Before using this unit,
carefully read the sections
entitled: "USING THE
UNIT SAFELY" and
"IMPORTANT NOTES"
(p. 4; p. 6). These sections
provide important
information concerning the
proper operation of the unit.
Additionally, in order to feel
assured that you have
gained a good grasp of every
feature provided by your
new unit, Owner's manual
should be read in its
entirety. The manual should
be saved and kept on hand
as a convenient reference.
Owner's Manual
Thank you, and congratulations on your choice of the Roland Digital Piano HP-7/3.
Main Features
Piano sounds with rich resonance and wide-ranging expressiveness
The stereo sampling piano sound generator realistically reproduces even the sound
of the hammers striking the strings, producing the tones of a high-quality concert
grand piano. Maximum polyphony of 64 notes ensures that you can use the pedal
freely without running out of notes.
The HP-7 features a new speaker system to provide sounds with depth and spatial
realism.
Pursuing the playing feel of a grand piano
These instruments feature a progressive hammer action keyboard, which duplicates
the touch of a grand piano, with a heavier touch in the lower register, and a lighter
touch in the upper register. In addition, on the HP-7, even the distinctive "click" that
you feel when pressing a key on a grand piano has been faithfully simulated
(escapement mechanism).
The pedal is designed for good-feeling response, and allows subtle performance
nuances to be expressed.
A variety of practice features to help you develop your musicality
In addition to a metronome, the HP-7/3 features a rhythm function, which
encourages your natural sense of rhythm, and a two-track recorder, which allows
you to experience piano lessons in a way possible only on electronic pianos.
An enjoyable ear-training game is also built-in.
65 piano songs built-in
The built-in songs are mainly classical pieces, and include compositions for listening
enjoyment as well as for lessons. The included music score collection (60 songs) is
also supported.
Piano Customize function lets you adjust details of the sound (HP-7)
This simulates the tonal changes that occur when the lid of a grand piano is opened
or closed, allowing you to play using the piano sound you want.
Adjustable music stand (HP-7)
In addition to allowing you to adjust the angle of the stand, and move it forward or
backward, the music holders accommodates even thick score books.
Copyright © 2002 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in
any form without the written permission of ROLAND CORPORATION.
Advertisement
Table of Contents
Related Manuals for Roland HP-7/3
Summary of Contents for Roland HP-7/3
-
Page 1: Main Features
Owner’s Manual Thank you, and congratulations on your choice of the Roland Digital Piano HP-7/3. Main Features Piano sounds with rich resonance and wide-ranging expressiveness The stereo sampling piano sound generator realistically reproduces even the sound of the hammers striking the strings, producing the tones of a high-quality concert grand piano. -
Page 3: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. -
Page 4: Using The Unit Safely
• Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page. - Page 5 • Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page. • Do not put anything that contains water (e.g., flower vases) on this unit. Also, avoid the use of insecticides, perfumes, alcohol, nail polish, spray cans, etc., near the unit.
-
Page 6: Important Notes
• Do not apply undue force to the music stand while it is in use.(HP-7) • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions. -
Page 7: Table Of Contents
Contents USING THE UNIT SAFELY ...4 IMPORTANT NOTES ...6 Contents...7 Panel Descriptions...8 Front Panel ...8 Rear Panel...9 Before You Start Playing ...10 Connect the Pedal Cable ...10 Connect the Speaker Cable (HP-7) ...10 Connect the Power Cord ...10 Setting Up the Music Stand (HP-3) ...10 Setting Up the Music Stand (HP-7) ...10 Adjusting the position of the music stand...11 Folding down the music stand...11... -
Page 8: Panel Descriptions
(p. 13, p. 25). Also starts/stops recording of a performance (p. 28–p. 31). (Rec)] button Puts the HP-7/3 in recording-standby mode (p. 27–p. 32). [1] button Plays back or records a performance separately for each hand. (p. 26, p. 30–p. 32). -
Page 9: Rear Panel
