RC9907 Issue 3.pmd
1
88
94
96
100 104
F M
M ains
M W
5 40
6 00
8 0 0
100 0
12 0 0
Ala rm o ff
M od e
Se t
LW
150
160
18 0
2 00
2 2 0
2 40
ROBERTS
R C 9907
3 Band Ra dio Cassette Re corder
with Programmable Clock Alarm
RC9907
3 Band Radio Cassette
106
108
M H z
k H z
16 0 0
2 60
k H z
Please read this manual before use
1/26/2007, 1:35 PM
Recorder
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Roberts RC9907
Summary of Contents for Roberts RC9907
- Page 1 RC9907 Issue 3.pmd 100 104 M H z M ains 5 40 k H z 6 00 8 0 0 100 0 12 0 0 16 0 0 Ala rm o ff M od e Se t 18 0 2 00...
-
Page 2: Right Side
Controls 1. Microphone 2. Headphone socket 3. Volume control 4. Telescopic aerial 5. Operation switch RC9907 Issue 3.pmd (Top) 6. Function switch 11. Rewind button 7. Waveband switch 12. Fast forward button 8. Tuning control 13. Stop/eject button 9. Record button 14. -
Page 3: Controls (Front)
15. Cassette door 16. Set button 17. Mode button If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd 18. Alarm off button 19. Mains indicator 20. Clock display. 1/26/2007, 1:35 PM... -
Page 4: Battery Operation
5. If your radio cassette is not to be used for any extended period of time it is recommended that the batteries are removed from the radio. We would recommend for economy, that the RC9907 is used on the mains whenever possible with battery operation for occasional or stand-by use only. - Page 5 8. To switch off the radio set the Function switch to the 'Tape Off ' position. If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd Waveband FM MW LW 100 104...
- Page 6 6. Rotate your radio cassette for optimum reception. 7. The MW and LW bands are marked in kilohertz (kHz). 8. To switch off the radio set the Function switch to the 'Tape Off ' position. RC9907 Issue 3.pmd Operation Auto Manual...
-
Page 7: Listening To Cassette Tapes
9. To stop the tape and switch off your radio cassette press the Stop/Eject button. If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd Operation Auto Manual Radio... -
Page 8: Recording From The Radio
When making a recording from MW and LW broadcasts, there may be a lot of background noise. Set the Beat cut switch located at the back of the cabinet to position 0, 1, or 2 in which noise is less prominent. RC9907 Issue 3.pmd Operation Auto... -
Page 9: Recording From The Internal Microphone
Note : to reduce background noise it is important to speak as close as possible to the Internal microphone . If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd Operation Auto Manual... -
Page 10: Setting The Clock
24hr mode, this is indicated by the letter 'H' after the hours digit. To change back to 12hr mode repeat the procedure. 12hr mode is indicated by the letter 'A' for AM or 'P' for PM after the hours digit. RC9907 Issue 3.pmd Alarm off Mode... -
Page 11: Setting The Date
4. Press the Mode button until the required minute is displayed. 5. Press the Set button to return to the normal clock display. If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd Alarm off Mode Alarm off... - Page 12 6. Press the Set button three times to return to the normal clock display. The radio will now turn on at the selected alarm time. 7. To cancel the alarm whilst the alarm is sounding press the Alarm off button. RC9907 Issue 3.pmd Operation Auto Manual symbol is showing.
- Page 13 Note : this function is not available if either the radio or tape functions are being used. If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd Operation Auto Manual...
-
Page 14: Displaying The Alarm Time
Displaying the seconds 1. Whilst the current time is displayed press the Mode button three times. The seconds will be displayed. 2. Press the Mode button to switch back to current time. RC9907 Issue 3.pmd Alarm off Mode Alarm off... -
Page 15: Headphones Socket
If you need any further advice, please call our Technical Helpline on :- 0208 758 0338 (Mon-Fri) RC9907 Issue 3.pmd M ic P h o n e s V ol u m e... -
Page 16: Cleaning The Heads
MW or LW bands. • The name plate is located at the underside of the radio cassette recorder. RC9907 Issue 3.pmd • No objects filled with liquids such as vases, shall be placed on the radio. -
Page 17: Mains Supply
Mains supply The RC9907 will operate from a supply of AC 230 volts, 50Hz DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adaptor. -
Page 18: Specifications
Clock Battery Frequency Coverage 87.5 - 108MHz 525 - 1610kHz 150 - 260kHz The Company reserves the right to amend the specification without notice. RC9907 Issue 3.pmd Circuit Features Loudspeaker only 1 x LR6 (AA size) Aerial System ROBERTS RADIO LIMITED... - Page 19 In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action. These statements do not affect the statutory rights of a consumer. RC9907 Issue 3.pmd Guarantee 1. Damage resulting from incorrect use.
- Page 20 ROBERTS RADIO TECHNICAL SERVICES DEPARTMENT 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline:- 0208 758 0338 (Mon-Fri) Issue 3 Website: http://www.robertsradio.co.uk RC9907 Issue 3.pmd 1/26/2007, 1:35 PM...
