfaces up to eight RTS Systems' Model IFB-325, 4020, or 4030 IFB beltpacks to any RTS Digital Matrix Inter-

com System, and it provides power to the beltpacks. The IFB-828 may also be used as a simple program interface to feed two

separate program sources to each of eight 4020 or 4030 beltpacks (16 program sources to eight beltpacks total).

IFB-828

8-Channel IFB Panel with Volume Controls

Table of Contents

Do you have a question about the Digital Matrix Intercom IFB-828 and is the answer not in the manual?

Page 1 Features The IFB-828 interfaces up to eight RTS Systems’ Model IFB-325, 4020, or 4030 IFB beltpacks to any RTS Digital Matrix Inter- com System, and it provides power to the beltpacks. The IFB-828 may also be used as a simple program interface to feed two separate program sources to each of eight 4020 or 4030 beltpacks (16 program sources to eight beltpacks total).
Page 2 Audio Inputs Type: Balanced (transformer coupled) Level: +4 to +8 dBu Impedance: Approximately 600 ohms Audio Outputs Type: Unbalanced Level: -10 to -6 dBu Output Power (each IFB beltpack channel): +24VDC, 200 mA Dimensions 19” (483 mm) W x 1.75” (44.5 mm) H x 7.5” (191 mm) D Input Power Requirements 110/120 or 220/240 VAC, 50/60 Hz, selectable via a back panel switch Connectors...
