Remaco AVA-301-IR Installation Manual And Manual

COPYRIGHTS 1998
C
Installation Guide / Manual (AVA-301-IR)
433MHz
All controls support 230V/50Hz
AVA-301 2-Channel Infrared Remote Control
Up button
Stop button
Down button
AVA-301-IR 2Ch
Front View
OPTION
AVA-300 compatible with Electronic Screen Control (ESC+)
Up
button
REMACO TECHNOLOGIES PTE LTD
Battery
AVA-301-IR 2Ch
Back View
ESC+
Electronic Screen Control
UP
DOWN
UP
DOWN
STOP
ESC+
Stop
button
Description
Input Voltage
Emission Frequency
Emission Power
Work Temperature
Emission Distance
Notice: The IR remote should not expose to moisture to
prolong life span of battery. We recommend to replace
with same type of battery as not to affect distance
sensitivity performance of remote control. Remaco
is environmental-friendly company, we strongly
encourage dispose battery in recycling centre.
AVA-ESC+
Down
button
Switch S1
LED1
Jumper CH1: open
C H2: close
A/V Control System
(e.g. AMX / Creston)
End
Website: www.remacotech.com
AVA-301-IR
3V (CR2032)
38KHz
3milliwatt
.
.
-20 C - 70 C
7m on normal condition
AC Power
Input
Motor
ESC PCB
Board
CON3
DN UP STOP COM
Contact Closure
DOWN STOP UP
AVA-200
Wall Switch
V: 5.0
AVA
