Roland HP107 Owner's Manual

Roland owner's manual digital piano hp107
Hide thumbs Also See for HP107:
Table of Contents

Advertisement

Quick Links

Download this manual
Before using this unit,
carefully read the sections
entitled: "USING THE
UNIT SAFELY" and
"IMPORTANT NOTES"
(p. 4; p. 6). These sections
provide important
information concerning the
proper operation of the unit.
Additionally, in order to feel
assured that you have
gained a good grasp of every
feature provided by your
new unit, Owner's manual
should be read in its
entirety. The manual should
be saved and kept on hand
as a convenient reference.
Owner's Manual
Thank you, and congratulations on your choice of the Roland Digital Piano HP107.

Main Features

Piano Sounds with Rich Resonance and Wide-ranging Expressiveness
The stereo sampling piano sound generator realistically reproduces even the sound of the
hammers striking the strings, producing the tones of a high-quality concert grand piano.
Maximum polyphony of 128 notes ensures that you can use the pedal freely without running
out of notes.
This instrument is receptive to all the subtle nuances that a performer might use, and skillfully
reproduces them—whether it be slight variations in touch or the resonance in the strings when
the keys are released, or the type of resonance heard when the pedals are released (Piano
Resonance). In addition, this instrument features a "Grand Sound" speaker system, and
simulates the full, three-dimensional nature of a concert grand piano (Grand Space), which
together help to deliver a sound with even greater clarity and power (Dynamic Emphasis).
Pursuing the Playing Feel of a Grand Piano
This instrument features a progressive hammer action keyboard, which duplicates the touch
of a grand piano, with a heavier touch in the lower register, and a lighter touch in the upper
register. In addition, on the HP107, even the distinctive "click" that you feel when pressing a
key on a grand piano has been faithfully simulated (escapement mechanism).
The instrument features two kinds of key touch control; key response, which changes the
keys' apparent weighting, and "hammer response function," which reproduces the piano
hammers' subtle movements. The pedal is designed for good-feeling response, and allows
subtle performance nuances to be expressed.
Expressiveness Only a Digital Instrument Can Provide
The HP107 lets you add just the right sounds to the piano for an effect that is full and rich.
You can layer different instrument sounds over the piano sound, layer sounds one octave
higher, and use a pedal to control the volume.
Comfortable for Use with Headphones
Special effects applied to the sound when headphones are used make listening through
headphones comfortable, not fatiguing. And in addition to an indicator on the Front panel that
lights up when you connect a pair of headphones, the HP107 also provides a convenient hook
where you can keep your headphones when they're not in use.
A Variety of Helpful Practice Features and Built-in Piano Songs
A metronome function and "two-track recorder," the built-in songs for a collection of scores
(60 songs included), and other features let you experience piano lessons in ways possible only
with a digital piano.
Copyright © 2004 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in
any form without the written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading

Related Manuals for Roland HP107

Summary of Contents for Roland HP107

  • Page 1: Main Features

    The HP107 lets you add just the right sounds to the piano for an effect that is full and rich. You can layer different instrument sounds over the piano sound, layer sounds one octave higher, and use a pedal to control the volume.

  • Page 2: Important Safety Instructions

    WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 3: Using The Unit Safely

    • Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.
  • Page 4 • Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.

  • Page 5: Important Notes

    However, in certain cases (such as when circuitry related to memory itself is out of order), we regret that it may not be possible to restore the data, and Roland assumes no liability concerning such loss of data.
  • Page 6 • Do not apply undue force to the music rest while it is in use. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.

  • Page 7: Table Of Contents

    Contents USING THE UNIT SAFELY ...3 IMPORTANT NOTES ...5 Panel Descriptions...10 Front Panel ...10 Rear Panel...11 Bottom Panel...11 Before You Start Playing ...12 Connecting the Pedal Cord...12 Connecting the Speaker Cable ...12 Connect the Power Cord ...12 Setting Up the Music Rest...12 Folding down the music rest...12 Using the music holders...12 Removing the music rest...13...
  • Page 8 Contents What’s MIDI?...48 Making MIDI-related Settings...48 MIDI send channel settings ...49 Switching Local Control on and off...49 Transmitting a performance you recorded ...49 Appendices...50 Troubleshooting ...50 Error Messages/Other Messages...51 Tone List ...52 Built-in Song List...53 Easy Operation List...55 Parameters Stored in Memory Backup ...56 MIDI Implementation Chart...57 Main Specifications ...58 Index...59...
  • Page 9 MEMO...