These jacks can be connected to another sound generating device or an audio device, so that the sound of that device will be output from the HP-7/3’s speakers (p. 36). Output jacks Allows you to output the piano’s sound to sound reinforcement equipment to obtain a more powerful sound. -
Page 10: Before You Start Playing
Speakers Connect the Power Cord Insert the included power cable into the AC inlet on the bottom panel of the HP-7/3, and then plug it into an electrical outlet. NOTE Be sure to use the supplied power cord. -
Page 11: Adjusting The Position Of The Music Stand
NOTE When opening and closing the lid, be careful not to let your fingers get caught. If small children will be using the HP-7/3, adult supervision should be provided. If you need to move the piano, make sure the lid is closed first to prevent accidents. -
Page 12: Turning The Power On And Off
On the HP-7, the softness of the tone can be varied subtly by the depth to which you press the pedal. About the adjuster When you move the HP-7/3 or if you feel that the pedals are unstable, adjust the adjuster located below the pedals as follows. -
Page 13: Enjoying The Built-In Songs And Game
Chapter 1. Enjoying the Built-in Songs and Game Listening to Built-in Songs The HP-7/3 comes with 65 piano songs onboard. ■ Playing back all songs continuously (All Song Play) The built-in songs can be played back consecutively. fig.panel1-1 HP-7 Hold down the [Song/Tempo] button, and press the [ The [Song/Tempo] button’s indicator will light, the [... -
Page 14: Playing The Note-Guessing Game
Chapter 1. Enjoying the Built-in Songs and Game Playing back Press the [ (Play)] button. The button’s indicator will light, and the selected song will play. Stopping the playback Press the [ (Play)] button. The button’s indicator goes out, and playback stops. The next time you press the [ from the beginning. -
Page 15: Chapter 2. Performance
Chapter 2. Performance Performing with a Variety of Sounds The HP-7 contains 24 different built-in tones. The tones are organized into six tone groups, which are assigned to the Tone buttons. The HP-3 contains 20 different built-in tones. The tones are organized into five tone groups, which are assigned to the Tone buttons. -
Page 16: Playing Two Sounds Together (Dual Performance)
Chapter 2. Performance Playing Two Sounds Together (Dual Performance) Simultaneously playing two tones when one key is pressed is called “Dual performance.” Simultaneously press the two Tone buttons that you want to play together. The indicator of the button you pressed will light. When you play the keyboard, the tones of the two Tone buttons you selected will sound simultaneously. -
Page 17: Playing Different Tones With The Left And Right Hands (Split Performance)
Playing Different Tones with the Left and Right Hands (Split Performance) Dividing the keyboard into right-hand and left-hand areas, then playing different sounds in each is called “Split performance.” The boundary key is called the “split point.” fig.splitpoint.e … A0 B0 C1 D1 E1 F1 G1 A1 B1 Left-hand Tone fig.panel2-3... -
Page 18: Changing The Keyboard's Split Point
(F#3). fig.disp-splitpoint Using Metronome and Rhythm ■ Sounding the metronome The HP-7/3 features a built-in metronome. While a song plays back, the metronome will sound at the tempo and time signature (Beat) of that song. fig.panel2-4... -
Page 19: Changing The Metronome And Rhythm Volume
Changing the beat of metronome Hold down the [ (Rhythm)/Beat] button, and press the [+] or [-] button. The currently selected beat will be displayed. If you hold down the [ the beat will change. If you hold down the [ simultaneously, the beat will go back to what it was before you changed it. -
Page 20: Playing Rhythm
Chapter 2. Performance ■ Playing rhythm The HP-7/3 contains 53 different rhythms. The built-in rhythms can be sounded or stopped by pressing a button, in the same way as the metronome. By playing the rhythm instead of the metronome, you can enjoy performing as if you were playing with a session-like feel. -
Page 21: Applying Effects To The Sound
Applying Effects to the Sound fig.panel2-5 HP-7 ■ Adding reverberation to the sound (Reverb) By applying the reverb effect you can produce a pleasant reverberation, making it sound as though you were performing in a concert hall. Press the [Reverb] button. The button’s indicator will light, and a reverb effect will be applied to the sound. -
Page 22: Transposing The Key Of The Keyboard (Transpose)
