Powerline Networking Kit
RF-GUV1124
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERLINE RF-GUV1124 and is the answer not in the manual?

Questions and answers

Related Manuals for RocketFish POWERLINE RF-GUV1124

Summary of Contents for RocketFish POWERLINE RF-GUV1124

  • Page 1 Powerline Networking Kit RF-GUV1124 User Guide...

  • Page 2: Safety Information

    Rocketfish RF-GUV1124 Powerline Networking Kit Safety information Take the following precautions when using this product: • Read all instructions before installing and operating. • Keep all instructions for later reference. • Follow all warnings and instructions. • This product should not be installed in any electrical socket so that the product’s venting holes are pointing downward.

  • Page 3: Table Of Contents

    Contents Introduction ... 4 Features... 4 Setting up your powerline network... 9 Frequently asked questions...14 Troubleshooting ...15 Specifications...17 Legal notices ...18 90-day limited warranty...19 RF-GUV1124...

  • Page 4: Introduction

    Introduction Congratulations on your purchase of the Rocketfish RF-GUV1124 powerline Ethernet kit. This easy-to-use system enables you to connect any Ethernet network device (such as computers and game consoles) to other devices on your home network and to the Internet. Your powerline kit also lets you connect your network without the hassle of setting up wireless networking and complex security measures.
  • Page 5 Powerline Ethernet bridge Item Description Power indicator On—Power is on. Blinking—Device in standby mode or is in group joining mode. Off—Power is off. Ethernet link/activity indicator On—Ethernet network link detected. Blinking—Network traffic detected. Off—No Ethernet network link detected. Powerline link/activity indicator On—Powerline link detected, but no powerline network traffic is detected.
  • Page 6 Item Description Ethernet port—Connect to your router (recommended) or Internet modem. For more information, see “Connecting your powerline devices” on page 10. GROUP button—For custom network configuration, press this to create or join an additional powerline network. For more information, see “Creating additional networks”...
  • Page 7 Powerline Ethernet switch Item Description Power indicator On—Power is on. Blinking—Device in standby mode or is in group joining mode. Off—Power is off. Ethernet link/activity indicator On—Ethernet network link detected. Blinking—Network traffic detected. Off—No Ethernet network link detected. Powerline link/activity indicator On—Powerline link detected, but no powerline network traffic is detected.
  • Page 8 Item Description Ethernet port—Connect to your router (recommended) or Internet modem. For more information, see “Connecting your powerline devices” on page 10. GROUP button—For custom network configuration, press this to create or join an additional powerline network. For more information, see “Creating additional networks”...

  • Page 9: Setting Up Your Powerline Network

    Setting up your powerline network Choosing a location Before connecting your powerline devices, you need to determine where they need to be installed. Notes: • Make sure that the two powerline devices are in the same home power circuit. • These devices should be installed only in a residential setting. Do not install in a business environment.
  • Page 10 Powerline Ethernet switch Install the powerline Ethernet switch on the same home power circuit as your powerline Ethernet bridge, and near your gaming console or other device. Connecting your powerline devices To connect your powerline bridge: Plug your powerline bridge directly into a wall power socket. If other appliances are plugged into the same outlet, isolate them from the powerline bridge by using a noise-filtering power strip.
  • Page 11 Connecting tips Powerline networking sends data along the electrical wiring of your home, so the data can be corrupted by electrical interference (sometimes called “noise”) and the length of wiring it must pass through. Although your powerline devices can overcome most interference, it’s best to avoid creating interference so ensure the highest reliability.
  • Page 12 Creating additional networks Your Rocketfish powerline devices are all pre-configured to see each other as part of the same network. Each has the default network name of HomePlugAV, and any other Rocketfish powerline devices with the same network name recognize these as part of the same network.
  • Page 13 If, however, you want to set up multiple powerline networks in your home or change your powerline network’s name (for added security), you can configure the powerline devices to do so. To create an additional network and join devices to it: Make sure that your powerline devices are plugged into a powered wall outlet and are not in standby mode.

  • Page 14: Standby Mode

    After your first and additional devices’ power indicators stop blinking, your additional device has successfully joined your first device’s network. Resetting a powerline device to factory defaults You can easily restore factory default settings for any of your powerline devices. To reset a powerline device to its factory default settings: Make sure that your powerline devices are plugged into a powered wall outlet and are not in standby mode.

  • Page 15: Troubleshooting

    Powerline devices using different powerline communication protocols may have difficulty communicating with each other, although they all can co-exist on same electrical wiring. Your Rocketfish powerline devices are HomePlug AV compliant. They can communicate with any other HomePlug AV-compliant powerline device, regardless of brand.

  • Page 16: Troubleshooting Tips

    • The computer can access the Internet if you connect it directly to the router. If there is no Internet connection, troubleshoot the router or contact your ISP (Internet service provider). Troubleshooting tips • Powerline products work better when plugged directly into the wall power outlet, not power strips, extension cords, surge protectors, or uninterruptable power supplies.

  • Page 17: Specifications

    Specifications Items PHY rate 200 Mbps Effective data rate TCP: Up to 91 Mbps UDP: Up to 94 Mbps Frequency band Access methods Four-level priority-based contention access, and multi-segment bursting Modulation 10/100 RJ-45 ports Distance LAN standards PLC standard Operating system Maximum devices in a network group IGMP...

  • Page 18: Legal Notices

    Items Relative humidity Power source Power consumption Full load: 110 VAC=3.3 W 220 VAC=3.8 W 240 VAC = 4.2 W Standby mode <1.6 W Certification Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...

  • Page 19: 90-Day Limited Warranty

    Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 20 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2010 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 21 RF-GUV1124...
  • Page 23 RF-GUV1124...
  • Page 24 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2010 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. All other products and brand names are trademarks of their respective owners. 10-0764...