  • Page 10: Panel Descriptions

    [Play] button Starts and stops playback of built-in songs and recorded performances (p. 15, p. 34). Also starts/stops recording of a performance (p. 37–p. 39). [Rec] button Puts the HP107 in recording-standby mode (p. 36–p. 40). 25 26...

  • Page 11: Rear Panel

    These jacks can be connected to another sound generating device or an audio device, so that the sound of that device will be output from the HP107’s speakers (p. 47). Output jacks Allows you to output the piano’s sound to sound reinforcement equipment to obtain a more powerful sound.

  • Page 12: Before You Start Playing

    Before You Start Playing Connecting the Pedal Cord Insert the pedal cord into the Pedal connector on the rear panel of the HP107. fig.00-01 Connecting the Speaker Cable As shown in the diagram, connect the speaker cable leading from the speaker box of the stand to the speaker connector located on the rear bottom of the HP107.

  • Page 13: Removing The Music Rest

    Attaching the Headphone Hook Press and twist the headphone hook included with the HP107 into the hole in the bottom of the HP107 (refer to the figure below). Turn the wing nut of headphone hook to secure the headphone hook.

  • Page 14: Turning The Power On And Off

    To turn the power off, turn the [Volume] knob all the way to the left, and press the [Power On] switch. The Power indicator at the left front of the HP107 will go dark, and the power will be turned off.

  • Page 15: Chapter 1. Enjoying The Built-In Songs

    Chapter 1. Enjoying the Built-in Songs Listening to Built-in Songs The HP107 comes with 68 piano songs onboard. ■ Playing back all songs continuously (All Song Play) The built-in songs can be played back consecutively. fig.panel1-1 Hold down the [Song/Tempo] button, and press the [Play] button.

  • Page 16: Listening To The Demo Songs

    Chapter 1. Enjoying the Built-in Songs Press the [-] or [+] button to select a song. Holding down the button causes the numbers to change continuously. Playing back Press the [Play] button. The button’s indicator will light, and the selected song will play. Stopping the playback Press the [Play] button.

  • Page 17: Listening To A Demo Of The Functions

    ■ Listening to a Demo of the Functions You can listen to the demo of the functions that can be applied to the piano tones. Press the [Demo] button. The button’s indicator flashes, and playback of the tone demo songs starts. Press any of the following buttons.

  • Page 18: Chapter 2. Performance

    Chapter 2. Performance Performing with a Variety of Sounds The HP107 contains 36 different built-in tones. The tones are organized into five tone groups, which are assigned to the Tone buttons. fig.panel2-1 Selecting a tone group Press any Tone button.

  • Page 19: Making Fine Adjustments To The Piano Sound (Piano Resonance)

    More resonance effect is applied as the value is increased. Chapter 2. Performance You can save this setting in the HP107’s memory using the Memory Backup function (p. 45). For more about the tones with which this setting is enabled, refer to the “Tone List”...

  • Page 20: Having Resonance Played When You Press The Damper Pedal (Damper Resonance)

    On an acoustic piano, depressing the damper pedal makes the notes you play resonate with other strings, adding rich reverberations and fatness to the sound. The damper pedal on the HP107 recreates this resonance (damper resonance) when depressed. Hold down the Piano Resonance [Damper] button, getting its indicator to light.

  • Page 21: Adjusting The Keyboard Touch (Key Touch)

    Dynamic fingering adds even more feeling to what you play. Sounds at a fixed volume, regardless of your keyboard playing strength. Chapter 2. Performance You can save this setting in the HP107’s memory using the Memory Backup function (p. 45).

