- Page 1 LCD Monitor Series 17.0 TFT Active Matrix LCD Panel User’s Manual All Information in this manual may change from time to time without prior notice.
-
Page 2: Table Of Contents
17.0 TFT Active Matrix LCD Panel User Manual Table of Content Table of Content ... …1 Safety Instructions... …2 View of Monitor ... 3 Unpacking... 5 Warning... 5 Optional TV Tuner ... 6 Remote Control ... 6 Cleaning Notes... 7 Precaution ... -
Page 3: Safety Instructions
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT UNCONDITIONED, STORAGE TEMPERATURE ABOVE 40°C, IT MAY DAMAGE THE EQUIPMENT. 10. Adaptor source : a. Channel Well Thecnology, MODEL PAA050F. b. Linearity Electronics co. LTD,MODEL LAD6019AB4 17.0 TFT Active Matrix LCD Panel User Manual English 2... -
Page 4: View Of Monitor
17.0 TFT Active Matrix LCD Panel User Manual View of Monitor Front View (1) Back View (2) English 3... - Page 5 17.0 TFT Active Matrix LCD Panel User Manual View of Monitor Side View (3) Top View (4) English 4...
-
Page 6: Unpacking
Unpacking Thank you for your purchase. Please first check the following package content of the 17” LCD monitor. Contact your dealer or store where you purchased the LCD monitor if anything is missing. 17” TFT LCD Monitor External Univ15 pin D-sub (RGB Analog) input signal cable... -
Page 7: Optional Tv Tuner
17.0 TFT Active Matrix LCD Panel User Manual Optional TV Tuner The 17” LCD monitor optionally supports TV tuner function with the following accessories . It can be purchased separately. Contact your dealer for detail. Optional TV Tuner S-Video Cable Composite Cable Europ PAL System U.S. -
Page 8: Cleaning Notes
Cleaning Notes Be gentle to clean the screen. Never use any kind of corrosiveness chemical dissolvent to clean the screen, it may hurt your screen surface. We suggest that a camel hair brush or a soft, lint-free cloth be used to clean the screen. -
Page 9: Hardware Installation
Hardware Installation Be careful to your LCD monitor. It’s very delicate and easy to break. Turn off LCD’s and PC’s power before installation. Follow the installation step by step described below. Input 【1】 【2】 【1】DC-IN：This is for connecting the power cable 【2】AUDIO-IN：This can be connected to the audio-out connector of any sound resource. -
Page 10: Hardware Installation Step By Step
Hardware Installation Step by Step 1. Turn your monitor upside down carefully with panel facing you to locate all connector port. Plug in signal cable to VGA-IN of the monitor and the other side of the cable to the computer. Connect the audio cable to AUDIO-IN on the monitor, and the other side to computer line out. -
Page 11: Hardware Installation Tv Tuner (Option)
Hardware Installation Step by Step 4. Plug power cord onto DC adapter. 5. Plug the DC cable from power adapter onto the DC-IN on monitor. 6. Congratulations! You have just completed the hardware installation. Hardware Installation TV Tuner (Option) 1. Hardware installation for optional TV tuner of the 17” TFT LCD monitor is described below. - Page 12 Hardware Installation TV Tuner (Option) 2. First, remove the plastic back cover by pushing clips in two sides . 3. Locate pin connector on the TV tuner and the pin connector on monitor indicated. 4. Slide the TV tuner module into the right side of the spare space of the back of monitor, and gently plug the optional TV tuner into the connector mentioned at Step 3 .
- Page 13 Hardware Installation TV Tuner (Option) 5. Screw to fix TV tuner module on the supporting sheet metal and re-install the color back panel. 6. Insert the RCA video signal cable into VIDEO port, and the other side to RCA Video output on sources such as DVD player………. 7.
-
Page 14: Angle Of Inclination
17.0 TFT Active Matrix LCD Panel User Manual Angle of Inclination In normal condition LCD lay back 0˚ ~ 25˚ (positive and negative 2˚) English 13... -
Page 15: Monitor Setup Button
Monitor Setup Button Menu control button Auto Adjust OSD Menu There 5 keys for user to set up the monitor, including “ “AUTO”, ” <▼> Down”, ” <▲> Up”. Please refer to the introduction below. “ Power”: Turn the LCD power on and off. When the power is on, the light turns green, and standby in the color of orange. -
Page 16: Troubleshooting
Troubleshooting If you encounter any trouble in using the monitor, make sure your monitor is properly installed according to the following steps before you call for service. ˙ There is no picture on the screen. Check: 1. Power saving mode. Press any key and move the mouse to deactivate the mode. -
Page 17: Osd (On-Screen Display) Menu Mode (Pc Mode)
17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) Contrast： Adjust the difference between light and dark area. Main menu contrast adjust Clock： Adjust the frequency of the pixel. Main menu clock adjust Phase： Adjust the phase of pixel clock. - Page 18 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) H-Position： Adjust the horizontal position of the display. Main menu H position adjust V-Position： Adjust the vertical position of display. Main menu V position adjust Volume : Adjust of speaker.
- Page 19 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (PC Mode) RGB : Adjust the color temperature. Main menu color temp. adjust EXIT OSD: Save and leave OSD Main menu EXIT adjust H-Position：Adjust the horizontal position of the OSD . V-Position：Adjust the vertical position of the OSD.
-
Page 20: Osd (On-Screen Display) Menu Mode (Tv/Catv Option)
OSD (On-Screen Display) Menu Mode (TV/CATV Option) Option select 1. Press the MENU button to access menu to select TV or CATV. 2. Using MENU again for advanced adjustment selection (channel selection is included). 3. Press Down and Up for choosing different OSD function. 4. - Page 21 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (TV/CATV Option) Tint: Adjust the tint. Video menu HUE Sharpness : Adjust the sharpness. Video menu TV-Monitor Volume : Adjust of speaker. Mute : Speaker soundless Reset : Recall the factory-setting Main menu volume adjust English 20...
- Page 22 17.0 TFT Active Matrix LCD Panel User Manual OSD (On-Screen Display) Menu Mode (TV/CATV Option) CH Searching：Channel select CH Edit：Channel select edit CH Fine Tune：Channel adjustment AIR-CABLE : Ant. / CATV input switching Video menu EXIT. EXIT OSD: Save and leave OSD H-Position：Adjust the horizontal position of the OSD .
-
Page 23: Display Mode
Display Mode Resolution Horizontal Frequency (KHz) 640X350 (50Hz) 640X350 (60Hz) 640X350 (70Hz) 720X400 (50Hz) 720X400 (60Hz) 720X400 (70Hz) 640X480 (50Hz) 640X480 (60Hz) 640X480 (66Hz) 640X480 (72Hz) 640X480 (75Hz) 800X600 (50Hz) 800X600 (60Hz) 800X600 (72Hz) 800X600 (75Hz) 832X624 (75Hz) 1024X768 (60Hz) 1024X768 (70Hz) 1024X768 (72Hz) 1024X768 (75Hz) -
Page 24: Specification
Specification LCD Panel Type Viewing Angle Contrast Ratio Brightness Response Time Display Colors Max Resolution Pixel Pitch Input Signals RGB Analog Video In** Compatibility Connector RGB Analog Audio In Audio Out Power Power AC input Voltage DC input Voltage Consumption Power saving mode Internal Speaker User Interface...
