- Page 1 WEB CAM RCM-3201V user manual...
-
Page 2: Table Of Contents
WEB CAM RCM-3201V user manual Index Package Contents...1 System Requirements...2 The Description for Each Part...3 Web Cam Features...4 Web Cam Specifications...5 Using the Web Cam...6 Install the Hardware...7 Install the Software...8 Setting the Software...11 Uninstall the Software...17... -
Page 3: Package Contents
WEB CAM RCM-3201V Package Contents Web Camera CD Driver - with Video & Frame Effect User’s Manual WEB CAM RCM-3201V user manual Driver Attention RCM-3201V Please install the driver WEB CAM Drivers before the Web Cam installation. user manual... -
Page 4: System Requirements
WEB CAM RCM-3201V user manual System Requirements Windows XPSP2/VISTA Above Mac 10.4.8 above Pentium 4 or faster processor 128 MB RAM 200 MB free hard drive space 24 bit color display adapter Available 2.0 USB port... -
Page 5: The Description For Each Part
WEB CAM RCM-3201V user manual The Description for Each Part Snap Shop Activity Light Lens Hidden Internal Microphone USB2.0 Multi-Flexible Stand... -
Page 6: Web Cam Features
WEB CAM RCM-3201V Web Cam Features Multi-Flexible Stand Any Flat Surface Any Flat Surface Multi-Swivel Design 。 Face Tracking Face Tracking USB Video Class, Plug & Play - Driver Free USB Video Class, Plug & Play - Driver Free For Notebook... -
Page 7: Web Cam Specifications
WEB CAM RCM-3201V user manual Web Cam Specifications Sensor Type: CMOS Native Resolution: 1280X1024 pixels Video Capture: Up to 1280X1024 pixels Still Image Capture: Up to 2560X2048 pixels (With CD Software) Frame Rate: Up to 30fps@640X480 pixels USB Protocol: USB 2.0 UVC... -
Page 8: Using The Web Cam
WEB CAM RCM-3201V Using the Web Cam How to use the Web Cam The web cam is UVC version- "Plug & Play" Under Window Vista It can use the preview function of Web Cam through "MSN", "SKYPE", "QQ" and "YAHOO"... -
Page 9: Install The Hardware
WEB CAM RCM-3201V user manual Install the Hardware Connect the camera USB cable to the USB port. -
Page 10: Install The Software
WEB CAM RCM-3201V Install the Software The driver of "Effect Software" will have extra bonus for "Video Effect" and "Frame Effect” Function. Attention: Please install the Web Cam before the driver installation. The Steps of installation: Step 1. Please install the Web Cam first. - Page 11 WEB CAM RCM-3201V user manual Install the Software 1. Click "Install" to begin the installation 2. Start installation...
- Page 12 WEB CAM RCM-3201V user manual Install the Software 3. Select “Continue Anyway” 4. Select “Finish”...
-
Page 13: Setting The Software
WEB CAM RCM-3201V Setting the Software How to use AMCAP tool : AMCAP is an application that let you capture video in your system. It captures video into an .AVI file. Below is description of AMCAP’s various options and features. - Page 14 WEB CAM RCM-3201V Setting the Software File/Save Captured Video As : Use this to copy the captured data to another file, so you can reuse the same preallocated file for your next capture. Options/preview: Lets you watch the input video that is being recorded in the application windows.
- Page 15 WEB CAM RCM-3201V user manual Setting the Software Options/Video Capture Filter: Adjust various video setting, such as brightness, contrast, etc.
- Page 16 WEB CAM RCM-3201V Settinig the Software Unique Video Effect 1. Particular Video Effect : There are 16 kinds of video effect for choosing. Snipping 2. Special Frame Effect : There are 10 kinds of frame effect for choosing. Newspaper Embossment...
- Page 17 WEB CAM RCM-3201V user manual Setting the Software Options/Video Capture Pin: Choose the video color space and video size. Supported color spaces are RGB24, 1420. Supported size is 160X120, 176X144, 320X240, 352X288,640X480 and 1280X1024.
- Page 18 WEB CAM RCM-3201V Setting the Software Capture/Start Capture : Save the capture file in your computer and select "START" and then "OK" to start capture of video sequence or "Cancel" to cancel the capture. Capture/Set Frame Rate : Where you can set the frame rate you want for preview and video.
-
Page 19: Uninstall The Software
1. Click "Start" from the task bar and choose "Programs" 2. Select "USB Video Device" and follow the instructions. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com/ for complete warranty information and future support for your product. "Uninstall"...