  • Page 22: Changing The Timing Of Sounds According To The Force Used To Press The Keys (Hammer Response)

    The Hammer Response function is cancelled. All Indicators The sound is played immediately, regardless of the force with which the keys are played (velocity). Setting You can save this setting in the HP107’s memory using the Memory Backup function (p. 45).

  • Page 23: Adding A Sense Of Depth To The Sound (Grand Space)

    Adding a Sense of Depth to the Sound (Grand Space) The HP107 includes a “Grand Space” function that allows you to get sounds that have a sense of depth like you get by playing an acoustic piano. Using this function gives you the natural-sounding reverberation and breadth of sound that an acoustic piano provides.

  • Page 24: Adding The Right Sense Of Depth For Headphones (Grand Space)

    You can adjust the sense of depth to any of four levels. A greater sense of depth is produced as the value is increased. You can save this setting in the HP107’s memory using the Memory Backup function (p. 45).

  • Page 25: Adding Liveliness To The Sound (Dynamic Emphasis)

    Produces a sound with chords in the low registers that are clear and distinct. Creates a sound with boosted bass. Description Chapter 2. Performance You can save this setting in the HP107’s memory using the Memory Backup function (p. 45).

  • Page 26: Applying Effects To The Sound

    Higher values will produce a deeper effect. You can save the reverb on/off setting as well as the setting for the amount of reverb applied in the HP107’s memory using the Memory Backup function (p. 45). You can save separate chorus effect on/off settings to each tone individually.

  • Page 27: Transposing The Key Of The Keyboard (Transpose)

    Transposing the Key of the Keyboard (Transpose) By using the “Transpose function,” you can transpose your performance without changing the notes you play. For example, even if the song is in a difficult key with numerous sharps ( ) or flats ( to play.

  • Page 28: Layering Complementary Sounds With The Piano Tones (Acoustic Layering)

    Chapter 2. Performance Layering Complementary Sounds with the Piano Tones (Acoustic Layering) With the HP107, you can easily select the perfect tones to complement the piano tone and play together with the piano tone. This feature is called the “Acoustic Layering function.”...

  • Page 29: Playing Two Sounds Together (Dual Performance)

    You can change the pitch of the tone of the right button in octave steps (p. 43). You can save this setting in the HP107’s memory using the Memory Backup function (p. 45). You can also change the volume balance by holding...

  • Page 30: Playing Different Tones With The Left And Right Hands (Split Performance)

    Chapter 2. Performance Playing Different Tones with the Left and Right Hands (Split Performance) Dividing the keyboard into right-hand and left-hand areas, then playing different sounds in each is called “Split performance.” The boundary key is called the “split point.” fig.splitpoint.e …...

  • Page 31: Changing The Keyboard's Split Point

    ■ Changing the keyboard’s split point You can change the location where the keyboard is divided (the split point) within the range of B1 through B6. While continuing to hold the [Split] button, press the key that you want to specify as the split point. The key you pressed becomes the split point, and belongs to the left-hand section of the keyboard.

  • Page 32: Using Metronome

    Chapter 2. Performance Using Metronome ■ Sounding the metronome The HP107 features a built-in metronome. While a song plays back, the metronome will sound at the tempo and time signature (Beat) of that song. fig.panel2-4 Sounding the metronome Press the [Metronome/Count In] button.

  • Page 33: Changing The Metronome Volume

    ■ Changing the metronome volume The volume of the metronome can be adjusted, with ten volume levels available. While holding down the [Metronome/Count In] button, press the [-] or [+] button. The currently specified volume will be displayed. Continue to hold down the [Metronome/Count In] button, and press the [-] or [+] button to sound the metronome, and change the volume.

  • Page 34: Playing Along With The Built-In Songs

    Sounding a “count sound” leading up to playback of a song is called “Count-In.” On the HP107, if you playback a song while the metronome is sounding, two measures of lead-in count will be heard at the beginning of the song.

  • Page 35: Playing Each Hand Separately

    Playing Each Hand Separately The built-in songs allow you to select the performance part that will be played back. The left-hand performance of the built-in songs is assigned to the [Left] button, while the right-hand performance is assigned to the [Right] button. The place where each part of the performance is held is called a “track,”...

