Rover 300361 Owner's Manual

Rover mowers owners manual reel mower 300361, 300433

Advertisement

Quick Links

Owners Manual
QUEEN
TM
30" REEL MOWER
TM

Advertisement

loading
Need help?

Need help?

Do you have a question about the 300361 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rover 300361

  • Page 1 Owners Manual QUEEN 30” REEL MOWER...
  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS * A mower user must be in good physical condition and mental health and not under the influence of any drug or alcohol which might impair vision, co-ordination or judgement. * Do not use a mower when tired or fatigued. Lack of alertness may cause serious injury.
  • Page 3: Maintenance And Adjustment

    MAINTENANCE AND ADJUSTMENT 30” QUEEN ELECTRIC MOWER 2 SPEED OPERATION Normal Speed _ 4.9km/p.h Low Speed _ 3.2km/p.h SPEED CONTROL To change speed, stop motor and move ribbed sliding sleeve (A) inwards to engage normal speed or outwards for low speed as required. It may be necessary to twist the sleeve or countershaft backwards and forwards slightly whilst sliding the sleeve position to allow the gear teeth to line up and mesh fully.
  • Page 4 HEIGHT ADJUSTMENT – To cut lower, slacken quadrant clamp bolt nuts (1), also the lower adjusting screw nut (2). Then tighten top adjusting screw nut (3) until desired height of cut is obtained. To cut higher, reverse procedure. Re-tighten all nuts after desired setting is obtained. The indicator marks on the quadrant are an indication of the cutting height, but to set the height of cut accurately the setting gauge must be used.
  • Page 5 TO CHECK THE MOWER FOR ALIGNMENT – Your mower is designed to produce the perfectly flat cut that is required for a top quality green. Ridging or stepping between cuts means that the height of cut is unevenly set or more likely, that the mower is “out of square”...
  • Page 6 REVERSING CUTTER – A feature of this machine is that the cylinder may be easily removed, reversed end for end and replaced. This provides a new keen cutting edge. If the bottom blade is badly worn, this should be replaced at the same time that the cutting cylinder is reversed or replaced.
  • Page 7 WARNING – State Electricity Authority regulations provide that it is always necessary to disconnect power supply before effecting any adjustments to the machine. ELECTRIC MOTOR MODEL 300361 1.5 HP 240V SINGLE PHASE 7.3 AMPS. MODEL 300433 1.5 HP 415V THREE PHASE 2.6 AMPS. NOTE: Model No: 300361 Queen The reset button is located on the mains power switch mounted on the right hand side of the handles.
  • Page 9 30” QUEEN ITEM PART No. 1 305795 2 305779 3 302148 4 A03285 5 301428 6 302033 7 302156 8 302172 9 305971 10 305621 11 1661775 12 305630 13 305656 14 A12106 15 A02110 16 A02034 17 A02060 18 318228 19 A02044...
  • Page 11 30” QUEEN ITEM PART No. 1 301217 2 303992 3 304012 4 301188 5 3111255 6 301807 7 301196 8 333024 9 301840 10 1502474 11 1122422 12 301815 13 301858 14 304400 15 304434 16 301583 17 161461 18 161453 19 2986543...
  • Page 13 30” QUEEN ITEM PART No. 1 306122 1 10168 2 393000 3 301735 4 301647 5 301698 6 2986519 7 165340 8 301680 9 163432 10 A07744 11 163440 12 301727 13 301719 14 161461 15 161453 16 1213325 17 2641238 18 A04069...
  • Page 15 30” QUEEN ITEM PART No. 1 301516 2 304506 3 304514 4 166246 5 304522 6 304485 7 303423 8 303440 9 303490 10 303503 11 303431 12 301583 13 301559 14 301049 15 301030 16 301057 17 303407 18 2211047 19 1122327...
  • Page 17 30” QUEEN PART ITEM DESCRIPTION 1 302869 Countershaft 2 301962 Countershaft sprocket 3 1502474 Circlip 4 1122422 Countershaft bearing 5 301815 Countershaft bearing housing- LH. 6 1501052 Circlip 7 302383 Countershaft gear 8 2721210 Countershaft gear seal 9 302201 Clutch housing side cover 10 301276 Clutch plate lining...
  • Page 19 30” QUEEN ITEM PART No. 1 305648 2 301065 3 305664 4 305701 5 305920 6 302076 7 302084 8 305728 9 305752 10 2051907 11 A02001 12 A02146 13 A02060 14 A02034 15 2321182 16 A02031 17 A02085 18 A02004 - SPARE PARTS LIST DESCRIPTION...
  • Page 21 30” QUEEN ITEM PART No. 305390 305445 173024 163029 305496 305470 301970 A03285 305437 A12106 A01080 A02060 A02110 A02034 2501116 2501054 A02030 2531120 A02049 A02223 - SPARE PARTS LIST DESCRIPTION Handle assembly Cord carrier assembly Cord grip Cord grip ring Clutch control rod Clutch lever Chain cover case Chain cover knob Cord carrier bar Decal- warning Spring pin Nut- 3/8” unf.hex.
  • Page 23 30” QUEEN ITEM PART No. 1 302640 2 164275 3 164267 4 300847 5 303028 6 509819 7 3172749 8 A02044 9 A02169 10 2531160 11 302658 - SPARE PARTS LIST DESCRIPTION Grassbox assembly Rubber pad Pad mount Grassbox screen assembly Height cut setting bar Decal- Scott Bonnar Setscrew- 1/4” x 1” unc.HT. Washer- 1/4” shakeproof Setscrew- 1/4” x 1” unc.hex.
  • Page 25 30” QUEEN ITEM PART No. 1 A80084 2 305584 3 1661150 4 1661775 5 1551265 6 A20207 7 A20206 8 306368 9 1661235 10 303124 11 A20211 12 306341 13 305373 14 A20209 15 A20208 16 301649 17 509819 18 318228 19 2062724...
  • Page 27 30” QUEEN ITEM PART No. 1674306 1661253 306405 655517 655525 655509 A20202 A20203 A20201 10 1661245 11 A20200 12 1551265 13 1661775 14 303124 15 305373 16 A20212 17 306333 18 306368 19 509819 20 301648 21 A02050 22 A02163 23 2061886 24...
  • Page 28: Warranty Conditions

    Product Serial No: ... Date of Purchase: ... Rover Mowers Limited reserves the right to make changes of and add improvements upon its product at any time without notice or obligation. The Company also reserves the right to discontinue manufacture of any product at its discretion at any time.

This manual is also suitable for:

300433Queen 300433Queen 300361
