Feature
Layout & Installation:
Centralized burner location
Highest single burner inputs in the infrared industry
Lowest clearances to combustibles, relative to total heater
input, in the infrared industry
Broad range of high BTUH input burners and tube lengths;
straight, "U" or "L" configurations available
Reflectors can be tilted or side reflectors can be added
Quick assembly stainless steel couplings
Option of decorative grille (for suspended ceiling
applications) or protective grille

Operation:

Operates with natural gas or LP (propane) gas
Low-intensity infrared heat
Deep-dish, high efficiency aluminum reflectors with end
caps
Dual direct spark ignition requires lower amperage draw
Three-try ignition module

Safety:

CSA design certified
Electrical and burner components separated by a partition
Stainless steel flex gas connector included
Detailed Installation, Operation and Service manual

Maintenance:

Separate burner compartment
Durable, welded burner construction with electrostatically
applied paint
Removable burner doors
Mica flame observation window
Green indicator light
Three-year limited warranty on all components
TFFBNA

Features/Benefits of the Vantage

The Twin Fire Unitary Infrared Heater
Printed in USA
®
TF
Benefit
Provides the most effective heat distribution in the unitary
infrared market
Reduces installation cost
Frees valuable workspace
Fits any building size or floor plan
Concentrates heat where needed
Minimizes installation time
Aesthetically-appealing look in high visibility areas
Fuel efficient and environmentally friendly
Warms people and objects directly, not the air
Maximizes energy reflection; minimizes heat loss by
convection
Reduces electricity and installation costs, reliable operation
Reduces nuisance lockouts
Independent testing to industry standards
Minimizes negative effects of contaminants and back draft
Reliable, durable gas piping
Reduces installation time and errors; easier to troubleshoot
and repair
Protects valuable electrical controls from heat exposure and
extends life of components
Strong, long-lasting unit
Easy access for service
Flame verification and burner operation easy to observe
Gas valve/burner verification
No hidden short-term exceptions for electrical and gas
components
