Summary of Contents for Rosewill RSV-R26
- Page 1 Server RSV-R26 User Manual...
- Page 2 Server RSV-R26 A list of mounting parts M4 Screw cap x 10 Washers x 10 M5 x 8L Screws x 18 M4 x 6L Screws x 18 Step 1 Take the sliding rail apart by sliding out the center slide.
- Page 3 Server RSV-R26 Step 2 Install the center slide to both sides of the chassis, then secure the center slides with M4*6L screws. Back-end Attention: 1. Put the center slide right next to the chassis. Align the center slide holes to the chassis＇mounting holes and install all 3 screws for each slide.
- Page 4 Server RSV-R26 Step 4 (type1) Install the latches onto the front-side of the pillar of a rackmount cabinet. Use M5 x 8L screws to secure the L brackets onto the latches (4 places). Please align the screw holes on the pillar with the screw holes on the brackets.
- Page 5 Server RSV-R26 Step 5 Install the chassis with center slides to the cabinet by sliding into the outer slides. 1. Pull the outer slide all the way until it reaches the limit. 2. Install the chassis with center slides to the cabinet by sliding into the outer slides.
- Page 6 Server RSV-R26 Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product. 3. Use M5 square locking nuts that come with the cabinet and M5 Round-capped Phillips screws to secure the chassis to the rackmount cabinet.(4 places)
