Rolls RS80 Specifications

The new RS80 Quartz PLL Synthesized AM/FM Tuner is a single rack space signal source designed for the in-
stall/contractor market. The unit is ideal for schools and business installs where reliability and great sound are
paramount. Programmable 9 - 10 kHz AM centers switching allow the RS80 to be operated in the United States
as well as Europe/Asia.
FEATURES:
• Up to 40 FM and AM stations may be stored
• RDS ( Radio Data System) Display
• Auto Search and Store function
• Headphone output, XLR outputs, and Signal Strength meter
• Switchable between 120 and 230 volt
SPECIFICATIONS
FM SECTION
Tuning Range:
3 dB Limiting:
Image Rejection:
Usable sensitivity mono IHF :
Selectivity:
S/N Ratio at 1 mV Mono :
Stereo:
THD at 1 mV 40 kHz deviation:
Stereo Separation:
Auto Scan Sensitivity:
AM Suppression Mod. :
Frequency Response:
Antenna Input Impedance:
Size:
Weight:
RS80 Digital AM/FM Tuner
AM SECTION
Tuning Range:
87.5-107.9MHz
12dB
IF Frequency:
53dB
Usable Sensitivity:
9dB
Auto Scan Sensitivity:
(-70KHz : +90KHz)
S/N Ratio at 5 mV/M:
52dB
6 dB Bandwidth:
50dB
0.18%
Image Rejection:
28dB
A.C.A. +/- 9 kHz:
23dB
AGC Action:
52dB
THD at 5mV/M:
3dB
Antenna Input Impedance:
75 Ohms
19" x 1.75" x 5"
(48.3 x 4.5 x 12 cm)
7.1 lbs. (3.2 kg)
• Large LCD alpha-numeric display
• Retains presets when power disconnected
• Standard 1 space EIA rack chassis
• Remote included
530 - 1710 kHz (10 kHz increm.)
522 - 1620 kHz (9 kHz increm.)
450KHz
28dB
41dB
46dB
7KHz
42dB
46dB
43dB
0.40%
300 Ohms
5968 South 350 West, Salt Lake City, UT, 84107
(801) 263-9053 FAX (801) 263-9068
info@rolls.com • www.rolls.com
ROLLS Coporation