Chapter 2. Performance Transposing the Key of the Keyboard (Transpose) By using the “Transpose function,” you can transpose your performance without changing the notes you play. For example, even if the song is in a difficult key with numerous sharps ( ) or flats ( to play. -
Page 23: Adjusting The Keyboard Touch (Key Touch)
Adjusting the Keyboard Touch (Key Touch) You can adjust the touch (playing feel) of the keyboard. fig.panel2-7 HP-7 Press the [Key Touch] button. The button’s indicator will light, and the feel of the keyboard will change. Each time you press the [Key Touch] button, the button’s indicator will change color, and the feel of the keyboard will change. -
Page 24: Making Fine Adjustments To The Piano Sound (Piano Customize) (Hp-7)
Chapter 2. Performance Making Fine Adjustments to the Piano Sound (Piano Customize) (HP-7) You can make fine adjustments to the sound of the piano as desired. [Hammer] Button This adjusts how your playing strength will affect the timing at which the note sounds. -
Page 25: Playing Along With The Built-In Songs
Sounding a “count sound” leading up to playback of a song is called “Count-In.” On the HP-7/3, if you playback a song while the metronome is sounding, two measures of lead-in count will be heard at the beginning of the song. -
Page 26: Playing Each Hand Separately
Chapter 3. Playing Along with the Built-in Songs Playing Each Hand Separately The built-in songs allow you to select the performance part that will be played back. The left-hand performance of the built-in songs is assigned to the [1] button, while the right-hand performance is assigned to the [2] button. -
Page 27: Chapter 4. Recording Your Performance
A recorded performance can be played back to hear your own playing, or to add additional parts. The following types of recording can be done using the HP-7/3. • Recording just your own keyboard performance (→ “Recording a New Song” (p. 28)) •... -
Page 28: Recording A New Song
Recording will start when you either press the [ the keyboard. The HP-7/3 counts down two measures, then recording starts. Note that recording will also begin as soon as you play anything on the keyboard, even if you do not press the [ when you start in this manner. -
Page 29: Recording Along With The Rhythm
Recording Along with the Rhythm You can record a performance that uses the Rhythm function. fig.panel4-2 HP-7 As described in steps 1 and 2 of “Recording a New Song” (p. 28), select the song “USr” before you continue. Selecting the tone and rhythm for recording Select the tone that you want to play (p. -
Page 30: Recording Along With A Song
When you want to record the left-hand performance, press the [1] button; to record that of the right hand, press the [2] button. The indicators of the button you pressed and of the [ the HP-7/3 enters recording-standby mode. Starting to record Press the [ (Play)] button. -
Page 31: Selecting And Recording The Track For Each Hand Separately
Selecting and Recording the Track for Each Hand Separately The recorder of the HP-7/3 has two recording tracks, allowing you to record the right and left hands separately. Use the [1] button or [2] button to specify the recording track. -
Page 32: Erasing Recorded Performances
Chapter 4. Recording Your Performance Erasing Recorded Performances You can erase a recorded performance. ■ Erasing a performance from the specified track You can select a recorded track and erase it. Hold down either the [1] or [2] button, and press the [ The indicator of the button you pressed will go dark, and the performance of the selected track will be erased. -
Page 33: Chapter 5. Changing Various Settings
The damper pedal on the HP-7/3 recreates this resonance (sympathetic resonance) when depressed. You can select from eight levels of depth for the resonant sound (resonance level). -
Page 34: Tuning To Other Instruments' Pitches (Master Tuning)
(Master Tuning) In situations such as when playing ensemble with other instruments, you can tune the HP-7/3’s reference pitch to the pitch of another instrument. The standard pitch generally refers to the pitch of the note that’s played when you finger the middle A key. -
Page 35: Setting The Tuning Curve (Stretch Tuning)
Chapter 5. Changing Various Settings Disabling Everything Except Piano Play (Panel Lock) The “Panel Lock” function locks the HP-7/3 in a state where only piano performance can be used, and all buttons will be disabled. This prevents the settings from being inadvertently modified even if children press the buttons accidentally. -
