Coleman 5453A Series Instructions For Use

To Clean

• MAINTENANCE DURING EACH USE
• Keep stove area clear and free from
combustible materials, gasoline and other
• Make sure stove is cool.
• Move stove away from flame (including pilot flammable vapors and liquids.
lights) and other ignition sources. • Do not obstruct the flow of combustion and
• Remove propane cylinder from regulator and ventilation air.
• A good flame should be blue with minimal
replace plastic cap on cylinder. (Fig. 7)
yellow tip. Some yellow tips on flames are
acceptable as long as no carbon or soot
deposits appear.
• Wipe clean with soft cloth and mild dish
detergent. Do not use abrasives.
• To check if the gas cylinder is empty,
disconnect the cylinder from the appliance
and shake from side to side. If there is no
sound or movement of liquid, the cylinder
is empty.
• Annual service by an authorised person
is recommend. Or if any of the following
conditions are noticed; incomplete
ignition, appreciable yellow tipping, carbon
Fig. 7
deposition, lifting, floating, lighting back or
objectionable odor.
• Unscrew regulator from stove. (Fig. 8)
• DO NOT use this appliance if it has damaged
or worn seals. DO NOT use this appliance if
it is leaking, damaged or does not operate
properly.
• Check that all seals between the appliance
and the gas cylinder are in place and in
good condition before connecting the gas
cartridge. Remove all transit protection
material.
• DO NOT move the appliance during
operation.
Fig. 8
• Wipe clean with soft cloth and mild household

To Store

cleaner. Do not use abrasives. (Fig. 9)
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open
flames, pilot lights, direct sunlight, other
ignition sources or where temperatures
exceed 120 °F (49 °C).
• The cylinder must be disconnected when the
Fig. 9
stove is in storage.

Things You Should Know

1. It is unsafe and illegal in some places to store
or use propane cylinders of greater than 1.14
kg (2.5 lbs) water capacity (approximately 1 lb.
propane) in occupied enclosures.
2. The usual storage areas for camping and picnic
equipment are the basement, attic, or garage.
To avoid the accumulation of dust, cobwebs,
etc., that is common in these areas, place your
stove in a plastic bag and seal it with a rub-
ber band.
3. If not completely satisfied with the performance
of this product, please call one of the numbers
listed on the cover of this manual.
www.coleman.com
English-5

