Rolls MX41b Specification Sheet

4-channel stereo mixer

Advertisement

INTRODUCTION

Congratulations and thank you for your purchase
of the MX41b. This unit is a stereo, four channel
passive mixer for expanding a console mixer, mix-
ing instruments, cd or cassette players, or other
signal sources. It requires no batteries or other
power source. The unit may be used as a stereo
1-in 4-out box when all controls are set to maxi-
mum.

DESCRIPTION

OUTPUTS: Stereo 1/4" TRS, and stereo 1/8" TRS
jacks for connection to a mixer input or other input
device.
INPUTS 1 - 4: 4 stereo 1/4" TRS, and 4 stereo 1/8"
TRS jacks for connection to line, instrument, or
consumer level devices.
VOLUME 1 - 4: Control the level of the signals
coming from Inputs 1 - 4.

SPECIFICATIONS

Input Impedance: 10K to 47K Ω
Output Impedance: 2.5K to 10K Ω
Gain: -12 dB MAX
Dimensions: 3.6" x 2.7" x 1.42" (W x H x D)
Weight: 1 lb.

SCHEMATIC