Page 36: Chapter 6. Connecting External Devices
You can use a USB MIDI interface cable (sold separately) to connect the HP-7/3 to your computer. If the HP-7/3 is connected to a computer in which sequencer software such as Roland’s “Visual MT” is installed, a song you’ve recorded on the HP-7/3 can be saved on your computer. -
Page 37: Connecting Midi Devices
MIDI HP-7/3 * Set Local Off if you have connected the HP-7/3 to a MIDI sequencer. Refer to “Switching Local Control on and off” (p. 38). Also set your MIDI sequencer to MIDI Thru mode (so that messages received at MIDI IN will be re-transmitted without change from MIDI OUT). -
Page 38: Midi Send Channel Settings
* The HP-7/3 receives all channels 1–16. * If you are using Dual performance (p. 16) or Split performance (p. 17) on the HP-7/3, only the channel you specify here will be transmitted. If you press the [Strings] button in step 2 of “Making MIDI- related settings,”... -
Page 39: Appendices
Is the panel locked? (p. 35) Turn the power off, then back on. work Is the volume level of the HP-7/3 turned all the way down? (p. 12) Are headphones plugged in? (p. 11) Has a plug remained connected to the Phones... -
Page 40: Error Messages/Other Messages
Roland pianos faithfully simu- abruptly beyond a late such characteristics of the acoustic piano. certain key On the HP-7/3, the range that is unaffected by the damper pedal will change depending on the Key Transpose setting. When listening through headphones:... -
Page 41: Tone List
Tone List [Split] Off Button name Tone [Variation] Dark Grand Piano1 [Piano] Grand Piano2 Green Piano + Strings Orange Piano + Choir Dark Electric Piano1 [E. Piano] Electric Piano2 Green Vibraphone Orange Electric Piano+Choir Dark Harpsichord [Harpsi- Organ Flute chord] Green Harpsichord + Strings Orange... -
Page 42: Built-In Song List
Menuett G dur (Beethoven) d. 43 Venezianisches Gondellied d. 44 Alpenabendröte Composer Copyright C. Debussy © 1995 Roland Corporation F. Chopin/ © 2002 Roland Corporation Arranged by John Maul W. A. Mozart © 1996 Roland Corporation J. Maul © 1998 Roland Corporation F. - Page 43 All rights reserved. Unauthorized use of this material for purposes other than private, personal enjoyment is a violation of applicable laws. Appendices Composer Copyright L. v. Beethoven © 1996 Roland Corporation W. Wagner © 1996 Roland Corporation W. Anderson © 1996 Roland Corporation C.
-
Page 44: Rhythm List
Rhythm List Rhythm Beat Rhythm Name r. 1 2/2 March r. 2 2/2 Swing r. 3 2/2 Voice (Japanese) r. 4 2/2 Voice (English) r. 5 2/2 Animal r. 1 Stick r. 1 2/4 March r. 2 2/4 Country r. 3 Samba r. -
Page 45: Easy Operation List
Easy Operation List HP-7 You want to Press the [Game] and [Key Touch] buttons simultaneously, and press the [●] button. Master Tuning Selecting a temperament Specifying the keynote Stretch tuning Applying the damper pedal to the left-hand keyboard area MIDI send channel settings Local Control Transmitting a recorded performance Hold down the [ ] button and press the [-] or [+] button. -
Page 46: Midi Implementation Chart
Appendices DIGITAL PIANO Model HP-7/3 Function... Basic Default Channel Changed Default Mode Messages Altered Note True Voice Number : Note ON Velocity Note OFF After Key’s Touch Ch’s Pitch Bend 6, 38 Control Change 100, 101 Prog Change : True Number... -
Page 47: Main Specifications
Power Consumption 45 W (HP-3) 1,445 (W) x 524 (D) x 872 (H) mm/56-15/16 (W) x 20-11/16 (D) x 34-3/8 (H) inches (HP-7/3) 1,445 (W) x 524 (D) x 1,085 (H) mm/56-15/16 (W) x 20-11/16 (D) x 42-3/4 (H) inches... -
Page 48: Index
Index AC inlet ... 10 Adjuster ... 12 All Song Play ... 13 Audio equipment ... 36 Beat ... 18, 20 [Brilliance] knob ... 12 Built-in song ... 13 Chorus ... 21 Depth ... 21 Computer ... 36 Count-In ... 25 Damper pedal Resonance ... - Page 49 MEMO...
- Page 50 Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below. PHILIPPINES AFRICA AFRICA G.A. Yupangco & Co. Inc. 339 Gil J. Puyat Avenue EGYPT Makati, Metro Manila 1200,...
- Page 51 This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 52 Contents Name Instrument Music Stand (HP-3 only) Manual Set AC Cord Set Collection of Printed Music This owner’s manual is printed on recycled paper. Qty. HP-3 HP-7 02891323 ’04-2-7N...
