Rotel RHB-200 Connecting And Operating Instructions

Keypad and connecting hub
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CD
TUN
AV
MP3
OFF
V
MUTE
V
RKP-200
Learning Keypad
RHB-200
Keypad Connecting Hub

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHB-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rotel RHB-200

Summary of Contents for Rotel RHB-200

  • Page 1 MUTE RKP-200 Learning Keypad RHB-200 Keypad Connecting Hub...

  • Page 2: Rkp-200/Rhb

    RKP-200/RHB-200 RKP-200 Keypad � � � � MUTE RHB-200 Connecting Hub DC 12V CLONE IN �� �� � � � � ZONE1 ZONE2 IR OUT ZONE1 ZONE2 ZONE3 ZONE3 ZONE4 �� �� ZONE ZONE �� COMMON IR OUT ZONE4 ��...

  • Page 3: Connecting Keypads

    Connecting Keypads ZONE ZONE ZONE ZONE ZONE ZONE MUTE MUTE ZONE1 ZONE2 DC 12V CLONE IN ZONE1 ZONE2 ZONE3 ZONE4 MUTE ZONE ZONE MUTE ZONE ZONE MUTE IR OUT COMMON IR OUT ZONE3 ZONE4 ZONE ZONE MUTE...

  • Page 4: Connecting Rhb-200

    RKP-200/RHB-200 Connecting RHB-200 ����� ������� ������ ������ ������ ��� �� ���� ������������ ������ ������ ������ ����� �� ��� ��� ��� � � � � ����������� ������� ��������� ��������� � � � � � ���� ������������ ��� � �� ������ �...

  • Page 5: Clone Setup

    Clone setup ZONE ZONE MUTE ZONE ZONE MUTE ZONE ZONE MUTE ZONE1 ZONE2 DC 12V CLONE IN IR OUT ZONE1 ZONE2 ZONE3 ZONE4 ZONE3 ZONE4 ZONE ZONE MUTE ZONE ZONE MUTE ZONE ZONE MUTE COMMON IR OUT ZONE ZONE MUTE...

  • Page 6: Table Of Contents

    Connecting the system ... 8 Cable selection Connecting Master Keypads Connecting a Second Keypad Mounting the Keypads Connecting the RHB-200 to a Rotel Receiver Connecting the RHB-200 to Source Components AC Power connection Operating the Keypads ...10 Selecting a component...

  • Page 7: Introduction

    Output Connector A modular RJ-45 jack on the back of the keypad connects the first keypad in a zone to the RHB-200 hub with CAT-5 Ethernet-style cables. Also, used to connect the second keypad in a zone to the first.

  • Page 8: +12V Dc Input

    Cable selection Run 8-conductor CAT-5 Ethernet cabling from each keypad location to the RHB-200 Connecting Hub. Terminate each end of the cables with standard 8- pin RJ-45 modular plugs. Use a “straight-through” wiring code, with the same color wire connected to the same pin on every plug as shown below.

  • Page 9: Mounting The Keypads

    1 IR input on the receiver, labeled EXT REM IR IN on the Rotel RX-1052. 3. Repeat for any additional zones, matching the ZONE 2 IR OUT on the RHB-200 to the ZONE 2 IR IN on the receiver, etc. Connecting the RHB-200...

  • Page 10: Operating The Keypads

    RKP-200/RHB-200 Operating the Keypads The keypads are preprogrammed to operate the Rotel RX-1052 multi-zone receiver and the follow- ing source components: Rotel CD Players: RCD-1072 & RCC-1055 Rotel Tuner: RX-1052 built-in tuner Rotel DVD Player: RDV-1092/RDV-1060 MP3 Players: Navipod and the most popular brands of por-...

  • Page 11: Backlighting

    Configuring the keypads With the default factory configuration, the keypads are ready to use in a system with Rotel compo- nents as described in the Operating the Keypads section of the manual. However, the keypads can be customized in several ways during setup. Op-...

  • Page 12: Disabling Backlighting

    RKP-200/RHB-200 Details of the switch settings are provided with the instructions for each configuration option, but here is a summary: SW1: Used for invisible layer command programming for the CD device. SW2: Used for invisible layer command programming for the TUN device.

  • Page 13: Learning Commands

    SW5 and SW6 in the OFF position: Learning commands The RKP-200 keypad is programmed at the factory with basic commands for Rotel and other compo- nents as described in the Operating the Keypads section of the manual. These commands can be replaced when using non-Rotel components or for access to different features.

  • Page 14: Learning Invisible Layer Commands

    RKP-200/RHB-200 5. Aim the handheld remote at the oval sensor on the front of the keypad from a distance of approxi- mately 1 inch (25 mm). Press and hold the button on the handheld remote with the command to be learned (the PAUSE button, in this example).

  • Page 15: Programming A Smart Sequence

    For ex- ample, the device button is programmed to switch the Rotel receiver to the CD input and be- gin disc play. You can store a new SMART sequence for any device button using the following procedure. In...

  • Page 16: Cloning

    2, Zone 3, and Zone 4 as necessary. The entire cloning process can take up to 10 minutes. 6. If an error occurs, all four LEDs on the RHB-200 flash green six times and the DEVICE buttons on the zone keypads flash on for one second.
  • Page 17 2. Using a small flat blade screwdriver, release the four tabs on the sides of the module, re- leasing the keypad cover. 3. Once the keypad cover has been removed, pull a button off and replace it with one of the optional buttons.
  • Page 18 082 OM RKP-200/RHB-200 ENG 112105 The Rotel Co. Ltd. 10-10 Shinsen-Cho Shibuya-Ku Tokyo 150-0045 Japan Phone: +81 3-5458-5325 Fax: +81 3-5458-5310 Rotel of America 54 Concord Street North Reading, MA 01864-2699 Phone: +1 978-664-3820 Fax: +1 978-664-4109 Rotel Europe Dale Road...
