Contents ... 2 Controls ... 3-5 Battery Operation ... 6 Using the AC Adaptor ... 6 Listening to the radio - FM ... 7 Listening to the radio - Medium and Long wave ... 8 Headphones ... 8 General ... 9 Mains Supply ...
Controls (Front) 1. Tuning dial 2. Waveband switch 3. Tuning indicator 4. Low battery indicator 5. Volume Control If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)
Controls (Right side) 8. Rubber socket cover 9. Headphone socket 10. DC input socket If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)
Battery operation 1. Open the Battery cover on the rear of your radio by removing the screw, lifting the cover flap and opening the door in a downward direction. 2. Insert four LR14 (C size) batteries into the spaces in the compart- ment.
Listening to the radio - FM 1. Select 'FM' using the Waveband switch. 2. Adjust the Volume control until a hissing sound is heard. 3. If not already fitted, screw the Rubber aerial into place on the top of the radio. 4.
Listening to the radio - Medium and Long wave 1. Select 'MW' or 'LW' using the Waveband switch. 2. Adjust the Volume control until a hissing sound is heard. 3. Carefully tune to the desired station using the Tuning control. The Tuning indicator will light when the station is correctly tuned.
Specifications Power Requirements Mains AC 230 volts, 50Hz Batteries 4 x LR14 (C size) Frequency Coverage Circuit Features only. Loudspeaker Output Power Headphone socket 3.5mm dia Aerial System 87.5-108MHz 522- 1600kHz 144- 281kHz The Company reserves the right to amend the specification without notice. 2 x 77mm 8ohms 2 x 1.6 Watts Rubber aerial...
In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action.
