Roland CM-30 Owner's Manual

Cube monitor

Hide thumbs Also See for CM-30:

User manual

Table Of Contents

ROLAND CORPORATION

No part of this publication

may be reproduced in any

form without the written

permission of ROLAND

CORPORATION.

Owner's Manual

Thank you, and congratulations on your choice of the Roland CUBE

Monitor CM-30.

Before using this unit, carefully read the sections entitled:

•

IMPORTANT SAFETY INSTRUCTIONS (p. 2)

•

USING THE UNIT SAFELY (p. 3 and 4)

•

IMPORTANT NOTES (p. 5)

These sections provide important information concerning the proper

operation of the unit. Additionally, in order to feel assured that you have

gained a good grasp of every feature provided by your new unit,

Owner's manual should be read in its entirety. The manual should be

saved and kept on hand as a convenient reference.

This unit is equipped with a protection circuit. The protection circuit

helps ensure safety by operating when excessive input continues for a

long time while the device is at a location with a high ambient

temperature. Sound drop-out may occur when the protection circuit is

actuated during use. Please read through the documentation carefully to

ensure correct use.

Main Features

•

Musical instrument monitor amp with 30 W output power, yet

lightweight and compact for easy portability.

•

The newly developed, magnetically shielded 16 cm (6.5") coaxial two-

way speaker uses highly rigid, titanium vapor-deposited polypro-

pylene injection cones, delivering clear, distortion-free sound.

•

In addition to a mic/line channel that provides an XLR-type

connector, there are two stereo channels and two stereo AUX IN

channels with RCA phono and stereo mini-jack connections, giving

you a total of five sets of inputs. These inputs can be combined

within the CM-30 by its stereo mixer.

•

The Stereo Link function (p. 10) lets you easily connect two CM-30

speakers for stereo playback. When using Stereo Link, a total of ten

sets of input can be used.

•

The built-in, two-band equalizer lets you adjust the tone of the speaker.

•

The stereo headphone jack provides a volume control that is

independent of the speaker output volume.

•

The cabinet is designed for easy portability. A metal grille cover

protects the speaker, and the cabinet features corner protectors.

There's also an easy-gripping handle for convenient carrying.

Table of Contents

Summary of Contents for Roland CM-30

Page 1: Main Features
These inputs can be combined within the CM-30 by its stereo mixer. • The Stereo Link function (p. 10) lets you easily connect two CM-30 speakers for stereo playback. When using Stereo Link, a total of ten sets of input can be used.
Page 2: Instructions Pertaining To A Risk Of Fire, Electric Shock, Or Injury To Persons
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
Page 3 (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page. • Never use or store the unit in places that are: •...
Page 4 Roland Service Center, or an authorized Roland distributor, as listed on the “Infor- mation” page when: • The power-supply cord, or the plug has been damaged; or •...
Page 5: Important Notes
(including padding) that it came in, if possible. Otherwise, you will need to use equivalent packaging materials. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.
Page 6: Panel Descriptions
Panel Descriptions ■ Control Panel fig.01 ■ Jack Panel fig.01...
Page 7: Stereo Link
AUX IN jacks, use the controls on such equipment. 9. STEREO LINK Stereo playback is enabled simply by connecting two CM-30 units with a single or double audio cables (phone type). For details on the Stereo Link function, refer to “Using Two CM-30 Speakers for Stereo Playback (Stereo Link)”...
Page 8: Making The Connections
Making the Connections Refer to the figure shown below to connect the CM-30 and the other equipment. Recorder OUTPUT Stereo Link (p. 10) Here is an example of a setup that makes full use of the CM-30’s mixer and monitor functions.
Page 9: Switching The Power On And Off
Making the Connections About the Volume-level Settings In order to get optimum sound from the CM-30 when performing, set the volume as described below. 1. Operate the CH 1 through CH 3 volume knobs to adjust the volume level for CH 1 through CH 3.
Page 10 (phone type). This function is called “Stereo Link.” Since the CM-30’s mixer section operates in stereo, the L or R channel signal can be output from a STEREO LINK OUT jack. This means you can enjoy stereo playback by making connections as follows.
Page 11 Using a Microphone Stand By using a mic stand, you can mount the CM-30 at the optimal height for use as a monitor speaker or simple PA device. Requirements when using a mic stand ● As shown in the diagram below, the mic stand’s tripod must be extended to its...
Page 12: Block Diagram
Appendices Block Diagram fig.13 CH 1 CH 1 PHONE VOLUME CH 2 L (MONO) VOLUME CH 2 VOLUME CH 3 L (MONO) VOLUME CH 3 VOLUME AUX IN 1 AUX IN 2 LINK IN PHONES (STEREO) LINK OUT L LINK OUT R LOW HIGH SPEAKER EQUALIZER...
Page 13: Main Specifications
Main Specifications ● Rated Power Output 30 W ● Nominal Input Level (1 kHz) Channel 1 (MIC/LINE): -50 – -20 dBu Channel 2, 3 (LINE): -20 dBu AUX IN 1, 2: -10 dBu STEREO LINK IN: -10 dBu ● Nominal Output Level (1 kHz) STEREO LINK OUT L/R: -10 dBu 0 dBu = 0.775 Vrms ●...
Page 14 MEMO...
Page 15 MEMO...
Page 16 For EU Countries This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC. SD000523...
