- Page 1 Owners Manual GRASS CATCHER MODEL No. 108 – 109...
-
Page 2: Table Of Contents
If any point is unclear, contact Rover Mowers Limited or any authorised Rover Mower Service Dealer. Rover Mowers Limited reserves the right to make changes and improvements to its products at any time, without notice or obligation. The Company also reserves the right to discontinue the manufacture of any product at its discretion at any time. -
Page 3: Safety Instructions
Rover Mowers Limited Know your controls. Read the Owners Manual carefully. Learn how to stop the engine quickly in any emergenc y. Do not allow children or people unfamiliar with thes e instructions to use the mower. Do not carry passengers. -
Page 4: Setting Up
"Grass Catcher Selection Chart" (See Section 1. 1 below). Some Rover Ride-on Mowers will need to have a towbar fitted and/or the use of a different mount support bracket before the Rover Grass Catcher can be correctly mounted. These mowers are identified in the chart below by an asterisk * SETTING UP 1.1 Grass Catcher Selection... -
Page 5: Retrofitting 2.1 Cutterhead Modifications
Ride-on Mower Grass Catcher. The mounting position of the rear bumper bar varies between models of Rover ride-on mowers. Due to this configuration the rear bumper bar model 1I0 has three sets of mounting holes in the side mounting flanges, which suit all front engine Ranchers and Lawnking mowers currently manufactured by Rover. -
Page 6: Installing The Support Bracket
Rover ride-on manufactured by Rover. Refer figure 3.2a and 3.2b. To fit the grass catcher to 17 and 18 series Rover ride-on mowers the support mount plate supplied with the grass catcher has to be replaced with the support mount plate part No: A12942 which can be purchased from any Authorised Rover Service Dealer. -
Page 7: Mounting The Grass Gatcher
Rover Mowers Limited 3.5 Mounting the Grass Catcher The grass catcher is supported off the rear towbar of the Rover Rancher, Raider and Lawn King ride-on mowers. Refer figure 3.3. l. Lift the grass catcher assembly onto the mower, positioning the support saddles on the rear towbar on the mower. -
Page 8: Outlet Chute Installation
Rover Mowers Limited 3.8 Outlet Chute Installation WARNING When working on the cutterhead the mower must be: Stationary with the park brake applied The engine switched off The ignition key removed. 1. Raise the stone guard (A) fitted to the mower... -
Page 9: Operation
10. It is recommended that the cutterhead cutting discs be fitted with fluted blades for maximum grass cutting and catching efficiency. Fluted blades are available from Rover service agents and dealers. mowed 4.2 Emptying the Grass Catcher l. Disengage the cutter drive on the mower... -
Page 10: Maintenance 5.1 Cleaning The Grass Catcher
Rover Mowers Limited 5. MAINTENANCE 5.1 Cleaning the Grass Catcher WARNING The mower must be stationary with the park brake applied, the engine switched off, and the ignition key removed. 1. Hose down the outside of the grass catcher to keep it free of debris and any build-up of grass or dirt. - Page 11 Rover Mowers Limited Ride-on Mower Grass Catcher NOTES...
-
Page 12: Warranty Conditions
Warranty Conditions Australia & New Zealand Only Rover Mowers Limited warrant that this machine is free from defects in material and workmanship. This warranty is limited to making good or replacing any part which appears upon inspection by the manufacturer or his agent to be defective in material or workmanship.
