CALERO
SMART TOILET SEAT
20-1/8" [510]
15" [380]
19-3/4" [503]
2-1/8" [55]
11-1/2" [291]
Measures: inch [millimeter]
INSTALLATION MANUAL
• Carefully read the instructions before starting the installation.
• This smart toilet seat should be installed by an experienced plumber.
If you are missing any part, please stop and contact us immediately at:
1-866-839-2888
OVE DECORS
p. 1
1-866-839-2888
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for OVE CALERO
Summary of Contents for OVE CALERO
- Page 1 CALERO SMART TOILET SEAT 20-1/8” [510] 15” [380] 19-3/4” [503] 2-1/8” [55] 11-1/2” [291] Measures: inch [millimeter] INSTALLATION MANUAL • Carefully read the instructions before starting the installation. • This smart toilet seat should be installed by an experienced plumber.
-
Page 2: Table Of Contents
CONTENT SAFETY NOTICE ..................... p.3 WARNINGS ...................... p.4 PART LIST ......................p.5 TOILET SEAT COMPATIBILITY................ p.6 INSTALLATION INSTRUCTIONS ..............p.7-8 FIRST TIME USE .................... p.9 CONTROLS DESCRIPTION ..............p.10-12 FEATURES ....................p.13 INTELLIGENT FEATURES ................p.14 CLEANING THE FILTER ................p.15 LONG TERM STORAGE ................ -
Page 3: Safety Notice
SAFETY NOTICE ATTENTION! BEFORE INSTALLING THE PRODUCT, YOU MUST READ AND UNDERSTAND CAREFULLY ALL BELOW WARNINGS. 1. It is forbidden to disassemble toilet by yourself. 2. Please do not set this product in a wet place, because it is an electronic product. If set in the bathroom, please insure that there is proper air flow. -
Page 4: Warnings
WARNINGS Do not leave the To prevent against power toilet exposed to the sun. surge damages, make May cause yellowing or sure the ground is working color fading. in the power socket. Direct sunlight affects the good functioning of the remote. -
Page 5: Part List
PART LIST Item Light Indicator Panel Water Inlet Side Control Panel Seat Water Tube Water Filter Inlet Valve (not supplied) Smart Seat (incl. electronics, cover, seat and lid) Smart Seat (incl. cover, seat and lid) Remote Receiver Mounting plate release button Sensor Nozzle Dryer outlet Remote Tee joint Mounting plate installation kit Thicker seat rim bumper Check valve p. -
Page 6: Toilet Seat Compatibility
TOILET SEAT COMPATIBILITY TO ENSURE THAT THE SMART SEAT IS COMPATIBLE WITH YOUR EXISTING TOILET BOWL: 4-1/2~ 6 5/16” [115~160] A) Ensure that the distance between the centers of seat installation holes is in the range given by “A”. B) Ensure that there is a clearance of at least “B” between the center of the seat installation holes and the front of the flush tank. C) Ensure that the distance between the center of the seat installation holes and the front edge of the toilet bowl is in the range given by “C”. D) Ensure that there is a clearance of at least “D” between the center of the toilet and the nearest wall on both sides. -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Turn off the water inlet valve before starting the installation of the smart toilet seat. 2. Only plug the smart seat to the electrical socket once the installation Loosely install the mounting plate with the plastic anchors, washers, is completely finished. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Screw the water supply hose to the Tee joint. Note that the filter is Turn off the inlet valve, and unscrew the supply hose from the toilet. located in the reducer. Connect the water tube to the smart seat. This is a pressure snap-in Screw the Tee joint to the toilet water inlet coupling. -
Page 9: First Time Use
FIRST TIME USE Open the water supply inlet valve. Plug the toilet in the power socket. The toilet’s blue light will start blinking. The blinking light indicates that the wash tank is filling with water, a sensor in the toilet will stop the filling process automatically after around 3 minutes when the tank is full of water. After the wash tank is filled with water, the indicator light will stop blinking. The toilet will turn ON automatically. Once the beeping sounds and the flashing light have stopped, the toilet is ready for use. Notice: • Warming up the toilet seat will take about 3 minutes. • Warming up the bidet cleaning water will take about 3 min. -
Page 10: Controls Description
CONTROLS DESCRIPTION POWER/ECO: Press 1 time, it will turn the toilet ON. Press 2 times, it will activate the ECO MODE. Press 3 times, it will turn the toilet OFF. REAR BIDET/MOVE & MANUAL NOZZLE WASH: Pressing this button will initiate the Static Rear Bidet Cleaning function. Press it again to change to the Back-&-Forth Rear Bidet Cleaning function. - Page 11 CONTROLS DESCRIPTION REAR BIDET/MOVE: Pressing this button will initiate the Static Rear Bidet Cleaning function. Press it again to change to the Back-&-Forth Rear Bidet Cleaning function. *The REAR BIDET refers the 1 water jet function of the nozzle. LADY BIDET/MOVE: Pressing this button will initiate the Static Lady Bidet Cleaning function.