  • Page 36: Chapter 4. Recording Your Performance

    ■ Notes regarding recording • Only one song can be recorded. • The HP107 includes a “Song Backup function” (p. 45), which allows you to store the song recorded with the HP107 in the instrument itself. Recorded performance that have not been backed up with Song Backup is erased with the power is turned off.

  • Page 37: Recording A New Song

    The HP107 includes a “Song Backup function” (p. 45), which allows you to store the song recorded with the HP107 in the instrument itself.

  • Page 38: Recording Along With A Song

    Press the [Play] button. You will hear the recorded performance. Once again press the [Play] button, and playback will stop. The HP107 includes a “Song Backup function” (p. 45), which allows you to store the song recorded with the HP107 in the instrument itself.

  • Page 39: Selecting And Recording The Track For Each Hand Separately

    Selecting and Recording the Track for Each Hand Separately The recorder of the HP107 has two recording tracks, allowing you to record the right and left hands separately. Use the [Left] button or [Right] button to specify the recording track.

  • Page 40: Erasing Recorded Performances

    Chapter 4. Recording Your Performance Erasing Recorded Performances You can erase a recorded performance. ■ Erasing a performance from the specified track You can select a recorded track and erase it. Hold down either the [Left] or [Right] button, and press the [Rec] button. The indicator of the button you pressed will go dark, and the performance of the selected track will be erased.

  • Page 41: Chapter 5. Changing Various Settings

    How to enter function mode Hold down the [Split] button, and press the [Chorus] button. The HP107 switches to the function mode. The indicators for the [Split] and [Chorus] buttons and the button to which the function is assigned start flashing.

  • Page 42: Tuning To Other Instruments' Pitches (Master Tuning)

    Factory setting 440.0 Hz This setting remains in effect until you turn off the power. → You can save this setting in the HP107’s memory using the Memory Backup function (p. 45). ■ Changing the temperament You can play classical styles such as Baroque using historic temperaments (tuning methods).

  • Page 43: Setting The Tuning Curve (Stretch Tuning)

    Factory setting → This effect works only with the piano tones. → You can save this setting in the HP107’s memory using the Memory Backup function (p. 45). ■ Changing the Pitch by Octaves (Octave Shift) You can change the pitch of the left tone in Split Play (p.

  • Page 44: Disabling Everything Except Piano Play (Panel Lock)

    Chapter 5. Changing Various Settings Disabling Everything Except Piano Play (Panel Lock) The “Panel Lock” function locks the HP107 in a state where only piano performance can be used, and all buttons will be disabled. This prevents the settings from being inadvertently modified even if children press the buttons accidentally.

  • Page 45: Remembering The Settings Even When The Power Is Turned Off (Memory Backup)

    (Song Backup) Normally, any songs you have recorded are deleted when you turn off the power to the HP107. However, if you wish, you can have such recorded songs be saved even while the power is turned off. This function is called “Song Backup.”...

  • Page 46: Using The V-Link Function

    Chapter 5. Changing Various Settings Using the V-LINK function Connecting the HP107 to a V-LINK compatible image device allows you to control the images with the HP107. V-LINK V-LINK ( ) is functionality promoted by Roland that allows linked performance of music and visual material.

  • Page 47: Chapter 6. Connecting External Devices

    * Use a USB cable no longer than 3 meters. * Turn on the power to the HP107 before starting up MIDI applications on the computer. Do not turn the HP107 on or off while any MIDI application is running.

  • Page 48: Connecting Midi Devices

    MIDI HP107 * Set Local Off if you have connected the HP107 to a MIDI sequencer. Refer to “Switching Local Control on and off” (p. 49). Also set your MIDI sequencer to MIDI Thru mode (so that messages received at MIDI IN will be re-transmitted without change from MIDI OUT).

  • Page 49: Midi Send Channel Settings

    * The HP107 receives all channels 1–16. * When using the HP107 in Dual mode (p. 29) or Split mode (p. 30), the left hand of the performance is transmitted on Channel 5 in Dual mode and in on Channel 3 in Split mode.

