- Page 1 GV-IPCam H.264 Hardware Manual Pinhole Camera Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. ICH264TG2V10...
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 4: Table Of Contents
Contents Contents ................i Options ................ii Chapter 1. Pinhole Camera ..........1 1.1 Packing List ................2 1.2 Features ...................3 1.3 Overview .................. 4 1.4 Installation ................1.5 Connecting the Camera............1.6 Loading Factory Default............ -
Page 5: Options
Options Optional devices can expand your camera’s capabilities and versatility. Contact your dealer for more information. Device Description The GV-PA191 PoE adapter is designed to provide GV-PA191 PoE power and network connection to the cameras Adapter over a single Ethernet cable. The GV-POE Switch is designed to provide power along with network connection for IP devices. -
Page 6: Chapter 1. Pinhole Camera
Pinhole Camera Chapter 1. Pinhole Camera The Pinhole Camera consists of a main body for processing and a separate camera lens for capturing images. The compact camera lens can be installed in surveillance sites with limited space such as behind the panel of an ATM machine. -
Page 7: Packing List
1.1 Packing List Pinhole Camera 1 m (3.28 ft) RJ-12 Cable Camera Adhesive Tape x 2 Installation Sticker Main Body Mount Main Body Adhesive Tape M3 Screw x 2 M2 Screw GV-IPCAM H.264 Software ... -
Page 8: Features
Pinhole Camera 1.2 Features 1/2.8" progressive scan super low lux CMOS Dual streams from H.264 or MJPEG Up to 30 fps at 1920 x 1080 Megapixel lens Day and night function (electronic) Micro SD card slot (SD/SDHC) for local storage ... -
Page 9: Overview
1.3 Overview Camera Lens Main Body Figure 1-1 Name Description Lens Receives images. Microphone Receives sounds. Lens Screw Loosens to adjust the camera lens. Use the supplied RJ12 cable to connect the RJ12 Port camera lens and main body. - Page 10 Pinhole Camera Name Description RJ12 Status Turns on (green) when the camera lens and main body are connected. Connects to a PoE adapter. Status LED Turns on (green) when the system is ready. Memory Card Inserts a micro SD card (SD/SDHC, version Slot 2.0, Class 10) to store recording data.
-
Page 11: Installation
1.4 Installation The Pinhole Camera is designed for indoors. You can install the camera lens behind a wall or the ceiling board. Note that the thickness of the wall or ceiling board must be under 4 mm. Figure 1-2 Paste the installation sticker on the ceiling or the wall where you want to install the camera lens. - Page 12 Pinhole Camera Paste one of the supplied camera adhesive tapes onto the camera lens. Figure 1-4 Remove the backing paper on the other side of the adhesive tape and attach the camera lens onto the wall or ceiling. The arrows on the camera lens point toward the top of the camera view.
- Page 13 Loosen the lens screw and adjust the position of the lens so that the metal ring is pressing against the wall or ceiling. Metal ring Lens screw Figure 1-6 Place the main body mount where you want to install it, and secure the mount using one of the methods below.
- Page 14 Pinhole Camera Align the main body with the mount as shown below and secure with the supplied M2 screw. Figure 1-9 Connect the camera lens and the main body using the RJ-12 cable. Connect the main body to the network and supply power via the PoE cable.
-
Page 15: Connecting The Camera
1.5 Connecting the Camera Use the supplied RJ12 cable to connect the camera lens and the main body. Figure 1-10 Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided over the network cable. Status LED Figure 1-11 The status LED of the camera will be on. -
Page 16: Loading Factory Default
Pinhole Camera 1.6 Loading Factory Default 1. Keep the PoE cable connected to the main body. 2. Use a pin to press and hold the Load default button on the panel. Status LED Load Default Figure 1-12 3. Release the default button when the status LED blinks. This shall take about 8 seconds.
