- Page 1 Modem RNX-56CX User Manual...
-
Page 2: Table Of Contents
Modem RNX-56CX Contents For AUSTRALIA User Warning ………………….………………………………………………… Caution………………. ……………………………………………………. Introduction Features ………………….………………………………………………… System Requirements ……………………………………………………. Package Checklist ……………………………………………………….. Installation Hardware Installation ……………………………………………………….. Installation Procedure for Windows Vista………………………………… Installation Procedure for Windows XP …………………………………… Installation Procedure for Windows 2000…………………………………. Installation Procedure for Windows ME ……………………………..……... -
Page 3: For Australia User
Modem RNX-56CX For AUSTRALIA User WARNING * Unit shall be connected to the Telecommunications Network through line cord, which meets the requirements of AS/ACIFS008. * This card must be used with the PC screw down lid. * Telecommunications network voltages exist inside the PC and Telecommunication line connection shall be removed before opening the cover. -
Page 4: Introduction
Modem RNX-56CX User Manual Introduction Features This modem supports the following communication standards. ITU-T is also known as CCITT. Data V.92 (Lite) V.90, V.34, V.32bis, V.32, V.22bis, V.21, V.22 Bell 103 & 212A V.44, V.42bis & MNP 5 (Data compression) V.42 & MNP2-4 (Error correction) V.17... -
Page 5: Installation
Once you have completed the hardware installation, switch on your computer and system will complete the installation automatically. The driver for RNX-56CX is included and fully compatible within Vista. Installation Procedure for Windows XP Once you have completed the hardware installation, switch on your computer and put the CD into the CD-ROM. - Page 6 Modem RNX-56CX Please click Control Panel ->Click System. Under System Properties select Hardware->Click Device Manager, click Click Modems->Click right button on Generic Softk56 Modem (Optional) and select: (method 1 or 2 below). User Manual...
- Page 7 Modem RNX-56CX Method 1. Install Confirm Device Removal, click OK Run (CD-ROM) e.g., D:\Driver\WINXP\HXFSETUP (It will install automatically) *Please wait until the windows show the message Found New Hardwared your new Device is ready to use. Method 2. Update Driver The wizard will search for new hardware.
- Page 8 Modem RNX-56CX Install new modem, please click Have Disk. 2.4-1 Click Browse to search for driver files and open it. e.g., (CD-ROM) D:\Driver\WINXP. Than Click OK 2.4-2 Click Next. Click Continue Anyway User Manual...
-
Page 9: Installation Procedure For Windows 2000
Modem RNX-56CX Click finish Installation Procedure for Windows 2000 Once you have completed the hardware installation, switch on your computer and put the CD into the CD-ROM. The wizard will search for new hardware. Click Next. Select Search for a suitable driver for my device (recommended) and click Next. - Page 10 Modem RNX-56CX Select Specify a location and click Next. Click Browse to search for driver files and open it. e.g., (CD-ROM) D:\Driver\WIN2000. Click OK. Windows found the driver of this modem. Click Next. Click Yes for Digital Signature. User Manual...
-
Page 11: Installation Procedure For Windows Me
Modem RNX-56CX Click Finish to complete the installation. Installation Procedure for Windows ME Once you have completed the hardware installation, switch on your computer and put the CD into the CD-ROM. The wizard will search for new hardware. Select Specify the location of the driver (Advanced) and click Next. - Page 12 Modem RNX-56CX Windows found the driver of this modem. Click Next. Click Finish to complete the installation. Windows has found the new hardware for Modem Device, please click Next. Select Search for the best driver for your device (Recommended) and Specify a location.
-
Page 13: Installation Procedure For Windows 98Se
Modem RNX-56CX Windows found the driver of this modem. Click Next. Click Finish to complete the installation. Installation Procedure for Windows 98SE Once you have completed the hardware installation, put the CD into the CD-ROM. The wizard searches for new hardware. Click Cancel. -
Page 14: Modem Dialing Location
Modem RNX-56CX User Manual Modem Dialing Location **If you want to change your dialing location, please follow the instructions and samples: For WIN 2000/XP Please click Control Panel->Phone and Modem Options ->Under Dialing Rules click Edit, and then you can change your location. - Page 15 Modem RNX-56CX On Control Panel/Network Connections, click Create a new connection. Click Next. User Manual...
- Page 16 Modem RNX-56CX Select Connect to the Internet and click Next. Select Set up my connection manually and click Next. User Manual...
- Page 17 Modem RNX-56CX Select Connect using a dial-up modem and click Next. Input ISP Name and click Next. User Manual...
- Page 18 Modem RNX-56CX Input User name, Password and Confirm password, select Use this account name and password when anyone connects to the Internet from this computer. Click Finish to complete manual connection. User Manual...
-
Page 19: Manual Dial-Up Connection Settings (For Vista)
Modem RNX-56CX User Manual Click Dial to connect to Internet. Manual Dial-up Connection Settings (For Vista) 1. open control Panel and click view network status and tasks... - Page 20 Modem RNX-56CX User Manual 2. click Set up a connection or network 3. Select Set up a dial-up connection then click Next...
- Page 21 Modem RNX-56CX User Manual 4. Input Dial-up phone number, User name, Password then click Connect 5. Waiting for Dial-up Connection. System will complete the other steps automatically.
- Page 22 Modem RNX-56CX User Manual...
- Page 23 Modem RNX-56CX User Manual...
- Page 24 Modem RNX-56CX User Manual 6. Once this screen pops out, the internet is connected successfully. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
