4-Port WirelessHD Kit
RF-WHD200
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF-WHD200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RocketFish RF-WHD200

Summary of Contents for RocketFish RF-WHD200

  • Page 1 4-Port WirelessHD Kit RF-WHD200 User Guide...

  • Page 2: Table Of Contents

    Legal notices ...21 One year warranty...23 Introduction Thank you for purchasing this high-quality Rocketfish system, which represents the state of the art in 60 and gives you complete freedom while enjoying your music or movies without the limitations of cables.

  • Page 3: Safety Information

    • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. RF-WHD200...

  • Page 4: Features

    • Only use attachments or accessories specified by the manufacturer. • Unplug the included devices during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when a component of the kit has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 5 HDMI 1—When the indicator is on this HDMI port is in use. Power and link status indicator ( ) • Blinking—The power is on and the receiver is searching for the transmitter or is in sleep mode. • On—The transmitter and receiver are linked. • Off—The power is off. RF-WHD200...
  • Page 6 Receiver front/top panel Item Description Power and link status indicator ( ) • Blinking—The power is on and the receiver is searching for the transmitter or is in sleep mode. • On—The transmitter and receiver are linked. • Off—The power is off. Transmitter back panel Item Description DC IN jack—Connect the power adapter labeled “transmitter”...
  • Page 7 HDMI jack—Connect this port to an HDMI input on the TV or projector, using a high-speed HDMI cable. DC IN jack—Connect the power adapter labeled “Receiver” to this jack. Power switch—Turns the receiver on or off. Cable routing clips - Insert HDMI cable into these clips for receiver placement stability. Back view Left side view RF-WHD200...

  • Page 8: Remote Control

    Remote control Note: Remote control design subject to change. Item Description SLEEP button -Press to put the WirelessHD receiver and transmitter into sleep mode; or to "wake" them up from sleep mode if they do not automatically do so on their own (this functionality varies by brand and model of connected components).

  • Page 9: Setting Up The Hdwireless Kit

    - For best performance and range, mount the receiver vertically on the wall next to the TV (NOT behind the TV) or upside-down on the ceiling next to the projector, ensuring that the Rocketfish and WiHD logos can be seen from the position in the room where the transmitter will be located.
  • Page 10 Connecting the WirelessHD transmitter and receiver To connect the WirelessHD transmitter and receiver: Connect up to 4 HDMI enabled source components, such as a Blu-ray/DVD player, cable/satellite box, gaming console, laptop, etc., to the HDMI input jacks on the transmitter, using high-speed HDMI cables. Game console Transmitter HDMI cable...
  • Page 11 Power on your TV or projector and switch to the HDMI input that the WirelessHD receiver is connected to. Power on at least one source component that is connected to the WirelessHD transmitter. Receiver Display devices RF-WHD200...
  • Page 12 Power on the WirelessHD transmitter and receiver. The HDMI input port LED on the transmitter should light continously (stop blinking) to indicate that the desired input is selected with active video. If this selection does not occur automatically, please use the included remote control or HDMI Select Switch on back of the transmitter to select the desired input port.

  • Page 13: Using The Wirelesshd Kit

    Upon completion of the setup process and successful linking of the WirelessHD transmitter and receiver, follow these steps to use the WirelessHD kit: Power on the TV or projector that the WirelessHD receiver is connected to and switch to the corresponding HDMI input. Power on the WirelessHD receiver. RF-WHD200...
  • Page 14 Power on the source component you wish to view. Power on the WirelessHD transmitter. Switching the WirelessHD transmitter to the correct HDMI input: Note: When switching between the four HDMI ports, it is normal for the switching to take an average of about 10 seconds (sometimes up to 20 seconds; the further the WirelessHD transmitter and receiver are from each other, the longer the switching will take).
  • Page 15 Turning off an HDMI-CEC enabled TV sends a broadcast message to all wired HDMI and WirelessHD source devices, giving them the opportunity to power off automatically (if they support HDMI-CEC and this option is enabled in the device's settings). RF-WHD200...
  • Page 16 WirelessHD function on your sources to switch between them. For example, without full TV support for CEC source switching, you may need to power off the Rocketfish WirelessHD transmitter in order to be able to switch to a laptop with embedded WirelessHD.

  • Page 17: Troubleshooting

    • Either the receiver or transmitter is not powered on. Be sure the AC adapter is securely connected and each unit is powered on correctly. • Power cycle both the transmitter and receiver by unplugging then plugging them back in. RF-WHD200...
  • Page 18 • Troubleshoot by connecting the HDMI cable directly from the HDMI source to the HDMI display (bypassing the Rocketfish adapters) to verify that audio/video is available. Try both the HDMI source side cable (connected originally to the transmitter) as well as the display side cable (connected originally to the receiver) to verify that you do not have a defective cable.

  • Page 19: Specifications

    4:4:4 4:4:4 YCbCr 4:2:2 4:4:4 4:4:4 YCbCr 4:2:2 4:4:4 4:4:4 YCbCr 4:2:2 4:4:4 4:4:4 Bits/pixel 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits 24/30 bits RF-WHD200...
  • Page 20 Video Vertical format refresh 50 Hz 720p 59.94/60 Hz 50 Hz 1080i 59.94/60 Hz 23.976/24 Hz 50 Hz 1080p 59.94/60 Hz 60 Hz 60 Hz SVGA 60 Hz 60 Hz SXGA 60Hz WSXGA+ Color Sampling Bits/pixel space YCbCr 4:2:2 24/30 bits 4:4:4 24/30 bits 4:4:4...

  • Page 21: Audio Format

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 1080p@23.98/24 Hz 720p@50/59.94/60 Hz 1080p@23.98/24 Hz 720p@50/59.94/60 Hz 1080i@50/59.94/60 Hz 48 kHz 88.2 kHz 96 kHz 6.144 11.29 12.288 12.288 22.579 24.576 RF-WHD200 LPCM 2-channel 176.4 kHz 192 kHz 22.579 24.576 45.158 49.152...

  • Page 22: Fcc Radiation Exposure Statement

    • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 23: One Year Warranty

    Product is determined to be defective by an authorized Rocketfish repair center or store personnel, Rocketfish will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you.
  • Page 24 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Rocketfish to service the Product • Products sold as is or with all faults •...
  • Page 25 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2011 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. All other products and brand names are trademarks of their respective owners. 10-1353...
