Owner's Manual
Thank you, and congratulations on your choice of the Roland Workstation GW-7.
201a
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" and "IMPORTANT
NOTES" (p. 2–3; p. 4). These sections provide important information concerning the proper operation of
the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature provided
by your new unit, Owner's manual should be read in its entirety. The manual should be saved and kept on
hand as a convenient reference.

Conventions Used in This Manual

Operating buttons are enclosed by square brackets [ ]; e.g., [ENTER].
Reference pages are indicated by (p. **).
The following symbols are used.
This indicates an important note; be sure to read it.
This indicates a memo regarding the setting or function; read it as desired.
This indicates a useful hint for operation; read it as necessary.
This indicates information for your reference; read it as necessary.
This indicates an explanation of a term; read it as necessary.
202
Copyright © 2005 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.
1
2

Advertisement

Table of Contents
loading

Related Manuals for Roland GW-7

Summary of Contents for Roland GW-7

  • Page 1: Conventions Used In This Manual

    Owner’s Manual Thank you, and congratulations on your choice of the Roland Workstation GW-7. 201a Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (p. 2–3; p. 4). These sections provide important information concerning the proper operation of the unit.

  • Page 2: Using The Unit Safely

    • When using the unit with a stand recommended by Roland, the stand must be carefully placed so it is level and sure to remain stable. If not using a stand, you still need to make sure that any location you choose for placing the unit provides a level surface that will properly support the unit, and keep it from wobbling.
  • Page 3 The unit and the AC adaptor should be located so their location or position does not interfere with their proper ventilation. 101c • This unit is for use only with Roland stand KS-12. Use with other stands is capable of resulting in instability causing possible injury. 102d •...

  • Page 4: Important Notes

    • Unfortunately, it may be impossible to restore the contents of data that was stored in the unit’s memory, another MIDI device (e.g., a sequencer), or on a computer once it has been lost. Roland Corporation assumes no liability concerning such loss of data.

  • Page 5: Table Of Contents

    MIDI Channels ... 26 MIDI Parameters... 26 Bulk Dump ... 27 Bulk Load... 27 Using the GW-7 as a MIDI Sound Module ... 27 Troubleshooting ... 28 Power Does Not Turn On... 28 No Sound from the GW-7... 28 No Sound from a Specific Part... 28 No Sound from a Connected MIDI Device...

  • Page 6: Panel Descriptions

    Panel Descriptions Front Panel VOLUME knob This knob controls the volume of the entire GW-7. D Beam controller You can use this controller simply by moving your hand above it. (p. 16) ASSIGNABLE buttons You can use these buttons to turn the D Beam controller on/off, or to select the D Beam function.

  • Page 7: Rear Panel

    Use these buttons to select tones by category. (p. 9–11) Rear Panel USB connector Use a USB cable to connect the GW-7 to your computer via this connector. (p. 24) MIDI OUT/IN connectors Connect MIDI devices to these connectors. (p. 26)

  • Page 8: Introduction

    About the GW-7 What is a Tone? (p. 11) On the GW-7, each of the sounds you normally play is called a “Tone.” If we use the analogy of an orchestra, a Tone corresponds to an instrument played by one of the musicians.

  • Page 9: Connecting The Ac Adaptor

    Playing Sounds from the Keyboard (Keyboard Mode) Immediately after you turn on the power, the GW-7 will be in a state where you can use the entire keyboard to play a piano sound. The GW-7’s keyboard can operate in one of the following three modes.

  • Page 10: Using Split Mode

    ] to get the screen to indicate “Factory Reset?” Press [ENTER]. The screen will prompt “Sure?” Press [ENTER] to initialize the GW-7. If you press [EXIT] instead, you’re returned to the previous screen and no initialization takes place. Once the initialization is complete, the previous screen will reappear.

  • Page 11: Keyboard Mode Functions

    Keyboard Mode Functions Selecting the Tone for the Keyboard Mode The GW-7 contains 657 different Tones. You can use these Tones in the three keyboard modes (Main, Split, Dual) (p. 9). Selecting a Tone Press MODE [TONE] so the button is lit.

  • Page 12: Editing A Tone

    Keyboard Mode Functions Editing a Tone You can turn the C1/C2 knobs to edit the currently selected Tone (including drum set Tones). After editing a Tone, you can save it in user memory. For example, if the KEYBOARD [SPLIT] and [UPPER] buttons are lit, the following procedure will edit the Tone for the Upper Part of Split mode.