- Page 12 CONTROLS DESCRIPTION SEAT TEMPERATURE: Pressing on this button will cycle through the 4 possible temperatures settings for the seat heating. 4 settings: Room temp / Low / Medium / High AIR TEMP: Pressing this button will cycle through the 4 possible temperatures settings for the air drying function. 4 settings: Room temp / Low / Medium / High LIGHT: Pressing this button will turn the toilet bowl’s light ON / OFF.
-
Page 13: Features
FEATURES REAR BIDET CLEANING (1 WATER JET) This function will only work if the user is sitting on the toilet. Press the REAR BIDET/ MOVE button for a rear bidet cleaning. Water will spray and clean the user. Press the button again and the nozzle will move back &... -
Page 14: Intelligent Features
INTELLIGENT FEATURES ECO MODE ECO MODE will cut down the electricity usage of your intelligent toilet during times of none-usage. The cleaning water tank will start heating the water only once the user is sitting on the toilet, whereas in normal mode, the cleaning water is kept to your preferences for your instant enjoyment. -
Page 15: Cleaning The Filter
CLEANING THE FILTER Close the inlet valve, turn clockwise. Unscrew the reducer from the Tee joint and Do not take out the filter before closing the take out the filter. inlet valve. Clean the filter. Install the filter back into the reducer. Use a tooth brush to clean the dirt on the Screw the reducer back onto the Tee joint. filter. -
Page 16: Long Term Storage
LONG TERM STORAGE In order to prevent from any damages that may be caused from frozen toilet water, please drain away the remaining water according to the following methods. When leaving for a long time without using this toilet, please make sure to drain all the water from the toilet. -
Page 17: Specification Sheet
SPECIFICATION SHEET Item Content AC 120V / 1300W / 60HZ Electric Load 1.2 m insulated power cord Electric Cord Cleaning System 1 jet REAR Bidet 4 jets LADY Bidet 4 settings: Room temp / LOW / MEDIUM / HIGH Water Temp AC 120V / 1200W / 60HZ Heater Capacity 500mL... -
Page 18: Maintenance & Consumer Responsibilities
MAINTENANCE & CONSUMER RESPONSIBILITIES ■ The DISTRIBUTOR does prohibits the use of harsh abrasive cleansers on any of its products. Harsh cleansers will damage the inner workings of the toilets. ■ For daily maintenance, use a wet cloth and a soft liquid cleaner. ■... -
Page 19: Installation Picture
INSTALLATION PICTURE p. 19... - Page 20 Save this manual for future reference Conservez ce manuel pour usage ultérieur Conserve este manual para futura referencia HEAD OFFICE / SIÈGE SOCIAL / OFICINA PRINCIPAL 2800 Etienne Lenoir, Laval Quebec H7R 0A3 Canada Customer service / Service à la clientèle / Service al cliente Tel.: 1-866-839-2888 Fax: 1-866-922-9990 8:00 am - 5:00 pm E.S.T Monday - Friday...
