Summary of Contents for Roberts R9927
- Page 1 R9927 3 Band Mains Battery Portable Radio Please read this manual before use...
-
Page 2: Table Of Contents
Contents Important Information ... 1 Controls ... 2-3 Battery Operation ... 4 Mains Operation ... 4 Operating your radio - FM ... 5 Operating your radio - Medium and Long wave ... 6 Headphones ... 7 General ... 7 Specifications ... 8 Notes ... -
Page 3: Controls
Controls (Top) 1. Power button 2. Waveband buttons 3. Telescopic aerial 4. Tuning control If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) 5. Treble control 6. Dial pointer 7. Bass control 8. -
Page 4: Controls
Controls (Rear) 9. Headphone socket (on side) 10. Battery compartment 11. Mains socket... -
Page 5: Battery Operation
4. If the radio is not to be used for any extended period of time it is recommended that the batteries are removed from the radio. We would recommend for economy that the R9927 is used on the mains whenever possible with battery operation for occasional or stand-by use only. -
Page 6: Operating Your Radio Fm
Operating your radio FM 1. Switch on your radio by pressing the Power button. 2. Press the FM button to select the FM waveband. 3. Adjust the Volume control until a hissing sound is heard. 4. Rotate the Tuning control to select the desired station. On FM the Tuning scale is marked in Megahertz (MHz). -
Page 7: Operating Your Radio - Medium And Long Wave
Operating your radio (Medium and Long wave) 1. Switch on your radio by pressing the Power button. 2. Press either the MW or LW button. 3. Adjust the Volume control until a hissing sound is heard. 4. Rotate the Tuning control to select the desired station. On MW and LW the Tuning scale is marked in kilohertz (kHz). -
Page 8: Headphones
Headphones 1. A Headphone Socket (3.5mm) located on the right hand end of your radio is provided for use with either headphones or an earpiece. Inserting the headphone plug automatically mutes the internal loudspeaker. General Do not allow this unit to be exposed to dripping or splashing. Do not leave your radio where excessive heat could cause damage such as in a parked car where the heat from the sun can build up even though the outside temperature may not seem too high. -
Page 9: Specifications
If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) Circuit Features Loudspeaker only Output Power Headphone socket Aerial System FM ROBERTS RADIO LIMITED PO BOX 130 MEXBOROUGH SOUTH YORKSHIRE S64 8YT 92mm 4ohms 1W into 4ohms 3.5mm dia... -
Page 10: Notes
Notes:... -
Page 11: Guarantee
In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action. - Page 12 ROBERTS RADIO TECHNICAL SERVICES DEPARTMENT 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline:- 020 8758 0338 (Mon-Fri) Issue 1...