  • Page 13: Other Functions

    Using the GW-7 as a MIDI Keyboard Controller You can change the MIDI channel transmitted by the keyboard. This is convenient when you’re using the GW-7 with an external computer, sequencer, or sound module. Hold down [SHIFT] and press MODE [SONG] so the button is lit.

  • Page 14: Playing With An Accompaniment (Backing)

    Turn the knob toward the left to make the backing louder. If you want to adjust the volume of the entire GW-7, turn the VOLUME knob. Adjusting the Tempo Press [TAP TEMPO].

  • Page 15: Selecting A Music Style

    Turn the VALUE dial to step through the styles one by one, and then press [ENTER]. Adding Music Styles Use a USB cable to connect the GW-7 to your computer. (p. 24) Copy music style files from your computer to the user memory of the GW-7.

  • Page 16: Performance Functions And Effects

    If you turn off the power while the D Beam setting screen is displayed, the D Beam setting you chose will not be remembered by the GW-7. You must press [EXIT] before you turn off the power. A performance using a function that produces a sound such as...

  • Page 17: Pitch Bend And Modulation

    Assignable Pedal You can connect a separately available foot switch (Boss FS-5U) or a separately available expression pedal (Roland EV-5) to the CONTROL PEDAL jack on the rear panel. You can assign a variety of functions to this pedal. For details, refer to “Pedal”...

  • Page 18: Performance Parameters

    Performance Functions and Effects Performance Parameters Parameter Range Explanation Kbd Velo Sw OFF, ON Specifies whether the loudness of the notes you play from the keyboard will be fixed (OFF) or not (ON). Kbd Velocity 1–127 Specifies the loudness of each note when the above “Kbd Velo Sw” is OFF. Split Point 36–96 Specifies the split point (the key at which the keyboard will be divided) used in Split mode.

  • Page 19: Using Effects

    Using Effects The GW-7 contains built-in reverb, chorus, and multi-effect (MFX) processors. You can choose an effect type for each processor. Adjusting the Reverb or Chorus Send Level Press ANALOG MODIFY [SELECT] so EFFECT is lit. Turn the C1 (REVERB) or C2 (CHORUS) knob.

  • Page 20: Multi-Effect List

    Performance Functions and Effects Multi-Effect List MFX will not be applied. Controls the harmonic structure of the high- ENHANCER frequency portion of the sound, adding sparkle and improving the definition. OVERDRIVE 1–4 Produces a natural-sounding distortion typ- ical of a vacuum tube amplifier. 1: Small amp 2: Built-in type 3: Large double-stack amp...

  • Page 21: Song Functions

    The contents are preserved even when Sng99 you switch off the GW-7’s power. Recording a Song You can use the 16-track recorder of the GW-7 to record your own performances. The following four recording modes are available. Recording a new song Keyboard performance and backing are all recorded simultaneously.

  • Page 22: Punch-In/Out

    If you want to re-record again, continue from step 3. Using a Foot Switch to Punch-In/Out You can use a separately available pedal switch (Roland DP Series), foot switch (Boss FS-5U) to start and stop recording. This lets you play using both hands, or lets you use your left hand to operate pitch bend/modulation while you play the melody with your right hand.

  • Page 23: Selecting And Playing A Song

    Minus-One Playback You can mute (silence) a desired track of the song. For example, if you’ve copied an SMF (Standard MIDI File) to the GW-7, you can mute one of the tracks, and play that part yourself on the keyboard.

  • Page 24: Usb Functions And System Functions

    USB Functions and System Functions Transferring Files via USB The GW-7 can send and receive music styles and song files via a USB connection with your computer. You must not perform the following actions while the GW-7's [USB] button is lit or while files are being sent or received. If you perform these actions, your computer may freeze, or the files in the GW-7's memory may be damaged.

  • Page 25: System Parameter Functions

    Refer to “Local Ctrl (Local Control)” (p. 26). Master Tune 427.4–452.6 Hz Adjusts the tuning of the entire GW-7. The displayed value is the frequency of the A4 key (middle A). Transpose -12–+12 Transposes the pitch of the GW-7 in semitone steps.