Parts List

Warranty

No. Part Number Description Limited One Year Warranty
1 5453-2351 Grate
EXPRESS WARRANTY
2 R430-565T Regulator Assembly
Coleman Brands Pty. Ltd. ("Coleman") warrants
3 5453-3351 Foot Assembly (1 pk)
that for a period of one (1) year from the date
4 5453-1001 Carry Case
of original retail purchase, this product will be
(Model 5453-741 only)
free from defects in material and workmanship.
5 5453-1351 Knob
Coleman will, depending on the circumstances,
refund, repair or replace this product or any
component of the product found to be defective
during the warranty period. Replacement
will be made with a new or remanufactured
product or component. If the product is no
longer available, replacement may be made
with a similar product of equal or greater value.
To the extent permitted by law and subject to
1 your non-excludable rights under the Australian
Consumer Law (Schedule 2 to the Competition
and Consumer Act 2010 (Cth)) and the New
Zealand Consumer Guarantees Act, which are
not limited to a one (1) year period, this is your
exclusive remedy for any breach of this limited
warranty or for any other claims otherwise
relating to this limited warranty.
2
In Australia, our goods come with guarantees
that cannot be excluded under the Australian
5
Consumer Law. You are entitled to a
replacement or refund for a major failure
and compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and
3
the failure does not amount to a major failure.
The benefits provided under this warranty are
in addition to and do not affect purchaser's
statutory rights under the Australian Consumer
Law or other rights at law.
This warranty is valid for the original retail
purchaser from the date of initial retail purchase
and is not transferable. Please keep your
proof of purchase documentation, such as the
original sales receipt or the relevant credit card
statement. Proof of purchase is required to
obtain warranty performance. Coleman dealers,
Coleman service centres, or retail stores selling
Coleman ® products do not have the right to
alter, modify or in any way change the terms
and conditions of this warranty. The warranty is
valid only for products that are purchased new
4
and unused in Australia and New Zealand, from
Coleman or Coleman dealers or retailers.
WARRANTY EXCLUSIONS AND
LIMITATIONS
THE AUSTRALIAN CONSUMER LAW
PROVIDES CONSUMERS WITH CERTAIN
'CONSUMER GUARANTEES'. THESE
GUARANTEES APPLY WHERE THE GOODS
AND SERVICES COLEMAN SUPPLIES TO YOU
ARE OF A KIND ORDINARILY ACQUIRED FOR
PERSONAL, DOMESTIC OR HOUSEHOLD USE
OR COST LESS THAN $40,000, AND IN THE
CASE OF GOODS, ARE NOT RE-SUPPLIED BY
YOU. NOTHING IN THIS LIMITED WARRANTY
EXCLUDES, RESTRICTS OR MODIFIES
RIGHTS WHICH YOU HAVE UNDER THE
AUSTRALIAN CONSUMER LAW IN RESPECT
OF THE CONSUMER GUARANTEES AND ALL
OF THE PROVISIONS IN THIS SECTION ARE
TO BE READ SUBJECT TO THE AUSTRALIAN
CONSUMER LAW.
This warranty does not cover: (a)normal wear
of the product and/or its parts; (b) parts that
are not genuine Coleman ® parts, consumables,
lost parts and accessories; (c) damage resulting
English-6
a written description of the problem with the
from any of the following: negligent use or
product, together with your contact name,
misuse of the product, commercial use of
address and telephone number and proof of
the product, use contrary to the operating
purchase.
instructions; disassembly, repair or alteration
Subject to the applicable consumer laws in
by anyone other than Coleman or Coleman
your jurisdiction, you must pay for the costs of
service centre, the use of a part other than a
transporting the product, including packaging,
genuine Coleman ® part; or (d) acts of God,
freight and insurance costs, to an authorised
such as fire, flood, hurricanes and tornadoes.
Coleman retailer or Coleman service centre
To the extent permitted by the Australian
for warranty service. If the warranty claim
Consumer Law, the Competition and
is substantiated and accepted by Coleman,
Consumer Regulation 2010 and the New
Coleman will at its cost, repair or replace
Zealand Consumer Guarantees Act,
any product or parts and return the product
Coleman's liability is limited, depending on
to you. Additionally, if the warranty claim is
the circumstances, to refund, replacement or
substantiated and accepted by Coleman,
repair of Coleman products or components.
®
Coleman will reimburse you for the costs of
For the avoidance of doubt, any and all
transporting the product to an authorized
other warranties or conditions which are not
Coleman retailer or Coleman service
guaranteed by the Australian Consumer Law,
centre. Coleman reserves the right to seek
the Competition and Consumer Regulation
reimbursement for any costs and expenses
2010 and the New Zealand Consumer
incurred for a warranty claim if the product is
Guarantees Act and which are not expressly
found to be in good working order.
included in this warranty as additional
If you have any questions regarding this
warranties or conditions are expressly
warranty please call 1800 224 350 or + 61 2
excluded, including liability for incidental
8762 5000.
or consequential damages caused by the
breach of any express or implied warranty or
Coleman Brands Pty. Ltd.
condition.
ABN 74 091 681 195
MAKING A WARRANTY CLAIM -
Suite W2C1, 75-85 O'Riordan Street,
RETURN TO COLEMAN FOR REPAIR
Sydney Corporate Park, Alexandria, NSW
Take the product to an authorised Coleman
2015
retailer or Coleman service centre as soon
Australia
as the warranty claim arises. You may locate
Telephone: 1800 224 350 or + 61 2 8762 5000
the nearest authorised Coleman retailer or
Email: customerservice@colemanaust.com.au
Coleman service centre by visiting www.
coleman.com or calling 1800 224 350 or + 61
www.coleman.com
2 8762 5000. Please ensure that you provide
Coleman Brands Pty. Ltd.
ABN 74 091 681 195, Suite W2C1, 75-85 O'Riordan Street, Sydney Corporate
Park, Alexandria, NSW 2015, Australia
Telephne: 1800 224 350 or + 61 2 8762 5000
www.coleman.com
© 2016 The Coleman Company, Inc. All rights reserved.
Coleman ® , and are registered trademarks of
The Coleman Company, Inc.
The Coleman Company, Inc., a Jarden Corporation company (NYSE:JAH)
4010051753 (ECN20055731-01)
English-7
Propane Stoves
Instructions for use
© 2016 The Coleman Company, Inc.
5453A Series
www.coleman.com
Standard Ignition
Camp Stove
IMPORTANT
Important. Read these instructions for use carefully. Familiarise
yourself with the appliance before connecting it to its gas container.
Keep these instructions for future reference.
This instruction manual contains important information necessary for
the proper assembly and safe use of the appliance. Follow all warnings
and instructions when using the appliance. If you have questions
about assembly, operation, servicing or repair of this product, please
call Coleman on 1800 224 350. Coleman Brands Pty Ltd. Suite W2C1,
75-85 O'Riordan St, Alexandria, NSW 2015.
Gas cylinders shall be changed in a well-ventilated location, preferably
outside away from people and any sources of ignition, such as naked
ames, pilot ames, electric heaters / equipment. If there is a leak
on your appliance (smell of gas) and you cannot stop the gas ow,
remove the appliance to a well-ventilated location away from any
ignition source. Check for leaks using soapy water. Do not try to
detect leaks using a ame. This appliance must only be serviced by
an authorised person. Gas cylinders must be stored outdoors in a well
ventilated area out of the reach of children, any indoor storage shall
comply with AS/NZS 1596.
This appliance shall only be used with Propane LPG Coleman
disposable gas cylinders certi ed to DOT-39 NRC 232/290 M1110.
OR re llable Propane LPG cylinder certi ed to AS2030 & Coleman
hose assembly. IT MAY BE HAZARDOUS TO ATTEMPT TO FIT OTHER
TYPES OF GAS CONTAINERS. Only use the regulator assembly
as supplied with this appliance for connection to the cylinder or
compatible Coleman hose assembly – DO NOT USE ADAPTORS.
CAUTION: accessible parts may be very hot. Keep young children
away, USE OUTDOORS ONLY. Must only be operated on a horizontal
surface. Not suitable for marine environments. Do not modify this
appliance.
