OWNER’S MANUAL MANUAL DEL PROPIETARIO ARP-1200M / ARP-1200DM / ARP-1200E / ARP-1200DE PORTABLE AIR CONDITIONER ACONDICIONADOR DE AIRE PORTÁTIL Read and retain these instructions for future reference For any Customer Support needs, please choose the Customer Support tab on www.royalsovereign.com...
Page 2
PORTABLE AIR CONDITIONER Model ARP-1200M / ARP-1200DM / ARP-1200E / ARP-1200DE...
• Keep curtains or blinds closed during the sunniest part of the day. • Keep filters clean. • Once room has reached the desired conditions, reduce temperature and ventilation settings. ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE FIG.1 FIG.3 FIG.2 FIG.4...
Page 4
3. Carrying handle 4. Caster Accessories 10. Air Conditioner adaptor - for insertion over hose and into back of the air conditioner. 11. Window adaptor - for insertion over hose and into window spacer. 12. Exhaust hose 13. Extendable window spacer.
INSTALLATION Installation of the exhaust pipe The unit is a portable air conditioner that may be moved from room to room. Please follow the steps for installation: 1. Feed the outward adapter through the extendable window spacer. 2. Screw the exhaust hose into the outward adapter.
Mounting of the exhaust pipe • Using only the hose provided, screw unit adapter to exhaust hose then clip the unit adaptor to the back of the air conditioner. • Avoid kinks and bends in the exhaust hose as this will cause expelled moist air to build up causing the unit to overheat and shut down.
Turn the speed switch to select required setting: LOW FAN, HIGH FAN, LOW COOL, HIGH COOL Cooling & heating models (ARP-1200DM and ARP-1200DE) Turn the speed switch to select required setting: FAN, LOW COOL, HIGH COOL, LOW HEAT, HIGH HEAT Setting temperature Turn the THERMOSTAT to regulate the temperature desired: The cooling intensity increases clockwise..
Setting temperature Press the 'Temperature up' or 'Temperature down' button to regulate the temperature desired. The display window will show the temperature which you have set as you press the 'Temperature up' or 'Temperature down' button. Otherwise, it will always show the ambient temperature. The preset temperature of this machine is: 75 Setting ventilation speed 1.
Page 11
For the electronic model, both of the compressor and motor will stop. The COMP. indicator light will flash. To resume the cooling function, empty the water by the following steps: 1. Turn off the air conditioner and avoid moving it when full. 2. Position the water tray underneath the drain hole.
Page 12
If you wish to operate the unit without the need to empty the water tank, please: • Remove the drain knob and rubber plug and retain for future use. • Connect the drain tube supplied to the water outlet as shown and locate the other end into a drain.
MAINTENANCE Always unplug the air conditioner from the outlet before cleaning. To maximize the efficiency of the air conditioner clean regularly. Cleaning the housing Use a soft, damp cloth to wipe the body clean. Never use chemicals, gasoline, detergents, chemically treated cloths, or other cleansing solutions, as such could possibly damage the cabinet.
TROUBLE SHOOTING The air conditioner does not run: The machine seems to do little: The machine seems to do nothing: Too noisy: The compressor doesn't run: * Never try to repair or dismantle the unit yourself Is the air conditioner plugged in? •...
Page 15
19.7 x 15.7 x 29.5 (in) 500 x 400 x 750 (mm) C), RH60% Heating - RT 68 °F (20 C), RH60% ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE ARP-1200DE 12500 BTU’s 930 W / 8.6 A electronic w/ remote 54.1 dB(A)
LIMITED FIVE YEAR WARRANTY (COMPRESSOR) For a period of five years from the date of purchase, when this Royal Sovereign Portable Air Conditioner is operated and maintained according to the instruction manual provided with the product, Royal Sovereign will supply a replacement compressor (part only), free of charge, if the original compressor is determined to be defective in workmanship or material.
MANUAL DEL PROPIETARIO ARP-1200M / ARP-1200DM / ARP-1200E / ARP-1200DE ACONDICIONADOR DE AIRE PORTÁTIL Lea y conserve estas instrucciones para referencia futura Para preguntas, por favor. Visite nuestra pagina de internet www.royalsovereign.com service al cliente. Royal Centurian Inc.
• Mantenga ventanas y persianas cerradas durante las horas más soleadas. • Mantenga limpios los filtros. • Cuando la habitación alcance las condiciones deseadas reduzca los valores fijados de temperatura y ventilación. ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE FIG.1 FIG.3 FIG.2 FIG.4...
