Roberts Gorden II Features & Benefits

Feature
Layout & Installation:
Design based on over 30 years of infrared heating experience
Broad range of high BTUH input burners and tube lengths; straight,
"U" or "L" configurations available
Reflectors can be tilted or side reflectors can be added
Designed to readily accept low voltage thermostats
Quick assembly stainless steel couplings
Standard flue connector
Option of decorative grille for drop ceiling applications
Operation:
Operates with natural gas or LP gas (propane)
Honeywell® SmartValve® II control
Hot surface electronic ignition control
Prepurge and timed trial for ignition with multiple ignition trial
Auto reset from lockout
Low-intensity infrared heat
Deep-dish, high efficiency aluminum reflectors with end caps
Safety:
SmartValve® II control provides all gas ignition safety functions
CSA design certified
Electrical and burner components separated by a partition
Stainless steel flex gas connector included
Door interlock switch
Detailed Installation, Operation and Service manual
Maintenance:
Diagnostic capability incorporated in burner design
Separate burner compartment
Durable, spot welded burner construction with electrostatically
applied paint
Removable burner doors
Mica flame observation window
Three-year limited warranty on all components
CTH2FBNA
Features/Benefits of the Vantage
Setting the Standard in Unitary Infrared Heating
Printed in USA
®
II
Benefit
Field-proven product performance
Fits any building size or floor plan
Concentrates heat where needed
Reduces installation cost – no additional transformer required for
single heater installation.
Minimizes installation time
Easy vent installation
Aesthetically-appealing look in high visibility areas
Fuel efficient and environmentally friendly
Combines the gas valve and electronic ignition control functions
into one single unit
Reliable start-up
Reduces nuisance lockouts
Resets the system after one hour of lockout and begins another
sequence for ignition
Warms people and objects directly, not the air
Maximizes energy reflection; minimizes heat loss by convection
Controls gas flow, ignition source and combustion air blower and
monitors pressure switch
Independent testing to industry standards
Minimizes negative effects of contaminants and back draft
Reliable, durable gas piping
Halts burner operation for service
Reduces installation time and errors; easier to troubleshoot and
repair
Reduces service time
Protects valuable electrical controls from heat exposure and
extends life of componentry
Strong, long-lasting unit
Easy access for service
Flame verification and burner operation easy to observe
No hidden short-term exceptions for electrical and gas components