  • Page 50: Appendices

    Is the panel locked? (p. 44) Turn the power off, then back on. work Is the volume level of the HP107 turned all the way down? (p. 14) Are headphones plugged in? (p. 13) Has a plug remained connected to the Phones...

  • Page 51: Error Messages/Other Messages

    When listening through speakers: Here, a different cause (such as resonance produced by the HP107) would be suspect. Consult your Roland dealer or nearest Roland Service Center. Error Messages/Other Messages Display Usr.

  • Page 52: Tone List

    Tone List Piano Grand Piano 1 Mellow Piano 1 Honky-tonk Mellow Piano 2 Grand Piano 2 Detuned Piano Rock Piano E.Piano Electric Piano 1 Electric Piano 2 Vibraphone Morning Lite Celesta Electric Grand Harpsichord Harpsichord 1 Nylon Guitar Harp Coupled Harpsichord Harpsichord 2 Organ Church Organ 1...

  • Page 53: Built-In Song List

    Türkischer Marsch (Mozart) S. 42 Ständchen S. 43 Humoreske Composer Copyright F. Chopin © 2004 Roland Corporation C. Debussy © 2004 Roland Corporation F. Liszt © 2004 Roland Corporation F. Chopin/ © 2002 Roland Corporation Arranged by John Maul John Maul ©...
  • Page 54 Having been a product specialist for Roland U.K., John is now actively involved in music software composing/programming for both Roland Japan and various music publishers. Quite recently his “Musical Picture Book,” a volume of original piano music encompassing all standards of musical ability, which included the piano and orchestral accompaniment data in SMF format, was published and printed.

  • Page 55: Easy Operation List

    Easy Operation List You want to Hold down the [Split] button and press the [Piano] button. Twin Piano Press the [Split] and [Chorus] buttons simultaneously, and press the [●] button. Local Control MIDI send channel settings USB Driver Setting Grand Space Mode Master Tuning Selecting a temperament Specifying the keynote...

  • Page 56: Parameters Stored In Memory Backup

    Parameters Stored in Memory Backup Piano Tone-Related Settings in Effect When the Power is Turn On Other Settings Key Off Resonance (On/Off, Volume) String Resonance (On/Off, Depth) Damper Resonance (On/Off, Depth) Key Touch Hammer Response Temperament (Temperament, Tonic) Stretch Tuning Grand Space (On/Off, Depth) Dynamic Emphasis (On/Off, Depth) Master Tuning...

  • Page 57: Midi Implementation Chart

    MIDI Implementation Chart DIGITAL PIANO Model HP107 Function... Basic Default Channel Changed Default Mode Messages Altered Note True Voice Number : Note ON Velocity Note OFF After Key’s Touch Ch’s Pitch Bend 0, 32 6, 38 Control Change 100, 101...

  • Page 58: Main Specifications

    Weights 79 kg / 175 lbs (including Piano Stand) Owner’s manual, Roland 60 Classical Piano Masterpieces, USB Installation Guide, Accessories CD-ROM (Roland Digital Piano USB Driver), Power Cord, Headphone Hook In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.

  • Page 59: Index

    Index AC inlet ... 12 Acoustic Layering ... 28 Adjuster ... 14 All Song Play ... 15 Audio Equipment ... 47 Beat ... 32 [Brilliance] knob ... 14 Built-in Song ... 15 Chorus ... 26 Depth ... 26 Count-In ... 34 Damper pedal ...
  • Page 60 Index USB Connector ... 47 USB Driver ... 46 Variation tone ... 18 V-LINK ... 46 Volume ... 14 Metronome ... 33 [Volume] knob ... 14...
  • Page 61 MEMO...
  • Page 62 Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below. PHILIPPINES AFRICA G.A. Yupangco & Co. Inc. EGYPT 339 Gil J. Puyat Avenue Makati, Metro Manila 1200, Al Fanny Trading Office...
  • Page 63 This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 64 This owner’s manual is printed on recycled paper. 03670601 ’05-8-2N...