COMPONENTES Parte delantera 1. Panel de Control (vea en la página 5 una ilustración del pane 2. Salida de aire 3. Manija para transporte 4. Rueda giratoria Accesorios 10. Adaptador de acondicionador - para conectar a la manguera y a la parte posterior del acondicionador 11.
NOTA: Instalar el respiradero verticalmente o horlzontalmente dependiendo del estilo de ventana. El espaciador de la ventana se puede cortar a la medida. Si el espaciador no llena la abertura ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE Adaptador exterior FIG.5 FIG.7 FIG.6...
Page 22
Montaje del tubo de descarga • Utilizando la manguera provista, atornille el adaptador de la unidad a la manguera de descarga y después sujete el adaptador a la parte de atrás del acondicionador de aire. • Evite que la manguera de descarga se tuerza o se curve, ya que cualquiera de estas condiciones provoca la acumulación del aire húmedo expelido causando que la unidad se sobrecaliente y se detenga.
Page 23
5. Indicador de funcionamiento de la calefacción ( sólo para modelos ARP-1200DM) 6. Temporizador (1-8 horas) y llave de encendido/apagado (ON/OFF) 7. Llave de velocidades con opciones para VENTILACIÓN, REFRIGERACIÓN BAJA, REFRIGERACIÓN ALTA, CALEFACCIÓN BAJA, CALEFACCIÓN ALTA. 8. Termostato FIG.12 ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE...
Encendido/apagado (ON/OFF) Para operación continua lleve el temporizador a la posición de encendido (ON), (la unidad se mantendrá en funcionamiento mientras no se apague). El indicador de alimentación eléctrica se enciende. Para apagar la unidad lleve el temporizador a la posición de apagado (OFF). Selección de función/velocidad de ventilación Modelos sólo refrigeración (ARP-1200M y ARP-1200E) Gire la llave de velocidades para seleccionar la opción deseada: VENTILACIÓN BAJA, VENTILACIÓN ALTA, REFRIGERACIÓN BAJA, REFRIGERACIÓN ALTA...
Page 25
Si desea una temperatura por encima o por debajo de 75°F/24°C, haga funcionar la unidad en el modo de enfriamiento y fije la temperatura deseada oprimiendo los botones de aumento y bajada de temperatura. ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE FIG.16 13. Botón 'subir temperatura' 14.
Selección de la temperatura Oprima el botón 'Aumento de temperatura' o 'Disminución de temperatura' para regular la temperatura deseada. El indicador visual muestra la temperatura seleccionada. Si dichos botones no se oprimen el indicador visual muestra la temperatura ambiente. Los valores predeterminados de temperatura son: 75 F/20 C para calefacción..
Page 27
5. Repita hasta que la unidad se vacíe. 6. Vuelva a colocar el tapón de goma y apriete firmemente la perilla de drenaje. 7. Encienda la unidad - la luz COMP no debe parpadear. ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE FIG.19 Drain hole Rubber plug...
Page 28
Si desea operar la unidad sin tener que vaciar el tanque de agua: • Retire la perilla y el tapón de goma del drenaje y consérvelos para usarlos en el futuro. • Conecte el tubo de drenaje suministrado a la salida del agua como se muestra y coloque el otro extremo en un desagüe.
• Desenchufe y guarde el cordón de alimentación como se muestra. • Para guardar la unidad vuelva a colocarla en la caja original o tápela. • Mantenga siempre la unidad en posición normal. ARP-1200M / ARP-1200DM ARP-1200E / ARP-1200DE Cord FIG.23...
Page 30
RESOLUCIÓN DE PROBLEMAS El acondicionador de aire no funciona: El aparato parece tener bajo rendimiento: El aparato parece inactivo: El aparato es demasiado ruidoso: El compresor no funciona: * Nunca intente reparar o desmontar la unidad por sus propios medios •...
Page 31
Nivel de ruido NOTA: 1. La capacidad de calefacción se refiere solamente a los modelos que poseen dicha función, o sea, los modelos Nº ARP- 1200DM y ARP-1200DE. 2. Las condiciones de medición para los datos anteriores son las siguientes: Refrigeración - Temperatura ambiente 80.6 °F (27...
Page 32
GARANTÍA LIMITADA POR CINCO AÑOS (COMPRESOR) El compresor del Acondicionador de Aire Portátil Royal Sovereign posee una garantía de cinco años a partir de la fecha de compra, si el acondicionador de aire se opera y mantiene de acuerdo al manual de instrucciones provisto con el producto. Royal Sovereign suministrará sin cargo un compresor de reemplazo (solamente el repuesto), si se determina que el compresor original presenta defectos de materiales o mano de obra.
