Summary of Contents for Rosewill RCW-605.
- Page 1 USB TO IDE 2.5”+3.5”+SATA Cable RCW605 User Manual...
-
Page 2: Specifications
USB TO IDE 2.5”+3.5”+SATA Cable RCW605 USB TO IDE 2.5”+3.5”+SATA Cable Compliance • Compliance with Geni, and Genm of Serial ATA II Electrical Specification .0 • Compliance with USB 2.0 (Hi-Speed) electrical specification • Compliance with USB Mass Storage Class Bulk-Only Transport Specification Specifications •... -
Page 3: Package Contents
USB TO IDE 2.5”+3.5”+SATA Cable RCW605 Package Contents RCW-605 User manual X Power adapter X SATA cable SATA to 4 pin power cable Drive disc X Installation . Plug the 2.5” or 3.5” ATA/ ATAPI / SATA device to RCW-605 by IDE or SATA interface. (Please notice the direction of IDE or SATA port) Please check a to d as below. - Page 4 USB TO IDE 2.5”+3.5”+SATA Cable RCW605 c. 3.5" SATA hard drive d. 5.25" ATAPI device ATAPI device 2. Connect the power adapter set. SATA cable User Manual...
- Page 5 USB TO IDE 2.5”+3.5”+SATA Cable RCW605 3. Plug the power adapter to your ATA/ATAPI/SATA device. Please check a to d as below. a. 3.5" ATA b. 2.5" ATA There is no additional power needed for 2.5” HD. c. 3.5" SATA User Manual...
- Page 6 USB TO IDE 2.5”+3.5”+SATA Cable RCW605 d. 5.25" ATAPI 4. Plug the power adapter to power source and turn on the power (Please make sure the voltage is between 00~240V) 5. Plug the USB2.0 cable to PC and wait for PC auto-detection. Driver is needed only in old system such as Windows 98.
- Page 7 USB TO IDE 2.5”+3.5”+SATA Cable RCW605 User Manual 6. LED indicator meaning a. When LED is off, RCW605 is not working now. b. When LED is dim, RCW605 is stand by now. c. When LED is illuminated, the hard dirve is transferring or reading its data now. ( The LED will not be illuminated when RCW605 is working with ATAPI device.)
-
Page 8: Troubleshooting
USB TO IDE 2.5”+3.5”+SATA Cable RCW605 Notification . RCW-605 can support totally two ATA / ATAPI / SATA devices working together in one time. You can connect one 2.5" or one 3.5" ATA/ATAPI and one SATA devices together to your PC. (Only one 2.5"... - Page 9 *Solution:Please disconnect RCW-605 from your PC before system boot up. Connect it to PC after the Windows complete boot up. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com/ for complete warranty information and future support for your product.
- Page 10 www.rosewill.com...
