The economical unitary infrared heater installation, operation & service manual

Advertisement

FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. DO NOT try to light any appliance.
3. DO NOT use electrical switches.
4. DO NOT use any telephone in
your building.
5. Extinguish any open flame.
6. Leave the building.
7. Immediately call your local gas
supplier after leaving the building.
Follow the gas supplier's
instructions.
8. If you cannot reach your gas
supplier, call the Fire Department.
WARNING
Fire Hazard
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Some objects can catch fire or explode
when placed close to heater.
Failure to follow these instructions can
result in death, injury or property
damage.
© 2009 Roberts-Gordon LLC
GordonRay
The Economical Unitary
Installation, Operation &
Please take the time to read and understand
these instructions prior to any installation.
Installer must give a copy of this manual to the owner.
Keep this manual in a safe place in order to provide
your serviceman with necessary information.
Roberts-Gordon LLC
1250 William Street
P.O. Box 44
Buffalo, New York 14240-0044
Telephone: 716.852.4400
Fax: 716.852.0854
Toll Free: 800.828.7450
www.rg-inc.com
www.radiantheaters.com
®
Infrared Heater
Service Manual
BH-40
BH-125
BH-60
BH-140
BH-80
BH-150
BH-100
BH-175
BH-115
BH-200
Installer
Owner
P/N 170101NA Rev. K 03/09
BH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GordonRay BH-115 and is the answer not in the manual?

Questions and answers

Summary of Contents for Roberts Gorden GordonRay BH-115

  • Page 1 FOR YOUR SAFETY If you smell gas: 1. Open windows. 2. DO NOT try to light any appliance. 3. DO NOT use electrical switches. 4. DO NOT use any telephone in your building. 5. Extinguish any open flame. 6. Leave the building. 7.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1: Heater Safety... 1 1.1 Manpower Requirements ... 1 1.2 Safety Labels and Their Placement ... 1 SECTION 2: Installer Responsibility ... 3 2.1 Wall Tag ... 3 2.2 Corrosive Chemicals... 3 2.3 National Standards and Applicable Codes ... 3 SECTION 3: Clearances to Combustibles...
  • Page 5 TABLE OF FIGURES Figure 1: Top and Bottom Panel Label Placement ... 1 Figure 2: Side and Back Panel Label Placement ... 2 Figure 3: Standard Reflector ... 5 Figure 4: One Side Reflector... 5 Figure 5: Two Side Reflectors ... 5 Figure 6: 45°...
  • Page 7: Safety Labels And Their Placement

    SECTION 1: HEATER SAFETY Your Safety is Important to Us! This symbol is used throughout the manual to notify you of possible fire, electrical or burn hazards. Please pay special attention when reading and following the warnings in these sections. Installation, service and annual inspection of heater must be done by a contractor qualified in the installation and service of gas-fired heating equipment.
  • Page 8: Figure 2: Side And Back Panel Label Placement

    BH-S ERIES NSTALLATION PERATION AND ERVICE FIGURE 2: Side and Back Panel Label Placement Rating Plate Label DSI Ignition Module BLUE 24VAC DSI Ignition Module Module d’allumage BLUE 24VAC BLACK Flame Sense Electrode par étincelle YELLOW Ground Module d’allumage Électrode BLACK Flame Sense Electrode...
  • Page 9: National Standards And Applicable Codes

    SECTION 2: INSTALLER RESPONSIBILITY The installer is responsible for the following: • To install the heater, as well as the gas and electrical supplies, in accordance with applicable specifications and codes. Roberts-Gordon LLC recommends the installer contact a local Building Inspector or Fire Marshal for guidance.
  • Page 10: Section 3: Clearances To Combustibles

    BH-S ERIES NSTALLATION PERATION AND ERVICE SECTION 3: CLEARANCES TO COMBUSTIBLES 3.1 Required Clearances to Combustibles Clearances are the required distances that combustible objects must be away from the heater to prevent serious fire hazards. Combustibles are materials that may catch on fire and include common items such as wood, paper, rubber, fabric, etc.
  • Page 11: Figure 3: Standard Reflector

