Rosen M10 Owner's Manual

10.2" widescreen monitor / dual-zone system controller
Hide thumbs Also See for M10:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
10.2" Widescreen Monitor/
Dual-Zone System Controller
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for Rosen M10

Summary of Contents for Rosen M10

  • Page 1 10.2" Widescreen Monitor/ Dual-Zone System Controller Owner's Manual...

  • Page 3: Notices

    NOTICES NOTICE OF INTENDED USE Rosen Entertainment Systems are designed to enable viewing of video ONLY for rear-seat occupants, and are not intended for viewing by the driver when the vehicle is in motion. Such use might distract the driver or interfere with the driver’s safe operation of the vehicle, and thus result in...

  • Page 5: Table Of Contents

    Table of Contents Notices ... 3 Getting Started... 6 Switching On, Lowering and Adjusting the Screen, Finding the Remote Control Buttons You Need, Listening Over the Vehicle Speakers Introduction ... 8 Changing Display Settings, Using the Dome Lights ... 9 Using the Remote Control ...

  • Page 6: Getting Started

    ENTER (compatible Rosen DVD players only). Note: The DVD controls on the M10 remote control and front panel are compatible only with certain Rosen DVD players. Other players may be connected to the display, but will not be controlled by the remote or front panel buttons.
  • Page 7 Front View of the M10 OPEN button Reset Button OPEN ENTER SOURCE Dome light LCD Screen Infrared transmitter (for headphones) Console-mounted Input Jack Locations Game Controller Jack Auxiliary Input RCA Jacks To Use An External Video Source 1 Connect the RCA audio and video outputs of the device to the RCA inputs of the system.

  • Page 8: Introduction

    INTRODUCTION Congratulations on owning a Rosen M10 WIdescreen Monitor! Here’s a partial list of some things you can do with your M10: · Display high-quality video images from DVD players, video game systems, and other video sources with composite video output.

  • Page 9: Changing Display Settings, Using The Dome Lights

    “Wide”. USING THE BUILT-IN DOME LIGHTS The M10 system has built-in dome lights. In many vehicles, these built- in dome lights replace an original factory dome light which was displaced when the system was installed. The dome lights are controlled by both the Dome Light button on the front panel and by the matching Dome Light button on the remote control.

  • Page 10: Using The Remote Control

    (such as accessing the disc menu while a disc is loading), you’ll see this symbol: If no remote buttons work, your M10 may be set up as a second display for a Rosen A10. If you have an A10 installed, your M10 remote will operate the A10, which is the main system controller.

  • Page 11: Basic Remote Control Buttons

    25 Day/Night This button decreases display brightness for optimum viewing in low light conditions. The M10 system also has an automatic dimming feature which dims display brightness automatically whenever the headlights are on (this feature is not compatible with all vehicles).

  • Page 12: Using Menu And Navigation Buttons, Using Audio Buttons

    Rosen M10 Owner’s Manual USING MENU AND NAVIGATION BUTTONS 13 Source SOURCE This button lets you select an optional DVD/CD player, the optional TV Tuner, DVD Changer, or other optional auxiliary sources, if installed. Note: The Source button on the control panel performs the same function.

  • Page 13: Using Dvd Disc Features

    28 Display Mode DISPLAY MODE This button lets you select from the various screen display modes. Rosen Entertainment Systems • To view widescreen DVD’s, press this button until “WIDE” is displayed on the screen. This uses the full width of the screen.

  • Page 14: Using Wireless Headphones

    Volume Knob Power LED The M10 IR transmitter has two output channels, A and B. Using A and B, the M10 can transmit two different audio programs at the same time. When using optional Rosen AC3072 dual-channel headphones, listeners can switch between Channels A and B.

  • Page 15: Listening Over The Car Speakers

    LISTENING OVER THE CAR SPEAKERS The M10 uses an FM Modulator (FMM) to send audio through the vehicle radio and speakers. To listen over your speakers: 1 Make sure system MUTE is off. Press SPEAKER. “SPEAKER SOUND ON FM _ _ . _” appears. (If “SPEAKER SOUND DIS- ABLED”...

  • Page 16: Using External Sources, Optional Rosen Accessories

    This 10-disc changer plays CDs, DVDs, MP3 files, and Video CDs. It is fully compatible with your system (adapter kit required). R5000-series Rosen single-disc DVD player (R5600, etc.) This series of Rosen DVD players are compatible with the M10’s remote control DVD functions. AC3074 Remote Control This is the original replacement remote control for the M10.

  • Page 17: Adjusting The Screen Angle

    ADJUSTING THE SCREEN ANGLE The Rosen M10 uses an advanced mechanical design to hold the screen at the perfect viewing angle for you, your passengers, and your vehicle. Here’s how to adjust the screen angle: First, press the OPEN button on the front panel, or on the remote.
  • Page 18 Note: Best results are obtained by connecting only widescreen displays to the M10. DVD players can provide either widescreen video or standard, non-widescreen video - they cannot provide widescreen video for one screen and standard video for other screens.

  • Page 19: Using The Dual-Zone Mode And Output B

    USING THE M10 AS A SECOND SCREEN FOR A ROSEN A10 SYSTEM When the M10 is installed as a second screen for the Rosen A10 system, the M10’s infrared headphone transmitters are disabled, and it will not respond to its remote control. The A10acts as the infrared transmitter for both channels A and B.

  • Page 20: Frequently Asked Questions

    Check the battery in the remote control. Remember that the source-unit functions are conly compatible with certain Rosen-brand source units. If the M10 is installed as a second screen for a Rosen A10, the M10 will not respond to its remote, but its remote will control the A10.
  • Page 22 9100385-90 Rev B RES PN © 2004 Rosen Entertainment Systems www.rosenentertainment.com (951) 898-9808 All rights reserved. No part of this publication may be reproduced, stored in a retrieval sytem or transmitted in any form, electronic, mechanical, recording or other means without prior written permission from Rosen.