  • Page 26: Midi Functions

    The GW-7’s MIDI connectors allow it to transmit performance data to, and receive such data from other devices. You can use the GW-7 in a wide range of ways by connecting external devices to these connectors.

  • Page 27: Bulk Dump

    Bulk Dump The GW-7’s User Tone data and User Performance data can be sent via MIDI and saved on an external sequencer or other MIDI device. Make settings on your external sequencer so that it is ready to record normal performance data, and perform the following steps on the GW-7.

  • Page 28: Troubleshooting

    Troubleshooting This section provides points to check and actions to take when the GW-7 does not function as you expect. Refer to the appropriate section for the problem you are experiencing. Power Does Not Turn On Is the included AC adaptor/power cord correctly connected to an AC outlet and to the GW-7? (p.

  • Page 29: Sound Is Distorted

    Pitch Is Wrong For some tones, the pitch in certain ranges may sound different than other tones. Could the tuning of the GW-7 be incorrect? Check the Master Tune setting. (p. 25) Could the pitch have been changed by pedal...

  • Page 30: Tone Lists

    Tone Lists Button Tone Category PIANO St.Piano 1 PIANO EuropeanPf PIANO Piano 2 PIANO Honkytonk PIANO Piano 1 PIANO St.Piano 2 PIANO Piano 3 PIANO EG+EP 1 PIANO EG+EP 2 PIANO St.Piano 3 PIANO OldUpright PIANO E.Piano 1 ELECTRIC PIANO St.Soft EP ELECTRIC PIANO Dyno EP...
  • Page 31 Button Tone Category GUITAR/ Mt Dist Bs ELECTRIC GUITAR BASS Funk Pop ELECTRIC GUITAR Funk Gt ELECTRIC GUITAR Jazz Man ELECTRIC GUITAR Gt Pinch ELECTRIC GUITAR Dist Gt 2 ELECTRIC GUITAR Dazed Gt ELECTRIC GUITAR Feedback 1 ELECTRIC GUITAR Feedback 2 ELECTRIC GUITAR Power Gt 2 ELECTRIC GUITAR...
  • Page 32 Tone Lists Button Tone Category SAX/ Alto Sax 2 BRASS Hyper Alto Tenor Sax2 Velo Tenor Flute Vib WIND Piccolo WIND Oboe WIND Bassoon WIND Clarinet WIND Pan Flute WIND Whistle WIND EnglshHorn WIND JzClarinet WIND BsClarinet WIND Flute WIND Recorder WIND Ocarina...
  • Page 33 Button Tone Category SYNTH CelestlPad Ancestral Prologue Goblin 50s Sci-Fi Echo Drops Echo Bell Echo Pan 1 Echo Pan 2 Big Panner WaterPiano StarTheme2 WORLD 1 SitarDrone WORLD 1 Sitar 3 WORLD 1 Sarod WORLD 1 Erhu WORLD 1 Erhu/Vib WORLD 1 Erhu/Harm WORLD 1...
  • Page 34 Tone Lists Button Tone Category WORLD 2 HorseGallp Telephone2 Helicopter Car Engine Car-Pass Siren Train Applause 1 Laughing Screaming Explosion Breath Nz FlKeyClick Seashore Rain Stream Bubble Kitty Growl Telephone1 Door Creak Door Scratch 1 Scratch 2 WindChimes Car-Stop Car-Crash Jetplane Starship Burst Nz...

