Roberts GlowTime CR9952 Product Manual

Roberts GlowTime CR9952 Product Manual

Roberts radio alarm clock radio product manual
Hide thumbs Also See for GlowTime CR9952:

Advertisement

Quick Links

CR9952
Alarm Clock Radio
Please read this manual before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GlowTime CR9952 and is the answer not in the manual?

Questions and answers

Summary of Contents for Roberts GlowTime CR9952

  • Page 1 CR9952 Alarm Clock Radio Please read this manual before use...
  • Page 2: Table Of Contents

    Contents Contents ... 1 Controls ... 2-4 Batteries ... 5 Switching on and setting the time ... 6 Listening to the radio ... 7 Setting the alarm time ... 8 Snooze control ... 9 Sleep function ... 9 Backlight ... 10 Using the AC Adaptor ...
  • Page 3: Controls

    Controls Front 1. Clock Display 2. Minute hand 3. Hour hand 4. Alarm hand 5. Second hand Back 6. Battery Cover 7. Light Mode button 8. Mains Supply Socket...
  • Page 4 Controls 9. Tuning scale 10. Radio On/Off button 11. Sleep button 12. Snooze button 13. Speaker 14. Alarm/Off button 15. Light/Off button...
  • Page 5: Controls

    Controls Left hand side 16. Time Set control 17. Alarm Set control If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) Right hand side 18. Tuning control 19. FM/MW switch 20. Volume control...
  • Page 6: Batteries

    1. Press the On/Off button to switch the radio off before replacing batteries. 2. Open the battery cover located on the rear of your clock radio by pressing the catch down and pulling the battery cover towards you. 3. Insert 4 x AA batteries into the compartment. Make sure the (+) and (-) ends of the batteries are positioned as shown inside the compartment.
  • Page 7: Switching On And Setting The Time

    Switching on and setting the time Before using your alarm clock radio you must first set the correct time. 1. Check that the batteries have been installed correctly. 2. Place the unit on a flat surface. 3. Press in and turn the Time Set control.Rotating the control will move the clock hands, continue until the correct time is reached.
  • Page 8: Listening To The Radio

    3. Tune in to the desired station by rotating the Tuning control. The station frequency is indicated in the Tuning scale. The Wire aerial located on the rear of your clock radio is for FM reception. The wire should be fully extended and positioned for optimum reception.
  • Page 9: Setting The Alarm Time

    Setting the alarm time The alarm can be set to wake you by a buzzer. 1. Press the Alarm/Off button. 2. Press in and turn the Alarm Set dial. Rotating the dial will move the alarm hand, continue until the correct time is reached. The buzzer will sound at the preset time.
  • Page 10: Snooze Control

    Snooze control 1. The buzzer alarm can be silenced for 5 minutes by pressing the Snooze button. This sequence can be repeated during the 90 minute alarm period. Sleep function 1. The radio can be set to switch off automatically after a preset time has elapsed.
  • Page 11: Backlight

    Backlight The Backlight illuminates the clock display, making it easy to view in a dark environment. 1. Press and hold the Light/Off button on the top of the clock to turn on the Green backlight. The light will go off once the button is released.
  • Page 12: Using The Ac Adaptor

    The AC adaptor should be disconnected from the mains supply and the radio when not in use. The AC adaptor for use with the CR9952 should provide 4.5 volts DC output at 300mA, centre pin negative. We would recommend for economy that your radio is used via the AC adaptor whenever possible with battery operation for occasional or stand-by use only.
  • Page 13: Notes

    Notes If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri)
  • Page 14: Specifications

    Specifications Power Requirements Mains AC230 volts, 50Hz~ only Adaptor Output DC4.5 volts, 300mA Battery 4 x LR6 (AA Size) alkaline Frequency Coverage 87.5 - 108MHz 525 - 1605kHz The Company reserves the right to amend the specification without notice. General Do not allow this unit to be exposed to moisture (e.g.
  • Page 15: Guarantee

    In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services department at the address shown on the rear of this manual before taking further action.
  • Page 16 ROBERTS RADIO TECHNICAL SERVICES 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline:- 020 8758 0338 (Mon-Fri) Issue 1...