    NOTE: 1. All dimensions are from the surfaces of all tubes, couplings and elbows. 2. Clearances B, C and D can be reduced by 50% after 25' (7.5 m) of tubing downstream from where the burner and burner tube connect. FIGURE 3: Standard Reflector FIGURE 4: One Side Reflector FIGURE 5: Two Side Reflectors...
  • Page 12: Figure 6: 45° Tilt Reflector

    BH-S ERIES NSTALLATION PERATION AND ERVICE NOTE: 1. All dimensions are from the surfaces of all tubes, couplings and elbows. 2. Clearances B, C and D can be reduced by 50% after 25' (7.5 m) of tubing downstream from where the burner and burner tube connect. FIGURE 6: 45°...
  • Page 13: Figure 9: U-Tube, Opposite 45° Reflector

    NOTE: 1. All dimensions are from the surfaces of all tubes, couplings and elbows. 2. Clearances B, C and D can be reduced by 50% after 25' (7.5 m) of tubing downstream from where the burner and burner tube connect. FIGURE 9: U-Tube, Opposite 45°...
  • Page 14: Figure 12: Venting

    BH-S ERIES NSTALLATION PERATION AND ERVICE NOTE: 1. All dimensions are from the surfaces of all tubes, couplings and elbows. 2. Clearances B, C and D can be reduced by 50% after 25' (7.5 m) of tubing downstream from where the burner and burner tube connect. FIGURE 12: Venting ANUAL (inches)
  • Page 15: Gas Codes

    SECTION 4: NATIONAL STANDARDS AND APPLICABLE CODES 4.1 Gas Codes The type of gas appearing on the nameplate must be the type of gas used. Installation must comply with national and local codes and requirements of the local gas company. United States: Refer to National Fuel Gas Code NFPA 54/ANSI Z223.1 - latest revision.
  • Page 16: Section 5: Major Components

    BH-S ERIES NSTALLATION PERATION AND ERVICE SECTION 5: MAJOR COMPONENTS FIGURE 13: Major Component Descriptions Burner with Tube Gasket Must be installed with the flame observation window facing down. Burner Tube Supplied in 10' (3 m) lengths. Burner tube is always the first tube after the burner.
  • Page 17: Standard Parts List

    5.1 Standard Parts List Table 1: Contents of BH-Series Burner Carton Part No. Description 071XXXXX Burner (Rate and Fuel Varies) 90709700 Blower Assembly with Cord 02568200 Gasket (Burner to Burner Tube) 90709801 Gasket (Blower to Burner) 170101NA Installation, Operation and Service Manual 91201708 Pipe Nipple (Black) 1/2"...
  • Page 18: Table 3: Bh-Series Component Package Guide

    BH-S ERIES NSTALLATION PERATION AND ERVICE Table 3: BH-Series Component Package Guide Tubing Length Model Minimum BH-40 10' (3 m) BH-60 20' (6 m) BH-80 20' (6 m) BH-100 30' (9 m) BH-115 30' (9 m) BH-125 40' (12 m) BH-140 40' (12 m) BH-150...
  • Page 19: Section 6: Heater Installation

    SECTION 6: HEATER INSTALLATION WARNING Severe Injury Hazard Secure burner to burner tube with bolts and lockwashers. Hang heater with materials with a minimum working load of 75 lbs (33 kg). Failure to follow these instructions can result in death, injury or property damage. WARNING Cut/Pinch Hazard Wear protective gear during installation,...
  • Page 20: Figure 14: Critical Hanger Placement

    BH-S ERIES NSTALLATION PERATION AND ERVICE FIGURE 14: Critical Hanger Placement Description Part Number S-Hook 91907302 Tube/Reflector Hanger 03090100 ANUAL Run Length Typical Expansion 10' (3 m) - 50' (15.2 m) 51' (15.5 m) - 60' (18.3 m) 61' (18.6 m) - 80' (24.4 m) Minimum “X”...
