Summary of Contents for FAAFTECH FT-LVDS-MB2
- Page 1 INSTALLATION MANUAL FT-VIDEO-LVDS REV 020117...
- Page 3 PRESENTATION • Congratulations for purchasing the video interface FT-LVDS-MB2. • Please, read this manual with attention before installing your new device. • Keep this manual with you in order to check the functioning procedures and the security information. • We recommend that a professional, with experience in the field of installation of vehicle devices, is the one to install this interface.
-
Page 4: Dip Switches
UP on cars Class C and GLC DIP 5 DOWN on cars Class A, B, E, CLA, CLS, GLA, GLE and GLS TV and DVD selection FT-TV-1SEG DIP 6 up DIP 7 down TV FAAFTECH FT-TV-1SEGII DIP 6 down DIP 7 down FT-TV-HDII TV LBSAT LBCR-1100... - Page 5 CONNECTIONS Plug in to the Plug in to whip the radio Plug in to Plug in to the BLUE the whip LVDS plug on the radio DATA OUT/ SELECT UPDATE ANTENA IN/OUT Important Notice Check the Quadlock original connector if there is an optic fiber cable. If there is one, you will need to remove it from the original connector and connect it to the interface’s Quadlock connector before plugging it to the radio.
-
Page 6: Accessory Connections
ACCESSORY CONNECTIONS Check an example of an installation with a DVD, TV, front camera in the AV3 input, and a rear camera. Use the auxiliary outputs to power the accessories, such as DVD, TV and camera, in case they are being installed MOBILE MULTI-MEDIA PLAYER Digital TV Receptor... - Page 7 ACCESSORIES FUNCTIONING Follow the steps below in order to access the accessories you have installed on the interface’s AV inputs. 1º Select the FM source and tune in to the 91.7 bandwidth; Note: 91.7 is the default set bandwidth. That can be altered through the Setup Menu (page 11).
- Page 8 ACCESSORIES FUNCTIONING Use the central console iDrive to control the DVD and the TV (compatible models only) by using the following movements: TV COMMANDS DVD COMMANDS iDRIVE MOVEMENT Simple touch 2-seconds Simple touch 2-seconds Spin right Channel + ---------- Track + ---------- Spin left Channel -...
- Page 9 FUNCTIONING OF THE CAMERAS Rear Camera The rear camera will show automatically once you put the car on the reverse gear. When you spin the steering wheel, the parking guide lines will move, showing the approximate direction the vehicle will go to. Important Notice The parking guides are not 100% precise regarding to the way they show.
- Page 10 FUNCTIONING OF THE CAMERAS Camera Viewing You can view the installed cameras at any time by following the steps below: • Press and hold the BACK button on the steering wheel for 3 seconds to view the rear camera; • Simply touch the BACK button to switch between the rear and the front camera (in case both are installed);...
- Page 11 We recommend that you block the video while moving when you use the GPS. The utilization of the video while moving function is strictly forbidden to the driver and restricted to the passengers. FAAFTECH will not be held accountable for any damages caused by the misusage of this function.
-
Page 12: Setup Menu
SETUP MENU Check below how to access the setup menu of the FT-VIDEO-LVDS MB2: 1. Access the AV1 (DVD), AV2 (TV) or AV3 input; 2. After selecting one of those sources, press the iDrive and hold it for about 5 seconds to view the setup menu;... -
Page 13: Idioma (Language)
SETUP MENU AV2: Select the name of the auxiliary input AV2 (TV or AV2). AV3: AV3 – Select to use AV3 as the third audio/video input. NAV – Select to use AV3 as GPS. CAM FRONT – Select to use AV3 as a front camera input. Idioma (Language): PORTUGUES –... -
Page 14: Troubleshooting
TROUBLESHOOTING 1. After installing the interface, the multimedia won’t turn on. • Review the installation process and check if the connections have been done according to the images shown on pages 3 and 4; • Check if the connectors are plugged in tightly and if there are no wires loose on the connectors. -
Page 15: Warranty
WARRANTY FAAFTECH assures their clients a 01 (one) year period against defects in mate- rials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observ- ing the following: 1. -
Page 16: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
