- Page 1 Universal CPU Cooler RF-UPCUWR User Guide...
-
Page 2: Table Of Contents
Universal CPU Cooler Contents Important safety instructions ...3 Features...4 Package contents...7 Installing the cooler...8 Installing on an LGA 775/1156 platform ...8 Installing on an AMD platform... 11 Specifications... 15 One-year limited warranty ... 17... -
Page 3: Important Safety Instructions
8 The cooler is designed for computer usage only. Using the cooler in any other application will void the warranty. 9 If you are not familiar with computer hardware installation, see a qualified computer technician. RF-UPCUWR... -
Page 4: Features
Features Compatible with Intel Socket LGA 775/1156... - Page 5 Compatible with AMD Socket 754/939/940/AM2/AM RF-UPCUWR...
- Page 6 • Silent CPU cooler at only 18 dBA(at 800 rpm) • Maximum compatible CPU wattage: over 130 W TDP • Three direct-contact heat-pipes with aluminum fins to provide excellent heat dissipation • Option for adding second fan to increase cooling performance •...
-
Page 7: Package Contents
Package contents Item Description Cooler Screws (a) Screws (b) K8/AM2 retention plate (A) K8/AM2 retention plate (B) 775/1156 retention plate (1) 775/1156 retention plate (2) Thermal grease Quantity RF-UPCUWR... -
Page 8: Installing The Cooler
Installing the cooler Installing on an LGA 775/1156 platform To install the cooler: 1 Make sure that you select the correct retention plate for your processor. See “Package contents” on page 7. 2 Assemble the retention plate. LGA 775 1156... - Page 9 CPU. When the cooler is clamped to the processor, the grease will spread evenly to form a thin layer. 4 Place the cooler on the CPU, then press the push pins into place two at a time. RF-UPCUWR...
- Page 10 5 Connect the fan power cable. The following graphic is for reference only. Refer to the documentation for your system board for the location of the power connector.
-
Page 11: Installing On An Amd Platform
Installing on an AMD platform To install the cooler: 1 Make sure that you select the correct retention plate for your processor. See “Package contents” on page 7. 2 Assemble the retention plate. RF-UPCUWR... - Page 12 3 Remove the protective cover from the bottom of the cooler, then apply a small dab (about 1/2 the size of a pea) of thermal grease on the surface of the installed CPU. When the cooler is clamped to the processor, the grease will spread evenly to form a thin layer.
- Page 13 4 Place the cooler on the CPU, then push the lever down to secure the plate. RF-UPCUWR...
- Page 14 5 Connect the fan power cable. The following graphic is for reference only. Refer to the documentation for your system board for the location of the power connector.
-
Page 15: Specifications
3.62 × 3.62 × 0.98 inches (92 × 92 × 25 mm) 800 - 2800 rpm (PWM) 15.7 - 54.8 CFM 0.35 - 4.27 mmH2O 40,000 hours Long life sleeve bearing 12 V 4-pin 17-35 dBA 16.58 ounces (470 g) RF-UPCUWR... -
Page 17: One-Year Limited Warranty
One-year limited warranty Rocketfish Products (“Rocketfish”) warrants to you, the original purchaser of this new RF-UPCUWR (“Product”), that the Product shall be free of defects in the original manufacture of the material or workmanship for one (1) year from the purchase of the Product (“Warranty Period”). - Page 18 Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.
- Page 19 Product in the United States, Canada, and Mexico. What does the warranty not cover? This warranty does not cover: • Customer instruction • Installation • Set up adjustments • Cosmetic damage • Damage due to acts of God, such as lightning strikes • Accident RF-UPCUWR...
- Page 20 REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY. ROCKETFISH SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS OR LOST PROFITS.
- Page 21 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
- Page 23 RF-UPCUWR...
- Page 24 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2009 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. All other products and brand names are trademarks of their respective owners.