  • Page 35: Drum Sets

    Drum Sets PC: 1 [CC32: 2] PC: 33 [CC32: 2] PC: 31 [CC32: 2] Standard 1 Jazz Kit 1 New TR-909 ------------ ------------ ------------ ------------ ------------ 909 Kick 3 ------------ ------------ House Kick ------------ ------------ TR-808 Kick C0 12 ------------ ------------ HipHop Kick ------------...
  • Page 36 Drum Sets PC: 94 [CC32: 4] PC: 93 [CC32: 4] PC: 75 [CC32: 4] India Kit Orientl Kit Std Latin ------------ ------------ ------------ ------------ ------------ ------------ ------------ ------------ Mix HH Cl 4 ------------ ------------ Mix HH Cl 1 C0 12 ------------ ------------ Mix HH Cl 2...
  • Page 37 PC: 1 [CC69: 4] PC: 70 [CC32: 4] PC: 71 [CC32: 4] PC: 72 [CC32: 4] TR909 Asia HipHop Asia R&B Asia TechnoAsia ------------ ------------ ------------ ------------ 909 Kick 3 909 Kick 3 909 Kick 909 Kick 3 House Kick House Kick House Kick 909 Kick2...
  • Page 38 Drum Sets PC: 86 [CC32: 4] PC: 89 [CC32: 4] PC: 90 [CC32: 4] D'n'B OR MxKit&Latin MxKt&India ------------ ------------ ------------ 909 Kick 3 ------------ ------------ House Kick ------------ ------------ 909 Kick ------------ ------------ C0 12 HipHop Kick ------------ ------------ SimpleKick ------------ ------------...
  • Page 39 PC: 49 [CC32: 2] PC: 50 [CC32: 2] Orchestra Ethnic ------------ ------------ C1 24 Snare Roll Finger Snap Finger Snap Tambourine Jazz Clsd.HH Castanets Pedal HiHat Crash Cym.1 Jazz Open HH Snare Roll Ride Cymbal Concert Snr Sticks Concert Cym. SquareClick Concert BD Mtrnm.Click...

  • Page 40: Music Styles

    Music Styles Name Tempo Time sign. Rock: SteadyRk PowerRck ElecRock DynoRock ThumpRck USBallad Dance: FeverDnc 80sTekno EuroDnce IbizaDnc KeepOnDc 90sTekno HrdTekno 90sHouse ClubHous Hip'nHop NowHipHp Cool Rap PianoRap 70sDance EasyHop 8Beat: PianoBal Soul Bal ClassBal SimpleBl AlClapBl LayBakBl PoppinBl UKLiteBl UpTempBl SmilePop German P...

  • Page 41: Chord Intelligence ("Mode 1" Setting)

    Chord Intelligence (“MODE 1” setting) ● = Constituent notes of this chord. ★ = Keys you need to press to hear this chord. C#M7 C#m7 CmM7 C#mM7 Cdim C#dim Cm7 ( 5 ) C#m7 ( 5 ) Caug C#aug Csus4 C#sus4 C7sus4 C#7sus4...
  • Page 42 Chord Intelligence (“MODE 1” setting) ● = Constituent notes of this chord. ★ = Keys you need to press to hear this chord. F#M7 F#m7 F#mM7 GmM7 F#dim Gdim F#m7 ( 5 ) Gm7 ( 5 ) F#aug Gaug F#sus4 Gsus4 F#7sus4 G7sus4...
  • Page 43 Workstation MIDI Imprementation Chart Model GW-7 Function... Basic Default 1–16 Channel Changed 1–16, OFF Default Mode 3 Mode Messages Mode 3, 4 (M = 1) Altered ************** Note 0–127 Number : True Voice ************** Note On Velocity Note Off After...

  • Page 44: Specifications

    Specifications GW-7 Workstation Keyboard 61 keys (with velocity) [Sound Generator] Maximum Polyphony 64 voices Parts 16 parts + Keyboard part Wave Memory 32 M bytes (16-bit linear equivalent) Preset Memory Tones: 606 + 256 (GM2) Drum Sets: 51 + 9 (GM2)

  • Page 45: Index

    Index AC Adaptor ... 9 ALL ... 21 ANALOG MODIFY ... 6, 12, 14, 19 ASSIGNABLE ... 6, 16 Attack ... 12 Backing ... 8, 14 BACKING TRACK ... 6, 14–15 Balance ... 14 BAND TYPE ... 6, 14, 23 Bender ...
  • Page 46 Index Screen ... 6, 9 SELECT ... 6 Send Level ... 19 SFX ... 11 SINGLE ... 21 SONG ... 8, 23, 27 SONG CONTROL ... 6 SONG REC ... 6, 21–22 SPLIT ... 9–10 Split Point ... 18 STYLE ... 15 SYNC START ...
  • Page 47 DECLARATION OF CONFORMITY Compliance Information Statement Model Name : GW-7 Type of Equipment : Workstation Responsible Party : Roland Corporation U.S. Address : 5100 S. Eastern Avenue, Los Angeles, CA 90040-2938 Telephone : (323) 890-3700 NOTICE AVIS For EU Countries...
  • Page 48 Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below. PHILIPPINES AFRICA G.A. Yupangco & Co. Inc. 339 Gil J. Puyat Avenue EGYPT Makati, Metro Manila 1200, Al Fanny Trading Office...
